Seat Belts (v6) Acura TSX II

Restraints Control Systems 22 illustrations ~1467 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Front Seat Belt

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If replacing the front seat belt after deployment, refer to the component replacement/inspection after deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ) for a complete list of other parts that must also be replaced. Put on gloves to protect your hands. Check the front seat belts for damage (see INSPECTION ), and replace them if necessary. Be careful not to damage them during removal and installation. Take care not to tear or damage the seat covers. The driver's seat is shown; the passenger's seat is similar.

Scheme 2

Scheme 2: Front Seat Belt
Scheme 2: Front Seat Belt

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Slide the front seat all the way forward. Carefully pry up on the bottom of the anchor cover (A) at the pry point (B) with the appropriate trim tool to release the hooks (C) and the tab (D), then remove the cover by pulling it upward.
  2. Remove the lower anchor bolt (A).
  3. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
  4. Remove the B-pillar upper/lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
  5. Remove the upper anchor bolt (A).
  6. Disconnect the seat belt tensioner connector (A). Remove the upper retractor mounting bolt (B) and the lower retractor bolt (C), then remove the front seat belt (D) and the retractor (E).
  7. Remove the shoulder anchor adjuster (A).
  8. Install the seat belt and the retractor in the reverse order of removal, and note these items: Apply medium strength liquid thread lock to the upper anchor bolt and the retractor bolts before reinstallation. Check that the retractor locking mechanism functions (see «INSPECTION»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ). Assemble the washer, the collars, and the bushing on the upper anchor bolt and the retractor bolt as shown. Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt. Make sure the seat belt tensioner connector is plugged in properly. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ). Upper anchor bolt installation Retractor bolt installation

Front Seat Belt Buckle

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers.

Scheme 9

Scheme 9: Front Seat Belt Buckle
Scheme 9: Front Seat Belt Buckle

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
  2. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
  3. Lift up the front seat, detach and disconnect the seat belt buckle switch connector (A). On the driver's seat, detach the harness clips (6). Driver's seat Passenger's seat
  4. Release the hook strip (A), and pull back the seat cushion cover (passenger's seat). Remove the center anchor bolt (B), and detach the harness clip(s) (C), then remove the seat belt buckle (D). Driver's seat Passenger's seat
  5. Pull the seat belt buckle switch harness (E) out through the space between the seat cushion and the seat track (driver's seat), or through the hole in the seat track (passenger's seat).
  6. Install the buckle in the reverse order of removal, and note these items: Assemble the washers and the collar on the center anchor bolt as shown. Before installing the center anchor bolt, make sure there are no twists or kinks in the front seat belt. Apply medium strength liquid thread lock to the center anchor bolt before reinstallation. Make sure the seat belt buckle switch connector is plugged in properly. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ). Center anchor bolt installation

Rear Seat Belt Replacement

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. Check the front seat belts for damage (see INSPECTION ), and replace them if necessary. Be careful not to damage them during removal and installation.

Scheme 14

Scheme 14: Rear Seat Belt
Scheme 14: Rear Seat Belt

Scheme 15

Scheme 15
Scheme 15
  1. Remove the rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-cushion) ).
  2. Remove the lower anchor bolt (A).
  3. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-rear-shelf-area) ).
  4. Remove the retractor mounting bolt (A) and the retractor bolt (B), then remove the rear seat belt (C) and the retractor (D).
  5. Install the seat belt and the retractor in the reverse order of removal, and note these items: Check that the retractor locking mechanism functions (see «INSPECTION»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ). Before installing the anchor bolt, make sure there are no twists or kinks in the rear seat belt. Apply medium strength liquid thread lock to the anchor bolts before reinstallation.

Rear Center Seat Belt and Seat Belt Buckles

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. Check the rear center seat belt for damage (see Inspection ), and replace them if necessary. Be careful not to damage them during removal and installation.

Scheme 16

Scheme 16: Rear Center Seat Belt and Seat Belt Buckles
Scheme 16: Rear Center Seat Belt and Seat Belt Buckles

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Remove the rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-cushion) ).
  2. Remove the center anchor bolts (A), then remove the right seat belt buckle (B), the center seat belt buckle (C), and the left seat belt buckle (D).
  3. Fold down the rear seat-back.
  4. Pull out the center seat belt through the slit in the seat belt guide.
  5. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-rear-shelf-area) ).
  6. Remove the retractor mounting bolt (A) and the retractor bolt (B), then remove the center seat belt (C) and the retractor (D).
  7. Remove the rear center seat belt protector (E).
  8. Install the seat belt and the buckles in the reverse order of removal, and note these items: Check that the retractor locking mechanism functions (see «INSPECTION»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ). Assemble the washer on the center anchor bolt as shown. Apply medium strength liquid thread lock to the center anchor bolts before reinstallation. Before installing the center anchor bolt, make sure there are no twists or kinks in the center seat belt. Tighten the bolts to the specified torque. Make sure the rear center ELR (emergency locking retractor) is pointing straightforward. Center anchor bolt installation

Out of Vehicle

For front seat belt retractors with seat belt tensioners, review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 19

Scheme 19: Retractor
Scheme 19: Retractor

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Before installing the retractor, check that the seat belt can be pulled out freely.
  2. Make sure that the seat belt does not lock when the retractor (A) is leaned slowly up to 15° from the mounted position. The seat belt should lock when the retractor is leaned over 40°. Do not attempt to disassemble the retractor. Driver's side Passenger's side Rear Rear center
  3. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.

In-Vehicle

  1. Check that the seat belt is not twisted or caught on anything.
  2. After installing the anchors, check for free movement on the anchor bolts. If necessary, remove the anchor bolts and check that the washers and other parts are not damaged or improperly installed.
  3. Check the seat belts for damage or discoloration. Clean with a shop towel if necessary. Use only soap and water to clean the seat belt. NOTE: Dirt build-up in the loops of the upper anchors can cause the seat belts to retract slowly. Wipe the inside of the loops with a clean cloth dampened with isopropyl alcohol.
  4. Check that the seat belt does not lock when pulled out slowly. The seat belt is designed to lock only during a sudden stop or impact.
  5. Make sure that the seat belt will retract automatically when released.
  6. For each passenger's seat belt, check the seat belt retractor locking mechanism automatic locking retractor (ALR). This function is for securing child seats. Pull the seat belt all the way out to engage the ALR. The seat belt should retract, but not extend. This is normal. To disengage the ALR, release the seat belt and allow it to fully retract, then pull the seat belt out part-way. The seat belt should retract and extend normally.
  7. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.
