Scheme 1
Scheme 2
System Description
The driver's seat and the power mirrors have a memory feature. All the adjustments can be memorized by pressing the MEMO button on the driving position memory switch, and then pressing one of two position buttons within 5 seconds. Pressing the appropriate position button will move the seat and the mirrors to the memorized positions. This system is integrated with the multiplex integrated control system, and has 9 wake-up and sleep modes. All digital signals are sent via shared B-CAN and UART communication lines. For more information about communication line and wake-up/sleep mode, refer to the Multiplex Control System Description (see SYSTEM DESCRIPTION ).
DPMS is linked to the keyless transmitters 1 and 2. Depending on which keyless transmitter unlocks the doors, the driving memory position 1 or 2 is chosen. To turn remote DPMS feature ON (link) or OFF (unlinked) press and hold the LOCK and UNLOCK buttons on the keyless transmitter for about 1 second, the LED on the keyless transmitter blinks once when linked, and twice when unlinked, refer to Keyless Entry/Security Alarm System Descriptions (see SYSTEM DESCRIPTION ) for more information.
