Wipers/washers (4-cyl) Acura TSX II

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

DTC B1028: Rear Window Wiper Motor (As) Signal Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Operate the rear window wiper for at least 15 seconds, then turn the rear window wiper switch OFF. NOTE: If the wiper motor does not run, go to step 13 . Do the wiper arms stop at AUTO STOP (As) position? YES -Go to step 4. NO -Go to step 5 .
4. Check for DTCs with the HDS. Is DTC B1028 indicated? YES -Check for loose or poor connections at the passenger's MICU and the rear window wiper motor. If the connections are OK, replace the passenger's under-dash fuse/relay box (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl) ). NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections.
5. Turn the ignition switch to LOCK (0).
6. Do the rear window wiper motor test (see «WIPER MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ). Is the rear window wiper motor OK? YES -Go to step 7. NO -Replace the rear window wiper motor (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ) and recheck.
7. Disconnect the rear window wiper motor 4P connector.
8. Disconnect passenger's under-dash fuse/relay box connector H (38P).
9. Check for continuity between rear window wiper motor 4P connector terminal No. 2 and passenger's under-dash fuse/relay box connector H (38P) terminal No. 32. Is there continuity? YES -Go to step 10. NO -Repair an open or high resistance in the wire.
10. Check for continuity between rear window wiper motor 4P connector terminal No. 2 and body ground. REAR WINDOW WIPER MOTOR 4P CONNECTOR Is there continuity? YES -Repair a short to ground in the wire. NO -Go to step 11.
11. Turn the ignition switch to ON (II).
12. Measure the voltage between rear window wiper motor 4P connector terminal No. 2 and body ground. Is there voltage? YES -Repair a short to power in the wire. NO -Faulty passenger's MICU; replace the passenger's under-dash fuse/relay box (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl) ).
13. Turn the ignition switch to LOCK (0).
14. Check the No. 4(10 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 15. NO -Replace the fuse. If the fuse blows again, repair the short to ground on the No. 4(10 A) fuse circuit.
15. Do the rear window wiper motor test (see «WIPER MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ). Is the rear window wiper motor OK? YES -Go to step 16. NO -Replace the rear window wiper motor and recheck.
16. Reconnect the rear window wiper motor 4P connector.
17. Turn the ignition switch to ON (II).
18. Measure the voltage between rear window wiper motor 4P connector terminal No. 1 and body ground. with the rear window wiper switch ON. REAR WINDOW WIPER MOTOR 4P CONNECTOR Is there battery voltage? YES -Go to step 26 . NO -Go to step 21 .
19. Disconnect passenger's under-dash fuse/relay box connector A (38P).
20. Disconnect driver's under-dash fuse/relay box connector F (33P).
21. Check for continuity between driver's under-dash fuse/relay box connector F (33P) terminal No. 30 and passenger's under-dash fuse/relay box connector A (38P) terminal No. 7. Is there continuity? YES -Go to step 23 . NO -Repair an open or high resistance in the wire.
22. Disconnect the rear window wiper motor 4P connector.
23. Check for continuity between rear window wiper motor 4P connector terminal No. 1 and passenger's under-dash fuse/relay box connector H (38P) terminal No. 33. Is there continuity? YES -Go to step 24. NO -Repair an open or high resistance in the wire.
24. Check for continuity between rear window wiper motor 4P connector terminal No. 3 and body ground. Is there continuity? YES -Faulty rear window wiper motor relay circuit; replace the passenger's under-dash fuse/relay box (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl) ). NO -Repair an open or high resistance in the wire or poor ground (G901).
25. Disconnect the rear window wiper motor 4P connector.
26. Check for continuity between rear window wiper motor 4P connector terminal No. 3 and body ground.

REAR WINDOW WIPER MOTOR 4P CONNECTOR

Scheme 54

Is there continuity?

YES -Check for loose or poor connections at the passenger's MICU and the rear window wiper motor, and recheck.

NO -Repair an open or high resistance in the wire or poor ground (G901).

