Openers (v6) Acura TSX II

Communication Devices 21 illustrations ~1218 words

Scheme 33

Scheme 33: Component Location Index
Scheme 33: Component Location Index

Hood Opener Cable Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts. Take care not to kink the hood opener cable.

Scheme 34

Scheme 34: Hood Opener Cable Replacement
Scheme 34: Hood Opener Cable Replacement

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Remove these items: Front grille cover (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#exterior-trim-v6__engine-compartment-cover-replacement) ) Front inner fender, driver's side, as needed (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-v6__front-inner-fender-replacement) ) Kick panel, driver's side (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-door-areas) ) Air intake cover (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#intake-air-system-v6) )
  2. Remove the bolts, and pull up the left radiator upper bracket (A) to release it from the radiator (B), then remove the bracket.
  3. Disconnect the hood opener cable (A) from the hood latch (B) (see «HOOD LATCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/communication-devices/#openers-v6__hood-latch-replacement) ).
  4. Detach the clips with a clip remover.
  5. Disconnect the hood opener cable (A) from the hood release handle (8) (see «HOOD RELEASE HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/communication-devices/#openers-v6__hood-release-handle-replacement) ).
  6. Remove the grommet (C) then remove the hood opener cable.
  7. Install the cable in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. When installing the opener cable under the dashboard, route the cable over the ground harness (D).

Trunk Lid Opener Cable Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts. Take care not to kink the trunk lid opener cable.

Scheme 37

Scheme 37: Trunk Lid Opener Cable Replacement
Scheme 37: Trunk Lid Opener Cable Replacement

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Remove these items: Rear bulkhead cover (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-rear-shelf-area) ) Trunk side trim panels, both sides (see «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__rear-parcel-shelf-dynamic-damper) ) Trunk lid hinge trim, right side (see «TRUNK LID HINGE TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trunk-lid-hinge-trim) )
  2. Disconnect the trunk lid opener cable from the trunk lid lock cylinder (see «TRUNK LID LOCK CYLINDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/communication-devices/#openers-v6__trunk-lid-lock-cylinder-replacement) ). Pull out the cable from the trunk compartment through the hole in the body.
  3. Detach the clips (A, B) fastening the trunk lid opener cable (C) with a clip remover.
  4. Remove the trunk lid opener cable (A) from the trunk lid. Disconnect the trunk lid opener cable from the trunk lid latch (B) (see «TRUNK LID LATCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/communication-devices/#openers-v6__trunk-lid-latch-replacement) ). Detach the clips (C, D).
  5. Install the opener cable in the reverse order of removal, and note these items: Replace any damaged clips. Align the marks (A) on the opener cable (B) with the cable clips (C) as shown.

Hood Latch Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts.

Scheme 40

Scheme 40: Hood Latch Replacement
Scheme 40: Hood Latch Replacement

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Remove the front grille cover (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#exterior-trim-v6__engine-compartment-cover-replacement) ).
  2. Remove the bolts, and detach the harness clips (A), then remove the hood latch cover (B).
  3. Remove the hood latch mounting bolts, then remove the hood latch (A). Disconnect the hood opener cable (B) from the hood latch.
  4. Disconnect the hood latch switch connector (C).
  5. Install the latch in the reverse order of removal, and note these items: Apply multipurpose grease to each location on the hood latch indicated by the arrows. Make sure the hood opener cable is connected properly and hood latch switch connector is plugged in properly. Adjust the hood latch alignment (see «HOOD ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#hood-v6) ). Make sure the hood opens properly and locks securely.

Hood Release Handle Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body. Take care not to kink the cable.

Scheme 43

Scheme 43: Hood Release Handle Replacement
Scheme 43: Hood Release Handle Replacement
  1. Remove the driver's kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-door-areas) ).
  2. Remove the bolts, then remove the hood release handle (A).
  3. Disconnect the hood opener cable (B) from the hood release handle.
  4. Install the hood release handle in the reverse order of removal, and note these items: Make sure the hood opener cable is connected properly. Make sure the hood opens properly.

Fuel Fill Door Actuator Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body.

Scheme 44

Scheme 44: Fuel Fill Door Actuator Replacement
Scheme 44: Fuel Fill Door Actuator Replacement

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Remove the left trunk side trim panel (see «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__rear-parcel-shelf-dynamic-damper) ).
  2. Disconnect the fuel fill door actuator connector (A).
  3. Loosen the bolts. Remove the fuel fill door actuator (A) by sliding it upward, and remove the rod (B) from the grommet (C).
  4. Install the actuator in the reverse order of removal, and note these items: Make sure the actuator connector is plugged in properly, and the rod is inserted to the grommet securely. Apply multipurpose grease to the rod (A) where it slides inside the grommet (B). Make sure the fuel fill door opens properly and locks securely.

Trunk Lid Lock Cylinder Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body. Take care not to kink the trunk lid opener cable.

Scheme 47

Scheme 47: Trunk Lid Lock Cylinder Replacement
Scheme 47: Trunk Lid Lock Cylinder Replacement

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-rear-shelf-area) ).
  2. Detach the cable fastener (A), and disconnect the trunk lid opener cable (B) from the trunk key cylinder bracket (C).
  3. Remove the bolts securing the bracket (A).
  4. Remove the bracket (A).
  5. Remove the bolt. Release the hook (A) by turning the trunk lid lock cylinder (B) 45°, then remove the cylinder from the bracket (C).
  6. Install the cylinder in reverse order of removal, and note these items: Replace the damaged cable fastener with a new one. Make sure the opener cable is connected properly. When installing the bracket, first tighten the inside mounting bolt, then tighten the outside mounting bolt. Make sure the trunk lid opens properly and locks securely.

Trunk Lid Latch Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to scratch the trunk lid. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to kink the cable.

Scheme 51

Scheme 51: Trunk Lid Latch Replacement
Scheme 51: Trunk Lid Latch Replacement

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
  1. Remove the trunk lid trim panel (see «REAR WHEELHOUSE INSULATOR»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__rear-wheelhouse-insulator) ).
  2. Insert a trim tool through the latch cover (A) opening, and pry on the cover to release the hooks (B). Pull out the cover, and release the tab (C) from the trunk lid latch (D), then remove the latch cover.
  3. Disconnect the trunk lid latch connector (E), and remove the bolts, then remove the latch.
  4. Disconnect the trunk lid opener cable (A).
  5. Install the latch in the reverse order of removal, and note these items: Make sure the connector is plugged in properly, and the opener cable is connected properly. Make sure the trunk lid opens properly and locks securely. Fix the original position of the outer end of cable (A) on the trunk lid latch securely. And check the trunk lid latch operation: Make sure the trunk lid latch unlock when turning the trunk lid cylinder with a key. If necessary, adjust the position of the cable end.
