Power Mirrors (v6) Acura TSX II

Mirrors 15 illustrations ~2578 words

Scheme 11

Scheme 11: Component Location Index
Scheme 11: Component Location Index

Power Mirror Defogger Auto Operation Function

When the outside air temperature is 41 °F (5 °C) or below and the ignition switch is turned to ON (II), the left and right power mirror defoggers automatically turn on. The power mirror defogger auto operation function is controlled by the door multiplex control unit.

Scheme 12

Scheme 12: Power Mirror Defogger Auto Operation Function
Scheme 12: Power Mirror Defogger Auto Operation Function
  1. When the door multiplex control unit receives a signal that the outside air temperature is 41 °F (5 °C) or below from the climate control unit, the door multiplex control unit automatically turns on the left and right power mirror defoggers within 10 seconds after the ignition switch is turned to ON (II).
  2. Power mirror defogger output automatically stops in 10 minutes as a result of its timer.
  3. If the door multiplex control unit receives a rear window defogger/power mirror defogger switch input signal from the climate control unit during power mirror defogger output, the door multiplex control unit shuts off the auto operation function immediately.
  4. While the power mirror defogger auto operation function is operating, the rear window defogger does not automatically operate.
  5. The power mirror defogger auto operation function stops temporarily when any power window is operated during power mirror defogger output. (Scheme 12): Power Mirror System Diagram

Scheme 13

Scheme 13: Circuit Diagram
Scheme 13: Circuit Diagram

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Function Test

Note. The right power mirror actuator is controlled by the front passenger's power window switch. When the power mirror switch is operated, the power window master switch receives the signals from the power window master switch and send them to the front passenger's power window switch. So if there is malfunction of the right power mirror actuator operation, do the door multiplex control unit input test (see POWER WINDOW MASTER SWITCH INPUT TEST ) and front passenger's power window switch input test (see FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST ). Also, the power mirror defoggers, position sensor and retractable power mirrors are controlled by door multiplex control unit and front passenger's power window switch, do the door multiplex control unit input test (see FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST ) and front passenger's power window switch input test (see FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST ).

Scheme 16

Scheme 16: Left Power Mirror Function Test
Scheme 16: Left Power Mirror Function Test
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-v6__front-door-panel-removalinstallation) ).
  2. Disconnect the 20P connector (A) from the driver's door subharness.
  3. Turn the ignition switch to ON (II).
  4. Measure the voltage between body ground and terminal No. 3 of the driver's door subharness 20P connector with the ignition switch to ON (II). There should be battery voltage. If there is no voltage, check for: Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box. An open or high resistance in the LT GRN wire. If there is battery voltage, go to step 5 .
  5. Check for continuity between terminal No. 1 of the driver's door subharness 20P connector and body ground. There should be continuity. If there is no continuity, check for: An open or high resistance in the BLK wire. Poor ground (G501). If there is continuity, go to step 6 .
  6. Connect terminals No. 3 and No. 14, and terminals No. 15 (or No. 4) and No. 1 with jumper wires. The left mirror should tilt down (or swing left) with the ignition switch to ON (II). If the left mirror does not tilt down (or does not swing left), check for an open in the GRY (or YEL) wire between the left mirror and the 20P connector. If the wire is OK, check the left mirror actuator. If the mirror neither tilts down nor swings left, repair the PUR wire. If the mirror works properly, check the power mirror switch.

Power Window Master Switch Input Test

Note. Before testing, troubleshoot the multiplex integrated control unit first, using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 17