DTC B1077: Wiper Auto-Stop (As) Signal Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Turn the wiper switch to LOW or HIGH for at least 15 seconds, then turn the wiper switch OFF. NOTE: If the wiper motor does not run, go to step 13 . Do the wiper arms stop at AUTO STOP (park) position? YES -Go to step 4. NO -Go to step 5 .
4. Check for DTCs with the HDS. Is DTC B1077 indicated? YES -Check for loose or poor connections at the driver's MICU and the wiper motor. If the connections are OK, replace the driver's under-dash fuse/relay box, USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__special-tools-required) ). NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections.
5. Turn the ignition switch to LOCK (0).
6. Do the windshield wiper motor test (see «WIPER MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ). Is the windshield wiper motor OK? YES -Go to step 7. NO -Replace the wiper motor (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ) and recheck.
7. Disconnect the windshield wiper motor 4P connector.
8. Disconnect driver's under-dash fuse/relay box connector F (33P).
9. Check for continuity between windshield wiper motor 4P connector terminal No. 3 and driver's under-dash fuse/relay box connector F (33P) terminal No. 9. Is there continuity? YES -Go to step 10. NO -Repair an open or high resistance in the wire.
10. Check for continuity between windshield wiper motor 4P connector terminal No. 3 and body ground. WINDSHIELD WIPER MOTOR 4P CONNECTOR Is there continuity? YES -Repair a short to ground in the wire. NO -Go to step 11.
11. Turn the ignition switch to ON (II).
12. Measure the voltage between windshield wiper motor 4P connector terminal No. 3 and body ground. WINDSHIELD WIPER MOTOR 4P CONNECTOR Is there voltage? YES -Repair a short to power in the wire. NO -Faulty driver's MICU; replace the driver's under-dash fuse/relay box, USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__special-tools-required) ).
13. Turn the ignition switch to LOCK (0).
14. Measure the voltage between under-hood fuse/relay box connector B (14P) terminal No. 3 and body ground. UNDER-HOOD FUSE/RELAY BOX CONNECTOR B (14P) Is there battery voltage? YES -Go to step 16. NO -Go to step 15.
15. Check the No. 3-8 (WIP MTR) (30 A) fuse in the under-hood fuse/relay box. Is the fuse OK? YES -Repair an open or high resistance in the N0. 3-8 (WIP MTR) (30 A) fuse circuit. • NO -Replace the fuse. If the fuse blows again, repair a short to ground on the No. 3-8 (WIP MTR) (30 A) fuse circuit.
16. Do the relay circuit board test (see «RELAY CIRCUIT BOARD TEST»(/acura/tsx/ii-2008-2014/remont/body-electrical/#relays-4-cyl__relay-circuit-board-test) ). Is the relay board OK? YES -Go to step 17. NO -Replace the relay circuit board, and recheck.
17. Disconnect under-hood fuse/relay connector B (14P).
18. Check for continuity between under-hood fuse/relay box connector B (14P) terminal No. 4 and body ground. UNDER-HOOD FUSE/RELAY BOX CONNECTOR B (14P) Is there continuity? YES -Go to step 19. NO -Repair an open or high resistance in the ground wire or poor ground (G301).
19. Do the windshield wiper motor test (see «WIPER MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ). Is the windshield wiper motor OK? YES -Go to step 20. NO -Replace the windshield wiper motor (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ), and recheck.
20. Reconnect under-hood relay/fuse connector B (14P).
21. Turn the ignition switch to ON (II).
22. Measure the voltage between body ground and windshield wiper motor 4P connector terminal No. 2 with the wiper switch ON (Low), and measure the voltage between body ground and windshield wiper motor 4P connector terminal No. 4 with the wiper switch ON (high) individually. WINDSHIELD WIPER MOTOR 4P CONNECTOR Is There Battery Voltage? YES -Repair an open or high resistance in the wire(s) between the windshield wiper motor and body ground. If the wire(s) are OK, check for poor ground (G3202). • NO -Go to step 23.
23. Measure the voltage between body ground and under-hood fuse/relay box connector B (14P) terminal No. 5 with the wiper switch ON (Low), and measure the voltage between body ground and under-hood fuse/relay box connector B (14P) terminal No. 6 with the wiper switch ON (High) individually. UNDER-HOOD FUSE/RELAY BOX CONNECTOR B (14P) Is there battery voltage? YES -Repair an open or high resistance in the BLU (LO) or YEL (HI) wire(s). • NO -Check terminal F7 and F8 of the driver's under-dash fuse/relay box connector F (33P) using the input test (see «MICU INPUT TEST»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl__micu-input-test) ). If the input tests prove OK, replace the driver's under-dash fuse/relay box (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ).

