General Information (v6) Acura TSX II

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Paint Code

PAINT CODE REFERENCE CHART

Scheme 5

Scheme 6

Scheme 7

Danger/Warning/Caution Label Locations

Front Passenger's Compartment

Scheme 8

Steering Wheel

Scheme 9

Engine Compartment

Scheme 10

Doorjamb Area

Scheme 11

Emission Group Identification

Example

Scheme 12

'12 Model

CONFORMS TO REGULATIONS: 2012 MY

Test Group and Evaporative Family

Test Group

Scheme 13

Evaporative Family

Scheme 14

Lift and Support Points

Note. If you are going to remove heavy components such as suspension or the fuel tank from the rear of the vehicle, first support the front of the vehicle with tall safety stands. When substantial weight is removed from the rear of the vehicle, the center of gravity can change, causing the vehicle to tip forward on the lift.

Scheme 15

1. Position the lift pads (A) under the vehicle's front support points (B) and rear support points (C). NOTE: Be sure the lift pads are properly placed to avoid damaging the vehicle.
2. Raise the lift a few inches, and rock the vehicle gently to be sure it is firmly supported.
3. Raise the lift to its full height, and inspect the vehicle support points for solid contact with the lift pads.

Safety Stands

To support the vehicle on safety stands, use the same support points as for a vehicle lift. Always use safety stands when working on or under any vehicle that is supported only by a jack.

Scheme 16

1. When lifting the front of the vehicle, set the parking brake. When lifting the rear of the vehicle, put the shift lever in P.
2. Block the wheels that are not being lifted.
3. Position the floor jack under the front jacking bracket (A) or the rear jacking bracket (B). Center the jacking bracket on the jack lift platform (C), and jack up the vehicle high enough to fit the safety stands under it. NOTE: Be sure the floor jack is properly placed to avoid damaging the vehicle.
4. Position the safety stands under the support points, and adjust them so the vehicle is level side-to-side.
5. Lower the vehicle onto the stands.

Towing

If the vehicle needs to be towed, call a professional towing service. Never tow the vehicle behind another vehicle with just a rope or chain. It is very dangerous.

Emergency Towing

There are three popular methods of towing a vehicle.

Flat-bed Tow Truck Equipment - The operator loads the vehicle on the back of a flat-bed tow truck. This is the best way of transporting the vehicle.

To accommodate the flat-bed tow truck equipment, the vehicle is equipped with front towing hooks (A), front tie down hook slots (B), a rear towing hook (C), and rear tie down hook slots (D).

The towing hooks can be used with a winch to pull the vehicle onto the flat-bed tow truck, and the tie down hook slots can be used to secure the vehicle to the flatbed tow truck.

Scheme 17

Scheme 18

Wheel Lift Equipment - The tow truck uses two pivoting arms that go under the tires (front or rear) and lifts them off the ground. The other two wheels remain on the ground. This is an acceptable way of towing the vehicle.

Sling-type Equipment - The tow truck uses metal cables with hooks on the ends. These hooks go around parts of the frame or suspension, and the cables lift that end of the vehicle off the ground. The vehicle's suspension and body can be seriously damaged if this method of towing is attempted. This method of towing the vehicle is unacceptable.

If the vehicle cannot be transported by a flat-bed tow truck, it should be towed with the front wheels off the ground. If the vehicle is damaged, and must be towed with the front wheels on the ground, or if the vehicle is towed with all four wheels on the ground, do this

1. Release the parking brake.
2. Start the engine.
3. Shift to D, then to N.
4. Turn off the engine.
5. Leave the ignition switch in ACCESSORY (I) so the steering wheel does not lock.
6. Make sure all accessories are turned off to minimize battery current draw.

It is best to tow the vehicle no farther than 50 miles (80 km), and keep the vehicle speed below 35 mph (55 km/h).

Note. Improper towing preparation will damage the transmission. Follow the above procedure exactly. If you cannot shift the transmission or start the engine, the vehicle must be transported on a flat-bed tow truck. Trying to lift or tow the vehicle by the bumpers will cause serious damage. The bumpers are not designed to support the vehicle's weight.

Parts Marking

To deter vehicle theft, certain major components are marked with the vehicle identification number (VIN). Original parts have self-adhesive labels. Replacement body parts have generic self-adhesive labels. These labels should not be removed. The original engine or transmission VIN plates are not transferable to the replacement engine or transmission.

Note. Be careful not to damage the parts marking labels during body repair. Mask the labels before repairing the part.
