Fenderwell Acura TSX I

Exterior Body Panels 8 illustrations ~544 words

Front Inner Fender Replacement

Note. Take care not to scratch the body.

Scheme 10

Scheme 10: Front Inner Fender Replacement
Scheme 10: Front Inner Fender Replacement
  1. Remove the front inner fender (A). On the back of the wheel arch, remove the screws (B) If equipped, remove the front splash guard (C) (Canada models). From under the front bumper (D), remove the bolts (E) securing the front bumper, splash shield (F), and front inner fender, and remove the clip (G) securing the front bumper and front inner fender. From the wheel arch, remove the clips (H, I, J) securing the front inner fender (and splash shield) on the body. Release the hook (K) of the splash shield, then remove the front inner fender.
  2. Install the inner fender in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Splash Shield Replacement

Note. Take care not to scratch the body.

Scheme 11

Scheme 11: Splash Shield Replacement
Scheme 11: Splash Shield Replacement
  1. Remove the splash shield (A). From both wheel arch, remove the bolts (B), clips (C), and clip (D) securing the front inner fender (E) and splash shield (on the body). From under the front bumper (F), remove the clips (C), and bolts (G). Release the hooks (H) of the splash shield, then pull the splash shield out.
  2. Install the splash shield in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Scheme 12

Scheme 12: Front Fender Fairing Replacement
Scheme 12: Front Fender Fairing Replacement

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Remove the front inner fender as needed (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
  2. Open the front door. Remove the upper clip, and from inside the door, remove the lower clip securing the front fender fairing (A) and front fender (B).
  3. From the wheel arch, release the clips.
  4. Remove the front fender fairing (A).
  5. Install the fender fairing in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Before installing the clips in the door opening area, install the front fender fairing (A) to the front fender (B) properly as shown. Push the clips into place securely.

Rear Inner Fender Replacement

Note. Take care not to scratch the body.

Scheme 16

Scheme 16: Rear Inner Fender Replacement
Scheme 16: Rear Inner Fender Replacement
  1. Remove the rear inner fender (A). On the front of the wheel arch, remove the screws (B) securing the side sill panel (C) and rear inner fender, and the clip (D) securing the rear inner fender and middle floor undercover (E). On the rear bumper (F), remove the screw (G). From the wheel arch, remove the clips (H, I). Pull the rear inner fender out.
  2. Install the inner fender in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Scheme 17

Scheme 17: Rear Air Outlet Replacement
Scheme 17: Rear Air Outlet Replacement
  1. Remove the rear bumper (see «REAR BUMPER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#bumper-system__rear-bumper-removalinstallation) ).
  2. Detach the hooks (A), then remove the rear air outlet (B). Take care not to scratch the body.
  3. Install the air outlet by pushing on the hook portions until the hooks snap into place.
