Body Glass System — Acura TSX I (2003-2008)

Scheme 14

Scheme 14: Component Location Index

Windshield Replacement

Note. Put on gloves to protect your hands. Wear eye protection while cutting the glass adhesive with piano wire. Use seat covers to avoid damaging the seat. When replacing a broken windshield, a commercially available windshield cutter can be efficiently used for cutting the adhesive. For details, follow the instructions of the tool manufacturer.

Scheme 15

Scheme 15: Windshield Replacement

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Remove these items: Windshield wiper arms (see «WIPER MOTOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/wiperwasher-systems/#wiper-system-washer-system) ) Cowl covers (see «COWL COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim) ) Rearview mirror (see «REARVIEW MIRROR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/mirrors/#mirrors) ) A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Roof molding, both sides (see «ROOF MOLDING REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim__roof-molding-replacement) )
Remove the molding (A) from the upper edge of the windshield (B). If necessary, cut the molding with a utility knife.
If the old windshield is to be reinstalled, make alignment marks across the glass and body with a grease pencil.
Pull down the front portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ). Take care not to bend the headliner excessively, or you may crease or break it.
Apply protective tape along the edge of the dashboard and body. Using an awl, make a hole through the rubber dam and adhesive from inside the vehicle at the corner portion of the windshield. Push a piece of piano wire through the hole, and wrap each end around a piece of wood.
With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the windshield (B) as possible to prevent damage to the body and dashboard. Carefully cut through the rubber dam and adhesive (C) around the entire windshield. Cutting portions
Carefully remove the windshield.
With a knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire windshield opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the rubber dam and fasteners from the body. Replace the dashboard seal with a new one.
Clean the body bonding surface with a sponge dampened in isopropyl alcohol. After cleaning, keep oil, grease and water from getting on the clean surface.
If the old windshield is to be reinstalled, use a putty knife to scrape off all of the old adhesive, the fasteners and the rubber dam from the windshield. Clean the inside face and the edge of the windshield with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil and grease.
Attach the upper rubber dam (A), lower side rubber dam (B), and clips (C) with adhesive tape to the inside face of the windshield (D) as shown: Be sure the rubber dam and clips line up with the alignment marks (E). Be careful not to touch the windshield where adhesive will be applied. Rubber dams adhesive tape: Thickness 0.16 mm (0.006 in.) Width 3.5 mm (0.14 in.) Clips adhesive tape: Thickness 0.4 mm (0.016 in.) Width 10 mm (0.39 in.)
Attach the molding (A) with adhesive tape (B) to the upper edge of the windshield (C). Be careful not to touch the windshield where adhesive will be applied. Molding adhesive tape: Thickness 0.8 mm (0.03 in.) Width 4 mm (0.16 in.)
Apply primer to the molding (A), then attach the molding upper seal (B) with adhesive tape to the inside surface of the molding as shown. Seals adhesive tape: Thickness 0.16 mm (0.006 in.) Width 7 mm (0.28 in.)
Set the windshield in the opening, and center it. Make alignment marks (A) across the windshield and body with a grease pencil at the four points shown. Make sure both clips (B) contact with the edge of the body holes. Be careful not to touch the windshield where adhesive will be applied.
Remove the windshield.
With a sponge, apply a light coat of glass primer around the edge of the windshield (A) between the dams (B) and molding (C) as shown, then lightly wipe it off with gauze or cheesecloth: Apply glass primer to the molding. Do not apply body primer to the windshield, and do not get body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the windshield properly, causing a leak after the windshield is installed. Keep water, dust, and abrasive materials away from the primed surfaces.
With a sponge, carefully apply a light coat of body primer to any exposed paint or metal around the flange where new adhesive will be applied. Let the primer dry for at least 10 minutes: Do not apply body primer to any remaining original adhesive on the flange. Be careful not to mix up the body and glass primer sponges. Never touch the primed surfaces with your hands.
Cut a "V" in the end of the nozzle (A) on the adhesive cartridge as shown.
Put the cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the windshield (B) between the dams (C) and molding (D) as shown. Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
Use suction cups to hold the windshield over the opening, align it with the alignment marks made in step 14 , and set it down on the adhesive. Lightly push on the windshield until its edges are fully seated on the adhesive all the way around. NOTE: Do not open or close any of the doors for about an hour until the adhesive is dry.
Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the windshield, wipe with a soft shop towel dampened with isopropyl alcohol.
After the adhesive has dried, spray water over the windshield and check for leaks. Mark the leaking area, let the windshield dry, then seal with sealant: Let the vehicle stand for at least 4 hours after windshield installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly. Keep the windshield dry for the first hour after installation.
Reinstall all remaining removed parts. NOTE: Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Rear Window Replacement

Note. Put on gloves to protect your hands. Wear eye protection while cutting the glass adhesive with piano wire. Use seat covers to avoid damaging any surfaces. Do not damage the rear window defogger grid lines, window antenna grid lines, and terminals.

