Note. Always replace seals and gaskets. Check thermal switch for proper function. See COOLANT FAN CONTROL (FC) THERMAL SWITCH, CHECKING . It is not necessary to remove the toothed belt to remove the thermostat. Arrows on ends of hoses must be aligned with arrows on coolant pipes. Tightening torque for coolant pipe hose clamps: 3-3.5 Nm (27-31 in lb). An oil cooler, located between the oil filter and the oil filter bracket, is connected to the coolant circuit.
Note. The following list refers to items in (Scheme 1).
- Thermostat Replacing. See «THERMOSTAT, REPLACING»(ref-201030-S04202789712005102400000) . Start of opening. See «THERMOSTAT, REPLACING»(ref-201030-S04202789712005102400000) .
- Seal Always replace
- Thermostat housing
- 10 Nm (7 ft lb)
- Gasket Always replace
- Coolant Pump To remove and install, remove ribbed drive belt and toothed belt
- 10 Nm (7 ft lb)