DTC B1281: Front Wiper MIST Position Circuit Malfunction; DTC B1282: Front Wiper INT Position Circuit Malfunction; DTC B1283: Front Wiper LOW Position Circuit Malfunction; DTC B1284: Front Wiper HIGH Position Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 62

Scheme 63

1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Turn the wiper switch to the MIST, INT, LOW, HIGH, and OFF positions, and wait for at least 6 seconds.
4. Check for DTCs with the HDS. Is DTC B1281, B1282, B1283, or B1284 indicated? YES -Go to step 5. NO -Intermittent failure, the wiper system is OK at this time. Check for loose or poor connections.
5. Select WIPER from the BODY ELECTRICAL SYSTEM SELECT menu, and enter DATA LIST.
6. Check each wiper switch position value with the DATA LIST menu. When the wiper switch is turned OFF WIPER SWITCH REFERENCE CHART Data List Value Wiper switch (LOW) OFF Wiper switch (HIGH) OFF Wiper switch (MIST) OFF Wiper switch (INT) OFF Are all data list values correct? YES -Go to step 7. NO -Go to step 10 .
7. Turn the ignition switch to LOCK (0).
8. Disconnect driver's under-dash fuse/relay box connector R (24P).
9. Check for continuity between driver's under-dash fuse/relay box connector R (24P) terminals as shown: CONNECTOR TERMINALS REFERENCE CHART From terminal To terminal 15 (ORN) 1 (BLU) 16 (WHT) 17 (GRN) 17 (GRN) 1 (BLU) 16 (WHT) Is there continuity? YES -Repair a short between the wires. NO -Faulty driver's MICU; replace the driver's under-dash fuse/relay box, USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__special-tools-required) ).
10. Turn the ignition switch to LOCK (0).
11. Disconnect the 8P connector from the wiper switch.
12. Turn the ignition switch to ON (II).
13. Check each wiper switch position value with the DATA LIST menu. DATA LIST Data List Value Wiper switch (LOW) OFF Wiper switch (HIGH) OFF Wiper switch (MIST) OFF Wiper switch (INT) OFF Are all data list values correct? YES -Replace the wiper/washer switch (see «WIPER/WASHER SWITCH TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ). NO -Go to step 14.
14. Turn the ignition switch to LOCK (0).
15. Disconnect driver's under-dash fuse/relay box connector R (24P).
16. Check for continuity between body ground and driver's under-dash fuse/relay box connector R (24P) terminals No. 15, No. 16, and No. 17 individually. DRIVERS UNDER-DASH FUSE/RELAY BOX CONNECTOR R (24P) Is there continuity? YES -Repair a short to ground in the wire. NO -Go to step 17.
17. Check for continuity between driver's under-dash fuse/relay box connector R (24P) terminal No. 4 and terminals No. 15, No. 16, and No. 17 respectively. DRIVER'S UNDER-DASH FUSE/RELAY BOX CONNECTOR R (24P) Is there continuity? YES -Repair a short between the wires. NO -Faulty driver's MICU; replace the driver's under-dash fuse/relay box, USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__special-tools-required) ).

MICU Input Test

Note. Before testing, troubleshoot the multiplex integrated control system first, using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Driver's MICU

