Electronic Throttle Control System Acura TSX I

Scheme 16

DTC P0122: TP Sensor A Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '05-08 models.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 9 . NO - Go to step 5.
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Disconnect the throttle actuator control module 16P connector.
8. Check for continuity between throttle body 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the throttle actuator control module (TPSA line), then go to step 17 . NO -Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 and recheck. If DTC P0122 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 . If DTC P0122 is indicated, go to step 15 .
9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 15 . NO - Go to step 10.
10. Turn the ignition switch OFF.
11. Disconnect the throttle actuator control module 16P connector.
12. Disconnect the throttle body 6P connector.
13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
14. Check for continuity between throttle actuator control module 16P connector terminal No. 11 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 and recheck. If DTC P0122 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 . If DTC P0122 is indicated, go to step 15. NO - Repair open in the wire between the throttle body and the throttle actuator control module (VCC line), then go to step 17 .
15. Turn the ignition switch OFF.
16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
17. Reconnect all connectors.
18. Turn the ignition switch ON (II).
19. Reset the ECM/PCM with the HDS.
20. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0122 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0123: TP Sensor A Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '05-08 models.

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 13 . NO - Go to step 5.
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Turn the ignition switch ON (II).
8. Measure voltage between throttle body 6P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 18 . NO - Go to step 9.
9. Turn the ignition switch OFF.
10. Disconnect the throttle actuator control module 16P connector.
11. Connect throttle body 6P connector terminal No. 1 to body ground with a jumper wire.
12. Check for continuity between throttle actuator control module 16P connector terminal No. 10 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 and recheck. If DTC P0123 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 . If DTC P0123 is indicated, go to step 18 . NO - Repair open in the wire between the throttle body and the throttle actuator control module (TPSA line), then go to step 20 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Disconnect the throttle actuator control module 16P connector.
16. Connect throttle body 6P connector terminal No. 4 to body ground with a jumper wire.
17. Check for continuity between throttle actuator control module 16P connector terminal No. 9 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 and recheck. If DTC P0123 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 . If DTC P0123 is indicated, go to step 18 . NO - Repair open in the wire between the throttle body and the throttle actuator control module (SG line), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the ECM/PCM with the HDS.
23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0123 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0222: TP Sensor B Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '05-08 models.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 9 . NO - Go to step 5.
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Disconnect the throttle actuator control module 16P connector.
8. Check for continuity between throttle body 6P connector terminal No. 3 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the throttle actuator control module (TPSB line), then go to step 17 . NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 and recheck. If DTC P0222 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 . If DTC P0222 is indicated, go to step 15 .
9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 15 . NO - Go to step 10.
10. Turn the ignition switch OFF.
11. Disconnect the throttle actuator control module 16P connector.
12. Disconnect the throttle body 6P connector.
13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
14. Check for continuity between throttle actuator control module 16P connector terminal No. 11 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 and recheck. If DTC P0222 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 17 . If DTC P0222 is indicated, go to step 15. NO - Repair open in the wire between the throttle body and the throttle actuator control module (VCC line), then go to step 17 .
15. Turn the ignition switch OFF.
16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
17. Reconnect all connectors.
18. Turn the ignition switch ON (II).
19. Reset the ECM/PCM with the HDS.
20. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0222 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0223: TP Sensor B Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '05-08 models.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 13 . NO - Go to step 5.
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Turn the ignition switch ON (II).
8. Measure voltage between throttle body 6P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 18 . NO - Go to step 9.
9. Turn the ignition switch OFF.
10. Disconnect the throttle actuator control module 16P connector.
11. Connect throttle body 6P connector terminal No. 3 to body ground with a jumper wire.
12. Check for continuity between throttle actuator control module 16P connector terminal No. 12 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 and recheck. If DTC P0223 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 . If DTC P0223 is indicated, go to step 18 . NO - Repair open in the wire between the throttle body and the throttle actuator control module (TPSB line), then go to step 20 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Disconnect the throttle actuator control module 16P connector.
16. Connect throttle body 6P connector terminal No. to body ground with a jumper wire.
17. Check for continuity between throttle actuator control module 16P connector terminal No. 9 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 and recheck. If DTC P0223 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 . If DTC P0223 is indicated, go to step 18. NO - Repair open in the wire between the throttle body and the throttle actuator control module (SG line), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the ECM/PCM with the HDS.
23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0223 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P1683: Throttle Valve Default Position Spring Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 35