Scheme 26

Scheme 26: Rear Window Replacement

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Remove these items: Trunk lid Rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-shelf-area) )
Disconnect the window antenna connectors (A) and rear window defogger connectors (B). '04-05 models '06-08 models
If the old rear window is to be reinstalled, make alignment marks across the glass and body with a grease pencil.
Pull down the rear portion of the headliner (A) by detaching the clips. Take care not to bend the headliner excessively, or you may crease or break it.
Apply protective tape along the inside and outside edges of the body. Using an awl, make a hole through the adhesive from inside the vehicle at the corner portion of the rear window. Push a piece of piano wire through the hole, and wrap each end around a piece of wood.
Remove the molding (A) from the lower edge of the rear window (B). If necessary, cut the molding with a utility knife.
With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the rear window (B) as possible to prevent damage to the body, and carefully cut through the adhesive (C) around the entire rear window. Cutting positions
Carefully remove the rear window.
With a putty knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire rear window opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the fasteners from the body.
Clean the body bonding surface with a sponge dampened in isopropyl alcohol. After cleaning, keep oil, grease and water from getting on the surface.
If the old rear window is to be reinstalled, use a putty knife to scrape off all of the old adhesive, the moldings and the fasteners from the rear window. Clean the inside face and the edge of the rear window with isopropyl alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil and grease.
Apply primer to the edge of the rear window (A) where the molding adhesive tape will be attached as shown. Attach the molding (B) with adhesive tape (C) to the lower edge of the rear window: After installing the molding, cut the ends (D) of the molding as shown. Be careful not to touch the windshield where adhesive will be applied. Molding adhesive tape: Thickness 0.2 mm (0.008 in.) Width 4 mm (0.16 in.)
Attach the rubber dam (A), clips (B), and fasteners (C) with adhesive tape to the inside face of the rear window (D) as shown: First attach the rubber dam, then attach the molding (E) around the edge of the rear window. Be sure both end of the molding contact with bottom of the rubber dam. If necessary, cut the rubber dam. Be sure the clips, and fasteners line up with the alignment marks (F). Be careful not to touch the windshield where adhesive will be applied. Rubber dam adhesive tape: Thickness 0.16 mm (0.006 in.) Width 4 mm (0.16 in.) Clips adhesive tape: Thickness 0.4 mm (0.016 in.) Width 10 mm (0.39 in.) Fasteners adhesive tape: Thickness 0.8 mm (0.031 in.) Width 7 mm (0.28 in.)
Attach the fasteners (A) with adhesive tape to the rear window opening flange (B) of the body on both sides. Fasteners adhesive tape: Thickness 0.8 mm (0.031 in.) Width 9 mm (0.35 in.)
Set the rear window in the opening, and center it. Make alignment marks (A) across the rear window and body with a grease pencil at the four points shown. Make sure both upper clips (B) are in the body holes. Be careful not to touch the rear window where adhesive will be applied.
Remove the rear window.
With a sponge, apply a light coat of glass primer along the edge of the rear window (A) between the dam (B) and molding (C) as shown, then lightly wipe it off with gauze or cheesecloth: With the printed dots (D) on the rear window as a guide, apply the glass primer to the rear window. Do not apply body primer to the rear window, and do not get body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the rear window properly, causing a leak after the rear window is installed. Keep water, dust, and abrasive materials away from the primed surfaces.
With a sponge, carefully apply a light coat of body primer to any exposed paint or metal around the flange where new adhesive will be applied. Let the primer dry for at least 10 minutes: Do not apply body primer to any remaining original adhesive on the flange. Be careful not to mix up the body and glass primer sponges. Never touch the primed surfaces with your hands. Use a body line (A) in the upside and both sides of the rear window opening flange as a guide to keep within width of the body primer shown while applying.
Cut a "V" in the end of the nozzle (A) on the adhesive cartridge as shown.
Pack adhesive into the cartridge without air pockets to ensure continuous delivery. Put the cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the rear window (B) between the dam (C) and molding (D) as shown. Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
Use suction cups to hold the rear window over the opening, align it with the alignment marks you made in step 15 , and set it down on the adhesive. Lightly push on the rear window until its edges are fully seated on the adhesive all the way around. NOTE: Do not open or close any of the doors for about an hour until the adhesive is dry.
Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the rear window, use a soft shop towel dampened with isopropyl alcohol.
After the adhesive has dried, spray water over the rear window and check for leaks. Mark the leaking area, let the rear window dry, then seal with sealant. Let the vehicle stand for at least 4 hours after rear window installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly.
Reinstall all remaining removed parts. NOTE: Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).