Scheme 17: Power Window Master Switch Input Test
Scheme 17: Power Window Master Switch Input Test
  1. Turn the ignition switch to LOCK (0).
  2. Carefully remove the power window master switch (see «POWER WINDOW MASTER SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6) ).
  3. Disconnect the 37P connector (A) from the power window master switch (B).
  4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5 .
  5. Reconnect the connector to the power window master switch.
  6. Turn the ignition switch to ON (II), and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7 . WIRE TEST CONDITION CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 14 LT GRN Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire 32 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G501) An open in the ground wire 37 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G502) An open in the ground wire
  7. Turn the ignition switch to LOCK (0).
  8. Open and close the driver's door, then disconnect the 37P connector from the power window master switch again.
  9. With the connector still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the power window master switch must be faulty, replace switch (see «POWER WINDOW MASTER SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6) ). NOTE: After replacing the power window master switch, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6__resetting-the-power-window-control-unit) ). WIRE TEST CONDITION CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 9 WHT Ignition switch ON (II), power mirror switch in RIGHT mirror position Measure the voltage to ground: There should be battery voltage when the power mirror switch LEFT or DOWN is pressed. Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 10 RED Ignition switch ON (II), power mirror switch in RIGHT mirror position Measure the voltage to ground: There should be battery voltage when the power mirror switch RIGHT or DOWN is pressed. Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 11 GRY Ignition switch ON (II), power mirror switch in RIGHT mirror position Measure the voltage to ground: There should be battery voltage when the power mirror switch UP or LEFT is pressed. Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 1 ORN Ignition switch ON (II), connect terminals No. 14 and No. 1 with a jumper wire Check the left power mirror defogger operation: The left power mirror defogger should work (the inside lower edge becomes warm). Faulty left power mirror defogger Poor ground (G501) or an open in the ground wire An open or high resistance in the wire 26 PNK Ignition switch ON (II), connect terminals No. 14 and No. 26 with a jumper wire Check the power mirror switch light operation: The power mirror switch light should come on. Faulty LED Faulty power mirror switch Poor ground (G501) or an open in the ground wire An open or high resistance in the wire 27 BLU Disconnect the front passenger's power window switch 37P connector and the moonroof control unit/motor 14P connector Check for continuity between terminal No. 27 and front passenger's power window switch 37P connector terminal No. 29: There should be continuity. An open in the UART wire Check for continuity between terminal No. 27 and moonroof control unit/motor 14P connector terminal No. 11: There should be continuity. An open in the UART wire Check for continuity to ground: There should be no continuity. A short to ground in the UART wire

Scheme 18

Scheme 18: Front Passenger's Power Window Switch Input Test
Scheme 18: Front Passenger's Power Window Switch Input Test
  1. Turn the ignition switch to LOCK (0).
  2. Carefully remove the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6) ).
  3. Disconnect the 37P connector (A) from the front passenger's power window switch (B).
  4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5 .
  5. Reconnect the connector to the front passenger's power window switch.
  6. Turn the ignition switch to ON (II), and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7 . WIRE TEST CONDITION CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 25 GRN Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 13 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty driver's under-dash fuse/relay box Faulty passenger's under-dash fuse/relay box An open or high resistance in the wire 37 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G505) An open or high resistance in the ground wire 30 YEL Ignition switch ON (II) Measure the voltage to ground: There should be about 5 V. Faulty position sensor. An open or high resistance in the wire 31 GRN Ignition switch ON (II), and move the mirror from full left to full right Measure the voltage to ground: The voltage should vary from about 0.5 V to 4.5 V. Faulty position sensor A short to ground in the wire 32 LT GRN Ignition switch ON (II), and move the mirror from full up to full down Measure the voltage to ground: The voltage should vary from about 0.5 V to 4.5 V. Faulty position sensor An open or high resistance in the wire 35 BRN Ignition switch ON (II) Measure the voltage to ground: There should be about less than 0.2 V. Faulty position sensor Poor ground (G505) An open or high resistance in the wire
  7. Turn the ignition switch to LOCK (0).
  8. Open and close the driver's door, then disconnect the 37P connector from the front passenger's power window switch again.
  9. With the connector still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, replace the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6) ). NOTE: After replacing the front passenger's power window switch, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-v6__resetting-the-power-window-control-unit) ). WIRE TEST CONDITION CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 . 4 LT BLU . PNK Connect terminals No. 25 and No. 3 (or No. 4), and terminals No. 4 (or No. 3) and No. 37 with jumper wires. Check the right power mirror operation: The right power mirror should move UP (or DOWN). Faulty right power mirror Poor ground (G505) or an open in the ground wire An open or high resistance in the wire 4 . 5 PNK . RED Connect terminals No. 25 and No. 4 (or No. 5), and terminals No. 5 (or No. 4) and No. 37 with jumper wires. Check the right power mirror operation: The right power mirror should move LEFT (or RIGHT). Faulty right power mirror Poor ground (G505) or an open in the ground wire An open or high resistance in the wire 1 ORN Connect terminals No. 25 and No. 1 with a jumper wire Check the right power mirror defogger operation: The right power mirror defogger should work (the inside lower edge becomes warm). Faulty right power mirror defogger Poor ground (G505) or an open in the ground wire An open or high resistance in the wire 29 BLU Under all conditions, disconnect the power window master switch 37P connector Check for continuity between terminal No. 29 and power window master switch 37P connector terminal No. 27: There should be continuity. An open in the UART wire