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
4. Turn the ignition switch OFF, and wait 10 seconds.
5. Turn the ignition switch ON (II).
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1683 indicated? YES - Go to step 7. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
7. Turn the ignition switch OFF.
8. Disconnect the intake air duct from the throttle body.
9. Push the throttle valve closed as shown.
10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), then go to step 13 and recheck. If DTC P1683 is indicated, go to step 11. NO - Go to step 11.
11. Turn the ignition switch OFF.
12. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
13. Turn the ignition switch ON (II).
14. Reset the ECM/PCM with the HDS.
15. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
16. Turn the ignition switch OFF, and wait 10 seconds.
17. Turn the ignition switch ON (II).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1683 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P1684: Throttle Valve Return Spring Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 36

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
4. Turn the ignition switch OFF, and wait 10 seconds.
5. Turn the ignition switch ON (II).
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1684 indicated? YES - Go to step 7. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
7. Turn the ignition switch OFF.
8. Disconnect the intake air duct from the throttle body.
9. Push the throttle valve open as shown.
10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), then go to step 13 and recheck. If DTC P1684 is indicated, go to step 11. NO - Go to step 11.
11. Turn the ignition switch OFF.
12. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
13. Turn the ignition switch ON (II).
14. Reset the ECM/PCM with the HDS.
15. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
16. Turn the ignition switch OFF, and wait 10 seconds.
17. Turn the ignition switch ON (II).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1684 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2101: Throttle Actuator System Malfunction

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 37

Scheme 38

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Go to step 5.
5. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS APP SENSOR
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and at the throttle actuator control module, then clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
7. Turn the ignition switch OFF.
8. Disconnect the intake air duct from the throttle body.
9. Turn the ignition switch ON (II).
10. Clear the DTC with the HDS.
11. Do the ETCS TEST in the INSPECTION MENU with the HDS.
12. Visually check the throttle valve operation. Does the throttle valve operate smoothly? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), then go to step 21 and recheck. If DTC P2101 is indicated, go to step 18 . NO - Go to step 13.
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Disconnect the throttle actuator control module 16P connector.
16. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
17. Check for continuity between throttle actuator control module 16P connector terminals No. 1 and No. 8. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 and recheck. If DTC P2101 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 20 . If DTC P2101 is indicated, go to step 18. NO - Repair open in the wires between the throttle body and the throttle actuator control module (motor drive lines), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the ECM/PCM with the HDS.
23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
24. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS APP SENSOR
25. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), and go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2108: Throttle Actuator Control Module Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Turn the ignition switch OFF.
4. Turn the ignition switch ON (II).
5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2108 indicated? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), and recheck. If DTC P2108 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ). NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body, the throttle actuator control module, and the ECM/PCM.

DTC P2118: Throttle Actuator Current Range/ Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 39