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Turn the ignition switch to LOCK (0).
2. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-undercover-removalinstallation) ), then remove the dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-lower-cover-removalinstallation) ).
3. Disconnect driver's under-dash fuse/relay box connectors F, Q, and R. NOTE: All connector views are wire side of female terminals. CONNECTOR F (33P) CONNECTOR Q (20P) CONNECTOR R (24P) *:A/T
4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
5. With the connectors still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 6. INPUT TESTS REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained F7 F30 ORN YEL Under all conditions Connect terminals F16 and F30, and terminal F7 to body ground: The windshield wiper motor should run at high speed. Blown No. 3-8 (WIP MTR) (30 A) fuse in the under-hood fuse/relay box Faulty relay circuit board Faulty windshield wiper motor Poor ground (G301, G302) An open or high resistance in the wire F8 YEL/BLU Run the windshield wiper motor by connecting terminals F16 and F30, and terminal F7 to body ground. Connect terminal F8 to body ground: The windshield wiper motor speed should change from high speed to low speed. Faulty under-hood fuse/relay box Faulty relay circuit board Faulty windshield wiper motor An open or high resistance in the wire F9 WHT Run the windshield wiper motor by connecting terminals F16 and F30, and terminal F7 to body ground. Check for continuity to ground: The needle of the ohmmeter should pulse. NOTE: Use an ohmmeter. Faulty windshield wiper motor An open or high resistance in the wire
6. Reconnect the connectors to the driver's under-dash fuse/relay box, turn the ignition switch to ON (II), and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7. INPUT TESTS REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained Q1 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G502) An open or high resistance in the ground wire Q2 BRN Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G501) An open or high resistance in the ground wire R2 BRN Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G501) An open or high resistance in the ground wire R5 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G502) An open or high resistance in the ground wire F4 (A/T) GRN Transmission range switch in P Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G101) or an open in the ground wire Faulty transmission range switch An open or high resistance in the wire Transmission range switch in any other position than P Measure the voltage to ground: There should be about 5 V. A short to ground in the wire F20 LT GRN Brake pedal pressed Measure the voltage to ground: There should be battery voltage. Blown No. 12 (15 A) fuse in the under-hood fuse/relay box Faulty brake pedal position switch An open or high resistance in the wire Brake pedal released Measure the voltage to ground: There should be no voltage. Faulty brake pedal position switch A short to power in the wire R15 R4 ORN BLK Wiper switch (INT or LO) ON Measure the voltage between terminals R15 and the R4: There should be less than 0.2 V. Faulty wiper/washer switch An open or high resistance in the wire Wiper switch OFF Measure the voltage between terminals R15 and the R4: There should be about 5 V. Faulty wiper/washer switch A short to ground in the wire R16 R4 WHT BLK Wiper switch (LO or HI) ON Measure the voltage between terminals R16 and the R4: There should be less than 0.2 V. Faulty wiper/washer switch An open or high resistance in the wire Wiper switch OFF Measure the voltage between terminals R16 and the R4: There should be about 5 V. Faulty wiper/washer switch A short to ground in the wire R17 R4 GRN BLK Wiper switch (MIST) ON Measure the voltage between terminals R17 and the R4: There should be less than 0.2 V. Faulty wiper/washer switch An open or high resistance in the wire Wiper switch OFF Measure the voltage between terminals R17 and the R4: There should be about 5 V. Faulty wiper/washer switch A short to ground in the wire R18 R4 YEL BLK Washer switch ON Measure the voltage between terminals R18 and the R4: There should be less than 0.2 V. Faulty wiper/washer switch An open or high resistance in the wire Washer switch OFF Measure the voltage between terminals R18 and the R4: There should be about 5 V. Faulty wiper/washer switch A short to ground in the wire Passenger's MICU
7. Turn the ignition switch to LOCK (0), and remove the passenger's kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-door-areas) ).
8. Disconnect passenger's under-dash fuse/relay box connectors A, E, and H. NOTE: All connector views are wire side of female terminals. CONNECTOR A (38P) CONNECTOR E (18P) CONNECTOR H (38P)
9. With the connectors still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 10. INPUT TESTS REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained E9 E18 GRN BLK Ignition switch ON (II) Connect terminals A31 and E9, and terminal E18 and body ground: The windshield washer motor should run. Faulty windshield washer motor An open or high resistance in the wire
10. Reconnect the connectors to the passenger's under-dash fuse/relay box, and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 11. INPUT TESTS REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained A31 PNK Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 3 (15 A) fuse in the driver's under-dash fuse/relay box Faulty driver's under-dash fuse/relay box An open or high resistance in the wire A35 BRN Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 5 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty driver's under-dash fuse/relay box An open or high resistance in the wire E16 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G201) An open or high resistance in the ground wire E15 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G201) An open or high resistance in the ground wire A36 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G505) An open or high resistance in the ground wire A37 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G505) An open or high resistance in the ground wire H21 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G651) An open or high resistance in the ground wire
11. If multiple failures are found on more than one control unit, replace the driver's under-dash fuse/relay box (includes the driver's MICU), USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-4-cyl__special-tools-required) ). If input failures are related to a particular control unit, replace the control unit.

Scheme 70

Scheme 71

Scheme 72

1. Remove the steering column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__column-cover-removalinstallation) ).
2. Disconnect the 8P connector (A) from the wiper/washer switch (B).
3. Remove the two screws, then slide out the wiper/washer switch.
4. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
5. Check for continuity between the terminals in each switch position according to the table. Windshield Rear Window (Sport Wagon)
6. If the continuity is not as specified, replace the switch.
7. Install the switch in the reverse order of removal.

