2.0L - Cooling System - Engine Code(s): Cbea: Overview Audi A3 8P facelift 2

Cooling Fan 2 illustrations ~170 words

RADIATOR AND COOLANT FAN ASSEMBLY OVERVIEW

WARNINGRisk of injury from coolant fan starting by itself. Before working in fan shroud area, disconnect electrical connectors.

Scheme 55

Scheme 55
Scheme 55
  1. Coolant Fan -V7- With coolant fan control module -J293- Removing and installing, refer to «COOLANT FANS»(ref-496039-S30172444172012082100000)
  2. Nut 5 Nm
  3. Fan Rib Removing and installing, refer to «FAN SHROUD»(ref-496039-S03744169842012082100000)
  4. Upper Coolant Hose Lift the retaining clamp to remove Connect to the radiator «RADIATOR AND COOLANT FAN ASSEMBLY OVERVIEW»(ref-496039-S33964898452012082100000)
  5. O-ring Replace
  6. Radiator Removing and installing, refer to «RADIATOR»(ref-496039-S05831779592012082100000) Change coolant after replacing
  7. O-ring Replace
  8. Lower Coolant Hose Lift the retaining clamp to remove Connect to the radiator «RADIATOR AND COOLANT FAN ASSEMBLY OVERVIEW»(ref-496039-S33964898452012082100000)
  9. Bolt 5 Nm
  10. Nut 5 Nm
  11. Bolt 5 Nm
  12. Coolant Fan 2 -V177- Removing and installing, refer to «COOLANT FANS»(ref-496039-S30172444172012082100000)

Scheme 56

Scheme 56: CONNECT THE COOLANT HOSE WITH THE CONNECTOR COUPLING
Scheme 56: CONNECT THE COOLANT HOSE WITH THE CONNECTOR COUPLING

Remove the old O-ring -2- in the coolant hose -3-.

Coat new O-ring with coolant and install it in the coolant hose.

Press the coolant hose onto the connection -1- until it engages audibly.

Press the coolant hose on again and pull to make sure the connection is engaged correctly.