Scheme 40

1. Disconnect the throttle actuator control module 16P connector.
2. Measure resistance between throttle actuator control module 16P connector terminals No. 1 and No. 8. Is there about 1.0 ohms or less? YES - Go to step 3. NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 6 and recheck. If DTC P2118 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 6 .
3. Disconnect the throttle body 6P connector.
4. At the throttle body side, measure resistance between throttle body 6P connector terminals No. 5 and No. 6 with the throttle fully closed. Is there about 1.0 ohms or less? YES - Go to step 5. NO - Repair short in the wires between the throttle body and the throttle actuator control module (motor drive lines), then go to step 6 .
5. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
6. Reconnect all connectors.
7. Turn the ignition switch ON (II).
8. Reset the ECM/PCM with the HDS.
9. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
10. Turn the ignition switch OFF.
11. Turn the ignition switch ON (II).
12. Slowly press the accelerator pedal to the floor.
13. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2118 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2122: APP Sensor A (TP Sensor D) Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Turn the ignition switch ON (II).
2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the ECM/PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 7. NO - Go to step 17 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect ECM/PCM connector A (31P).
10. Check for continuity between APP sensor 6P connector terminal No. 4 and body ground. Is there continuity? YES - Repair short in the wire between APP sensor A and the ECM/PCM (A26), then go to step 20 . NO - Go to step 11.
11. Connect APP sensor 6P connector terminal No. 4 to body ground with a jumper wire.
12. Check for continuity between ECM/PCM connector terminal A26 and body ground. Is there continuity? YES - Go to step 13. NO - Repair open in the wire between APP sensor A and the ECM/PCM (A26), then go to step 20 .
13. Reconnect ECM/PCM connector A (31P).
14. Connect APP sensor 6P connector terminals No. 4 and No. 5 with a jumper wire.
15. Turn the ignition switch ON (II).
16. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 25 . NO - Go to step 18 .
17. Measure voltage between ECM/PCM connector terminals A21 and A24. Is there about 5 V? YES - Repair open in the wire between APP sensor A and the ECM/PCM (A21), then go to step 20 . NO - Go to step 25 .
18. Turn the ignition switch OFF.
19. Replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the ECM/PCM with the HDS.
23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2122 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
25. Turn the ignition switch OFF.
26. Reconnect all connectors.
27. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2122 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO -If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2123: APP Sensor A (TP Sensor D) Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 47

Scheme 48

1. Turn the ignition switch ON (II).
2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 4.9 V or more? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the ECM/PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 8 . NO - Go to step 7.
7. Measure voltage between ECM/PCM connector terminals A21 and A24. Is there about 5 V? YES - Repair open in the wire between APP sensor A and the ECM/PCM (A24), then go to step 10 . NO - Go to step 15 .
8. Turn the ignition switch OFF.
9. Replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ).
10. Reconnect the APP sensor 6P connector.
11. Turn the ignition switch ON (II).
12. Reset the ECM/PCM with the HDS.
13. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
14. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2123 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
15. Turn the ignition switch OFF.
16. Reconnect all connectors.
17. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2123 indicated ? YES - Check for poor connections or loose terminals at APP sensor A and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2127: APP Sensor B (TP Sensor E) Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. Turn the ignition switch ON (II).
2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor B and the ECM/PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 1 and No. 2. Is there about 5 V? YES - Go to step 7. NO - Go to step 17 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect ECM/PCM connector A (31P).
10. Check for continuity between APP sensor 6P connector terminal No. 3 and body ground. Is there continuity? YES - Repair short in the wire between APP sensor B and the ECM/PCM (A25), then go to step 20 . NO - Go to step 11.
11. Connect APP sensor 6P connector terminal No. 3 to body ground with a jumper wire.
12. Check for continuity between ECM/PCM connector terminal A25 and body ground. Is there continuity? YES - Go to step 13. NO - Repair open in the wire between APP sensor B and the ECM/PCM (A25), then go to step 20 .
13. Reconnect ECM/PCM connector A (31P).
14. Connect APP sensor 6P connector terminals No. 1 and No. 3 with a jumper wire.
15. Turn the ignition switch ON (II).
16. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 25 . NO - Go to step 18 .
17. Measure voltage between ECM/PCM connector terminals A20 and A23. Is there about 5 V? YES - Repair open in the wire between APP sensor B and the ECM/PCM (A20), then go to step 20 . NO - Go to step 25 .
18. Turn the ignition switch OFF.
19. Replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the ECM/PCM with the HDS.
23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2127 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting.
25. Turn the ignition switch OFF.
26. Reconnect all connectors.
27. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2127 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTC's are indicated, go to the indicated DTC's troubleshooting.