Scheme 73

1. Remove the wiper arms (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).
2. Remove the left side cowl cover (see «COWL COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#exterior-trim-4-cyl__cowl-cover-replacement) ).
3. Disconnect the 4P connector (A) from the windshield wiper motor (B).
4. Test the motor by connecting battery power to terminal No. 2 and ground to terminal No. 1 of the wiper motor 4P connector. The motor should run at low speed.
5. Test the motor by connecting battery power to terminal No. 4 and ground to terminal No. 1 of the wiper motor 4P connector. The motor should run at high speed.
6. Connect an analog ohmmeter to the terminals No. 3 and No. 1, and run the motor at low or high speed. The needle of the ohmmeter should pulse.
7. If the motor does not run or fails to run smoothly, or there is no pulse, replace the motor (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).

Scheme 74

1. Open the tailgate, and remove the tailgate lower trim panel (see «REAR FLOOR LID HANDLE»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ).
2. Disconnect the 4P connector (A) from the rear window wiper motor (B).
3. Test the motor by connecting battery power to the rear window wiper motor 4P connector No. 1 terminal and ground to the No. 3 terminal. The motor should run. If the motor does not run or fails to run smoothly, replace the motor (see «REAR WINDOW WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).
4. Connect an analog ohmmeter between the rear window wiper motor 4P connector No. 2 and No. 3 terminals. The ohmmeter should indicate continuity and no continuity alternately while the motor is running. If it does not, replace the motor (see «REAR WINDOW WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).

Scheme 75

Scheme 76

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ).
2. Disconnect the 2P connector (A) from the windshield/rear window* washer motor (B). *: Sport Wagon USA models Canada models
3. Test the motor by connecting battery power to terminal No. 2 (or No. 1)* and ground to terminal No. 1 (or No. 2)* of the washer motor. The motor should run.

*: Rear window washer motor operation.

1. If the motor does not run or fails to run smoothly, replace the motor (see «REAR WINDOW WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).
2. If the motor runs smoothly, but little or no washer fluid is pumped, check for a disconnected or blocked washer hose, or a clogged washer motor outlet.

Scheme 77

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ).
2. Disconnect the 2P connector (A) from the washer fluid level switch (B).
3. Remove the washer fluid level switch from the washer reservoir. NOTE: Fluid may flow out of the opening.
4. Check for continuity between terminals No. 1 and No. 2 in each float position. There should be continuity when the float is down. There should be no continuity when the float is up.
5. If the continuity is not as specified, replace the switch (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. Open the hood. Remove the cap (A) and nuts (B).
2. Close the hood, then spread protective cloths (A) on the hood to avoid scratching the hood edge.
3. Raise the wiper arms (B) off the windshield, then remove the wiper arms.
4. Remove the hood seal and cowl covers (A).
5. Disconnect the harness clip (A) and 4P connector (B) from the windshield wiper motor.
6. Remove the four bolts and wiper linkage assembly (C).
7. Separate the linkage (A) from the link (B).
8. Note the alignment marks (C), then remove the nut (D) and the link from the wiper motor (E).
9. Remove the three bolts, and separate the wiper motor from the linkage (F).
10. Before installing the motor, connect the 4P connector to the wiper motor, and turn the wiper/washer switch ON to (LO) or (HI) position, then OFF to return the motor shaft to the park position. NOTE: Do not use the wiper/washer switch (INT) position in this step. If necessary, replace any damaged clips. Apply multipurpose grease to the moving parts.
11. Install the wiper motor to the wiper linkage assembly in the reverse order of removal.
12. Install the link to the wiper motor shaft, then align the mark (A) of the link and the mark (B) of the wiper linkage assembly.
13. After installation, adjust the wiper arms (see «WIPER ARM/NOZZLE ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).

Scheme 84

Scheme 85

1. Open the tailgate, and remove the tailgate lower trim panel (see «REAR FLOOR LID HANDLE»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ).
2. Remove the mounting nut (A), the wiper arm (B) and the special nut (C).
3. Disconnect the 4P connector (A) and remove the three mounting bolts (B), then remove the rear window wiper motor (C).
4. Install in the reverse order of removal.