Scheme 19

Scheme 19: Power Mirror Actuator Test
Scheme 19: Power Mirror Actuator Test

Scheme 20

Scheme 20
Scheme 20
  1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-v6__front-door-panel-removalinstallation) ).
  2. Disconnect the 13P connector (A) from the power mirror (B).
  3. At the 13P connector, check the actuator operation by connecting power and ground according to the table. Power Mirror Actuator
  4. If the mirror fails to work properly, check for an open in the wire between the connector and the mirror holder. If the wire is OK, replace the mirror actuator. Defogger Test
  5. Check for continuity between terminals No. 5 and No. 10 of the 13P connector. There should be continuity.
  6. If there is no continuity, check for an open in the wire between the connector and the mirror holder. If the wire is OK, replace the mirror holder (see «MIRROR HOLDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-v6__mirror-holder-replacement) ).

Scheme 21

Scheme 21: Power Mirror Switch Test/Replacement
Scheme 21: Power Mirror Switch Test/Replacement

Scheme 22

Scheme 22
Scheme 22
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-v6__front-door-panel-removalinstallation) ).
  2. Remove the armrest and switch panel from the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-v6__front-door-panel-removalinstallation) ).
  3. Disconnect the 13P connector (A) from the power mirror switch (B), then remove the two screws and power mirror switch.
  4. Check for continuity between the terminals in each switch position according to the table. Power Mirror Switch
  5. If the continuity is not as specified, remove the screws and replace the power mirror switch.
  6. Install the switch in the reverse order of removal.

Scheme 23

Scheme 23: Removal
Scheme 23: Removal
  1. Remove the mirror holder (see «MIRROR HOLDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-v6__mirror-holder-replacement) ).
  2. Remove the mirror from the door (see «POWER MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-v6__power-mirror-replacement) ).
  3. Disconnect the connector(s) from the power mirror.
  4. Record the power mirror 13P connector terminal locations and wire colors.
  5. Disassemble the power mirror 13P connector, and remove all terminals from it.
  6. Remove the gasket (A).
  7. Remove the screw and the harness clip (B).
  8. Remove the cover (C) and the screws, then separate the mirror housings (D) from the bracket.
  9. Remove the screws, and separate the brackets (E).
  10. Remove the side turn signal light (F), and disconnect the 2P connector from the light.
  11. Remove the screws, and disassemble the mirror housing, then remove the mirror actuator (G).

Scheme 24

Scheme 24: Installation
Scheme 24: Installation

Scheme 25

Scheme 25
Scheme 25
  1. Route the new actuator's wire harness through the hole in the bracket.
  2. Reassemble the mirror in the reverse order of removal. Apply liquid thread lock to the screws (A) and tighten them to 4.4 N.m (0.45 kgf.m, 3.2 lbf.ft).
  3. Insert the new actuator terminals into the 13P connector in their original positions.
  4. Apply EPT sealer to the intersection of the wire harness and the 13P connector.
  5. Install the mirror holder. NOTE: Be careful not to break the mirror when reinstalling it to the actuator.
  6. Reinstall the mirror assembly on the door.
  7. Operate the power mirror to ensure correct operation.