DTC P2128: APP Sensor B (TP Sensor E) Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 55

Scheme 56

1. Turn the ignition switch ON (II).
2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 4.9 V or more? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor B and the ECM/PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 1 and No. 2. Is there about 5 V? YES - Go to step 8 . NO - Go to step 7.
7. Measure voltage between ECM/PCM connector terminals A20 and A23. Is there about 5 V? YES - Repair open in the wire between APP sensor B and the ECM/PCM (A23), then go to step 10 . NO - Go to step 15 .
8. Turn the ignition switch OFF.
9. Replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ).
10. Reconnect the APP sensor 6P connector.
11. Turn the ignition switch ON (II).
12. Reset the ECM/PCM with the HDS.
13. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
14. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2128 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
15. Turn the ignition switch OFF.
16. Reconnect all connectors.
17. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2128 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2135: TP Sensor A/B Incorrect Voltage Correlation

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 57

Scheme 58

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2135 indicated? YES - Go to step 5. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
5. Turn the ignition switch OFF.
6. Disconnect the intake air duct from the throttle body.
7. Turn the ignition switch ON (II).
8. Visually check the throttle valve operation while you clear the DTC with the HDS. Does the valve temporarily move to the fully closed position? YES - Go to step 14 . NO - Go to step 9.
9. Turn the ignition switch OFF.
10. Disconnect the throttle actuator control module 16P connector.
11. Check for continuity between throttle actuator control module 16P connector terminals No. 10 and No. 12. Is there continuity? YES - Go to step 12. NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 16 and recheck. If DTC P2135 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 16 .
12. Disconnect the throttle body 6P connector.
13. Check for continuity between throttle actuator control module 16P connector terminals No. 10 and No. 12. Is there continuity? YES - Repair short in the wires between the TPSA line and the TPSB line, then go to step 16 . NO - Go to step 14.
14. Turn the ignition switch OFF.
15. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
16. Reconnect all connectors.
17. Turn the ignition switch ON (II).
18. Reset the ECM/PCM with the HDS.
19. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
20. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2135 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2138: APP Sensor A/B (TP Sensor D/E) Incorrect Voltage Correlation

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 59

Scheme 60

1. Turn the ignition switch ON (II).
2. Clear the DTC with HDS.
3. Press the accelerator pedal to the floor.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Go to step 5. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the APP sensor and the ECM/PCM.
5. Check APP SENSOR A and APP SENSOR B in the DATA LIST with the HDS. Are they the same voltage? YES - Go to step 6. NO - Go to step 12 .
6. Turn the ignition switch OFF.
7. Jump the SCS line with the HDS.
8. Disconnect ECM/PCM connector A (31P).
9. Check for continuity between ECM/PCM connector terminals A25 and A26. Is there continuity? YES - Go to step 10. NO - Go to step 22 .
10. Disconnect the APP sensor 6P connector.
11. Check for continuity between ECM/PCM connector terminals A25 and A26. Is there continuity? YES - Repair short in the wires between ECM/PCM connector terminals A25 (APSB line) and A26 (APSA line), then go to step 14 . NO - Go to step 13 .
12. Turn the ignition switch OFF.
13. Replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ).
14. Reconnect all connectors.
15. Turn the ignition switch ON (II).
16. Reset the ECM/PCM with the HDS.
17. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
18. Turn the ignition switch OFF.
19. Turn the ignition switch ON (II).
20. Press the accelerator pedal to the floor.
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Check for poor connections or loose terminals at APP sensor A/B and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
22. Reconnect all connectors.
23. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
24. Turn the ignition switch OFF.
25. Turn the ignition switch ON (II).
26. Press the accelerator pedal to the floor.
27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Check for poor connections or loose terminals at APP sensor A/B and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then go to step 24 . If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2176: Throttle Actuator Control System Idle Position Not Learned

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). If DTC P2135 is stored at the same time as DTC P2176, troubleshoot DTC P2135 first, then recheck for DTC P2176.