Scheme 86

Scheme 87

Scheme 88

1. Remove the front section of right front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ).
2. Disconnect the 2P connector(s) (A) from the windshield washer motor (B). Washer Reservoir Capacity: 2.5 L (2.64 US qt) Sedan Sport Wagon
3. Disconnect the washer tube (C), then if necessary, remove the washer motor. NOTE: Fluid may flow out of the opening.
4. Remove the clip (A) and three bolts from the washer reservoir (B).
5. Install the washer reservoir in the reverse order of removal. Check the washer motor operation.

Scheme 89

Scheme 90

1. Remove the front section of right front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ).
2. Disconnect the 2P connector(s) (A) from the windshield washer motor (B) and the washer fluid level switch (C). Washer Reservoir Capacity: 4.5 L (4.75 US qt)
3. Disconnect the washer tube (D), then remove the washer motor and the washer fluid level switch. NOTE: Fluid may flow out of the opening.
4. Remove the clip (A) and three bolts from the washer reservoir (B).
5. Install the washer reservoir in the reverse order of removal. Check the washer motor operation.

Scheme 91

1. Lift the wiper arms off the windshield.
2. Pull up and hold the tab (A), and slide the wiper blade assembly (B) toward the tabs until it releases from the wiper arm (C).
3. Pull back the end of the old blade (A) and slide out the it of the blade holder (B).

Scheme 92

Scheme 93

Scheme 94

1. Align the groove (A) of the each rail (B) and a new blade (C).
2. Install the new blade with the rails into the blade holder in the reverse order of removal.
3. Install the wiper blade assemblies onto the wiper arms in the reverse order of removal.
4. Test the wipers by turning the wiper switch on. If the blades slip, turn the wiper switch off and seat the wiper blade securely.

Scheme 95

Scheme 96

1. Lift the wiper arm from the rear window.
2. Turn the rear window wiper blade (A); release the lock, and then remove the wiper blade from the rear window wiper arm (B).
3. Raise the old blade (A), and remove it from the wiper assembly (B).
4. Install the new blade on the wiper blade assembly, and install in the reverse order of removal. NOTE: After installation, confirm that the wiper arm works smoothly.

Windshield

Note. When you adjust the washer nozzles, carefully move the outside of the washer nozzles (A). Do not insert tools into the nozzle hole (B) as it may cause the washer fluid to spray incorrectly.

Wiper Arms Park Position

Scheme 97

1. Turn the ignition switch to ON (II), then turn the wiper switch ON, and then OFF.
2. When the wiper arms stop at the park position, confirm that they are at the standard position. Position at about 1.9 in (48 mm) from the top of cowl cover (A). Position at about 1.3 in (33.2 mm) from the top of cowl cover (A). Washer Nozzle Position When you turn on the washer(s), confirm 50 % or more of the washer fluid lands within the spray area. If the spray area is not within the standard positions, adjust the nozzle(s).
3. d: Position at about 6.5 in (166 mm) from the top of the black ceramic area (B) at the lower windshield.
4. e: Position at about 15 in (380 mm) from the top of the black ceramic area (B) at the lower windshield.
5. f: Position at about 9.8 in (250 mm) from the windshield center line (C).

Rear Window

Wiper Arm Park Position

Scheme 98

1. When the wiper arm stops at the automatic stop position, confirm that it is at the standard position. a: Position on the black ceramic (A) at windshield. Washer Nozzle Position When you turn on the washers, confirm 50 % or more of the washer fluid lands within the spray area. If the spray area is not within the standard positions, adjust the nozzle. b: Position at 0.8 in (21.1 mm) from the rear washer nozzle (B).

Scheme 99

Scheme 100

Scheme 101

1. Remove the right front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) )
2. Remove the wiper arms (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/wiperwasher-systems/#wiperswashers-4-cyl) ).
3. Remove the cowl cover (see «COWL COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#exterior-trim-4-cyl__cowl-cover-replacement) ).
4. Remove the windshield washer nozzles and clips, then remove the tubes. Sedan Sport Wagon
5. Install the parts in the reverse order of removal. Take care not pinch the washer tubes. Check the washer for correct operation.

See also:
• TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A
• INSTALLATION
• DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION
• SPECIAL TOOLS REQUIRED
• RELAY CIRCUIT BOARD TEST
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• COLUMN COVER REMOVAL/INSTALLATION
• COWL COVER REPLACEMENT
• REAR FLOOR LID HANDLE
• FRONT INNER FENDER REPLACEMENT
• WIPER MOTOR TEST
• MICU INPUT TEST