Scheme 61

Scheme 62

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Turn the ignition switch OFF.
4. Turn the ignition switch ON (II), and wait 10 seconds.
5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2176 indicated? YES - Go to step 6. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
6. Turn the ignition switch OFF.
7. Disconnect the intake air duct from the throttle body.
8. Turn the ignition switch ON (II).
9. Clear the DTC with the HDS.
10. Visually check the throttle valve operation while performing the ETCS TEST in the INSPECTION MENU with the HDS. Does the throttle valve move to its fully closed position? YES - Go to step 11. NO - Go to step 12 .
11. Check for sludge or carbon on the throttle valve. Is there sludge or carbon on the throttle valve? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), then go to step 20 and recheck. NO - Go to step 17 .
12. Turn the ignition switch OFF.
13. Disconnect the throttle body 6P connector.
14. Disconnect the throttle actuator control module 16P connector.
15. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
16. Check for continuity between throttle actuator control module 16P connector terminals No. 1 and No. 8. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 19 and recheck. If DTC P2176 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 19 . NO - Repair open in the wires between the throttle body and the throttle actuator control module (motor drive lines), then go to step 19 .
17. Turn the ignition switch OFF.
18. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
19. Reconnect all connectors.
20. Turn the ignition switch ON (II).
21. Reset the ECM/PCM with the HDS.
22. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
23. Turn the ignition switch OFF.
24. Turn the ignition switch ON (II), and wait 10 seconds.
25. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2176 indicated? YES - Check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system__throttle-body-cleaning) ), and go to step. 1. NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the, indicated DTCs troubleshooting.

DTC P2552: Throttle Actuator Control Module Relay Malfunction

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 63

Scheme 64

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS. Is the RELAY Circuit OK? YES - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM. NO - Go to step 4.
4. Turn the ignition switch OFF.
5. Remove the throttle actuator control module relay (A).
6. Test the throttle actuator control module relay (see «POWER RELAY TEST»(/acura/tsx/i-2003-2008/remont/body-electrical/#relays__power-relay-test) ). Is the relay OK? YES - Go to step 7. NO - Replace the throttle actuator control module relay, then go to step 10 .
7. Jump the SCS line with the HDS.
8. Disconnect ECM/PCM connector D (17P).
9. Check for continuity between ECM/PCM connector terminal D15 and body ground. Is there continuity? YES - Repair short in the wire between the throttle actuator control module relay and the ECM/PCM (D15), then go to step 10. NO - Go to step 17 .
10. Reconnect ECM/PCM. connector D (17P).
11. Turn the ignition switch ON (II).
12. Reset the ECM/PCM with the HDS.
13. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
14. Turn the ignition switch OFF.
15. Turn the ignition switch ON (II), and wait 10 seconds.
16. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2552 indicated? YES - Check for poor connections or loose terminals at the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting.
17. Reconnect all connectors.
18. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
19. Turn the ignition switch OFF.
20. Turn the ignition switch ON (II), and wait 10 seconds.
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2552 indicated? YES - Check for poor connections or loose terminals at the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTC's are indicated, go to the indicated DTC's troubleshooting.

DTC U0107: Lost Communication With Throttle Actuator Control Module

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check for Temporary DTCs or DTCs with the HDS. Is DTC U0107 indicated? YES - Check for poor connections or loose terminals at the throttle body, the throttle actuator control module, and the ECM/PCM, then go to step 50 . If the connections are OK, go to step 6 . NO - Go to step 4.
4. Start the engine.
5. Check for Temporary DTCs or DTCs with the HDS. Is DTC U0107 indicated? YES - Go to step 46 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body, the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM.
6. Clear the DTC with the HDS.
7. Turn the ignition switch OFF.
8. Disconnect the intake air duct from the throttle body.
9. Press the accelerator pedal to the floor.
10. Turn the ignition switch ON (II).
11. Check the throttle valve operation. Does the throttle valve open after it closes? YES - Go to step 12. NO - Go to step 13 .
12. Check the throttle valve again. Does the throttle valve open fully? YES - Go to step 40 . NO - Go to step 34 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle actuator control module 16P connector.
15. Check for continuity between throttle actuator control module 16P connector terminal No. 7 and body ground. Is there continuity? YES - Go to step 16. NO - Repair open in the wire between the throttle body, the throttle actuator control module, and G101, then go to step 50 .
16. Remove the throttle actuator control module relay (A).
17. Measure voltage between throttle actuator control module relay 4P connector terminal No. 1 and body ground. Is there battery voltage? YES - Go to step 19 . NO - Go to step 18.
18. Check the No. 1 DBW (THROTTLE ACTUATOR CONTROL) (15 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES - Repair open in the wire between the throttle actuator control module relay (+B line) and the No. 1 DBW (THROTTLE ACTUATOR CONTROL) (15 A) fuse, then go to step 50 . NO - Repair short in the wire between the throttle actuator control module relay (+B line) and the No. 1 DBW (THROTTLE ACTUATOR CONTROL) (15 A) fuse. Also replace the fuse, then go to step 50 .
19. Install the throttle actuator control module relay.
20. Turn the ignition switch ON (II).
21. Measure voltage between throttle actuator control module 16P connector terminal No. 2 and body ground. Is there battery voltage for about 2 seconds? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 and recheck. If DTC U0107 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 . NO - Go to step 22.
22. Turn the ignition switch OFF.
23. Remove the throttle actuator control module relay (A).
24. Check the throttle actuator control module relay (see «POWER RELAY TEST»(/acura/tsx/i-2003-2008/remont/body-electrical/#relays__power-relay-test) ). Is the throttle actuator control module relay OK? YES - Go to step 25. NO - Replace the throttle actuator control module relay, then go to step 50 .
25. Turn the ignition switch ON (II).
26. Measure voltage between throttle actuator control module relay 4P connector terminal No. 4 and body ground. Is there battery voltage? YES - Go to step 27. NO - Repair open in the wire between the throttle actuator control module relay and PGM-FI main relay 1 (FI MAIN), then go to step 50 .
27. Turn the ignition switch OFF.
28. Jump the SCS line with the HDS.
29. Disconnect ECM/PCM connector D (17P).
30. Check for continuity between ECM/PCM connector terminal D15 and throttle actuator control module relay 4P connector terminal No. 3. Is there continuity? YES - Go to step 31. NO - Repair open in the wire between the ECM/PCM (D15) and the throttle actuator control module relay, then go to step 50 .
31. Check for continuity between throttle actuator control module 16P connector terminal No. 2 and body ground. Is there continuity? YES - Repair short in the wire between the throttle actuator control module and the throttle actuator control module relay (+B line), then go to step 50 . NO - Go to step 32.
32. Connect throttle actuator control module relay 4P connector terminal No. 2 to body ground with a jumper wire.
33. Check for continuity between throttle actuator control module 16P connector terminal No. 2 and body ground. Is there continuity? YES - Go to step 56 . NO - Repair open in the wire between the throttle actuator control module and the throttle actuator control module relay (+B line), then go to step 50 .
34. Turn the ignition switch OFF.
35. Jump the SCS line with the HDS.
36. Disconnect the throttle actuator control module 16P connector.
37. Disconnect ECM/PCM connector B (24P).
38. Check for continuity between ECM/PCM connector terminal B19 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (B19) and the throttle actuator control module, then go to step 50 . NO - Go to step 39.
39. Check for continuity between ECM/PCM connector terminal B19 and throttle actuator control module 16P connector terminal No. 6. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 and recheck. If DTC U0107 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 . If DTC U0107 is indicated, go to step 56 . NO - Repair open in the wire between the ECM/PCM (B19) and the throttle actuator control module, then go to step 50 .
40. Turn the ignition switch OFF.
41. Jump the SCS line with the HDS.
42. Disconnect the throttle actuator control module 16P connector.
43. Disconnect ECM/PCM connector B (24P).
44. Check for continuity between ECM/PCM connector terminal B20 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (B20) and the throttle actuator control module, then go to step 50 . NO - Go to step 45.
45. Check for continuity between ECM/PCM connector terminal B20 and throttle actuator control module 16P connector terminal No. 14. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 and recheck. If DTC U0107 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 50 . If DTC U0107 is indicated, go to step 56 . NO - Repair open in the wire between the ECM/PCM (B20) and the throttle actuator control module, then go to step 50 .
46. Turn the ignition switch OFF.
47. Jump the SCS line with the HDS.
48. Disconnect ECM/PCM connector A (31P).
49. Check for continuity between body ground and ECM/PCM connector terminals A8 and A9 individually. Is there continuity? YES - Check for poor connections or loose terminals at the throttle body, the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM. Then reconnect all connectors, and go to step 6 . NO - Repair open in the wire between the ECM/PCM (A8, A9) and G101, then go to step 50.
50. Turn the ignition switch OFF.
51. Reconnect all connectors.
52. Turn the ignition switch ON (II).
53. Reset the ECM/PCM with the HDS.
54. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#idle-control-system__ecmpcm-idle-learn-procedure) ).
55. Check for Temporary DTCs or DTCs with the HDS. Is DTC U0107 indicated? YES - Check for poor connections or loose terminals at the throttle body, the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting.
56. Update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ).
57. Check for Temporary DTCs or DTCs with the HDS. Is DTC U0107 indicated? YES - Check for poor connections or loose terminals at the throttle body, the throttle actuator control module relay, the throttle actuator control module, and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM; '04-05 models (see «'04-05 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '06-08 models (see «'06-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ). If any other Temporary DTCs or DTC's are indicated, go to the indicated DTC's troubleshooting.

APP Sensor Signal Inspection

Note. This procedure checks the APP sensor in its fully closed position. In any other position, the APP sensor stores DTCs which are covered in other troubleshooting procedures. Check for Temporary DTCs or DTCs with the HDS before doing this procedure. If any DTCs are indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times to check its operation. If it does not operate properly, check the pedal, the throttle cable, and the APP sensor individually. If you find a problem in one of them, replace the part(s) that caused the problem.

Scheme 80

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch ON (II).
3. Make sure the HDS communicates with the ECM/PCM. If it doesn't, go to the DLC circuit troubleshooting; '04-06 models (see «'04-06 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ), '07-08 model (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) ).
4. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, adjust the throttle cable (see «THROTTLE CABLE ADJUSTMENT»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system) ), then go to step 5.
5. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__updating-the-ecmpcm) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then go to step 6.
6. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, replace the APP sensor (see «APP SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 1 .

Scheme 81

1. Remove the throttle cable (see «THROTTLE CABLE REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#intake-air-system) ).
2. Disconnect the accelerator pedal position (APP) sensor 6P connector (A).
3. Remove the bolts (B), and the APP sensor (C).
4. Install the parts in the reverse order of removal.

Scheme 82

1. Remove the right kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ).
2. Push the tab (A) and disconnect the throttle actuator control module 16P connector (B).
3. Remove the bolts (C), and the throttle actuator control module (D).
4. Install the parts in the reverse order of removal.

See also:
• GENERAL TROUBLESHOOTING INFORMATION
• THROTTLE BODY REMOVAL/INSTALLATION
• ECM/PCM IDLE LEARN PROCEDURE
• THROTTLE BODY CLEANING
• UPDATING THE ECM/PCM
• SUBSTITUTING THE ECM/PCM
• '04-05 MODELS
• POWER RELAY TEST
• THROTTLE CABLE ADJUSTMENT
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT
