Seat Belt System Acura TL III

Scheme 1

Scheme 2

Front Seat Belt Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or service.

Note. Check the front seat belts for damage (see INSPECTION ), and replace them if necessary.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Make sure you have the anti-theft codes for the audio and navigation systems, and then write down the audio presets.
2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
3. Slide the front seat forward fully.
4. Remove the B-pillar lower trim (see «B-PILLAR»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim) ).
5. Driver's seat belt/Passenger's seat belt ('04 model): Pull the lower anchor cover (A) up, and remove the lower anchor bolt (B) and double-shouldered washer (C).
6. Passenger's seat belt ('05-06 models): Detach the front seat belt latch plate (A). -1 Pull out the recline cover cap (B) to release the hooks (C), and remove the cap by pulling it up. -2 Push the top of the lock (D) in to detach the latch plate from the lower anchor (E).
7. Remove the B-pillar upper trim and slider (see «B-PILLAR»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim) ).
8. Remove the upper anchor bolt (A).
9. Disconnect the seat belt tensioner connector (A) and seat belt tension reducer connector (B). Remove the upper retractor mounting bolt (C) and the lower retractor bolt (D), then remove the front seat belt (E) and retractor (F).
10. If necessary, remove the front seat belt protector (G).
11. Remove the shoulder anchor adjuster (A).
12. Install the seat belt in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions as described (see «INSPECTION»(/acura/tl/iii-2003-2006/remont/restraints-control-systems/#seat-belt-system) ). Assemble the washers, collars, and bushings on the upper and lower anchor bolts as shown. If the seat belt tensioner has been activated, replace the front seat belt protector with a new one. Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt. Passenger's seat belt ('05-06 models): Before attaching the front seat belt lower anchor, make sure there are no twists or kinks in the belt. Insert the latch plate (A) into the lower anchor (B) and be sure the lower anchor is locked securely. Make sure the seat belt tensioner and tension reducer connectors are plugged in properly. Reconnect the negative cable to the battery. Check for any DTCs, and clear them using the HDS. If the DTCs will not clear, perform the necessary troubleshooting. Enter the anti-theft codes for the audio and navigation systems, then enter the audio presets. Set the clock (without navigation system).

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Make sure you have the anti-theft codes for the audio and navigation systems, and then write down the audio presets.
2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
3. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/seats/#seats__front-seat-removalinstallation) ).
4. Remove the center cover, 4-way power seat (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - 4-WAY POWER»(/acura/tl/iii-2003-2006/remont/seats/#seats__front-seat-disassemblyreassembly-4-way-power) ), 10-way power seat (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - 10-WAY POWER»(/acura/tl/iii-2003-2006/remont/seats/#seats__front-seat-disassemblyreassembly-10-way-power) ).
5. Disconnect or detach the seat belt switch connector (A).
6. Release the hook (A) of the seat cushion cover on 4-way power seat. Remove the center anchor bolt (B), and detach the harness clip (C) on the driver's and some passenger's seats, then remove the seat belt buckle (D).
7. Pull the seat belt switch harness (E) out through the space between the seat cushion and the seat linkage or through the hole in the seat track.
8. Install the buckle in the reverse order of removal, and note these items

Scheme 15

1. Assemble the washers on the center anchor bolt (Scheme 15)
2. Apply liquid thread lock to the center anchor bolt before reinstallation.
3. Tighten the bolts by hand first, then tighten to specification with a torque wrench.
4. Reconnect the negative cable to the battery.
5. Enter the anti-theft codes for the audio and navigation systems, and then enter the audio presets.
6. Set the clock (without navigation system).

Scheme 16

Scheme 17

1. Make sure you have the anti-theft codes for the audio and navigation systems, and then write down the audio presets.
2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
3. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/seats/#seats__front-seat-removalinstallation) ).
4. Remove the recline cover (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - 4-WAY POWER»(/acura/tl/iii-2003-2006/remont/seats/#seats__front-seat-disassemblyreassembly-4-way-power) ).
5. Remove the lower anchor bolt (A), then remove the lower anchor (B).
6. Install the anchor in the reverse order of removal, and note these items: Assemble the washers, collar, and bushing on the lower anchor bolt (Scheme 17) Reconnect the negative cable to the battery. Enter the anti-theft codes for the audio and the navigation systems, then enter the audio presets. Set the clock (without navigation system).

Rear Seat Belt Replacement

Note. Check the rear seat belts for damage, and replace them if necessary.

Scheme 18

Scheme 19

1. Remove the rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/seats/#seats__rear-seat-removalinstallation) ).
2. Remove the lower anchor bolt (A).
3. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-shelf-area) ).
4. Remove the retractor mounting bolt (A), and the retractor bolt (B), then remove the rear seat belt (C) and retractor (D).
5. Install the seat belt in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Check that the retractor locking mechanism functions as described (see «INSPECTION»(/acura/tl/iii-2003-2006/remont/restraints-control-systems/#seat-belt-system) ). Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt.

Scheme 20

Scheme 21

Scheme 22

1. Remove the rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/seats/#seats__rear-seat-removalinstallation) ).
2. Remove the center anchor bolts (A), and remove the seat belt buckles (B).
3. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-shelf-area) ).
4. Remove the retractor bolt (A), then remove the center seat belt (B) and retractor (C).
5. Install the seat belt and buckles in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions as described (see «INSPECTION»(/acura/tl/iii-2003-2006/remont/restraints-control-systems/#seat-belt-system) ). Assemble the washers on the center anchor bolt (Scheme 22) Before installing the center anchor bolt, make sure there are no twists or kinks in the center belt. Verify that the rear center emergency locking retractor (ELR) is pointing straight forward.

Out of Vehicle

For front seat belt retractor with seat belt tensioner, review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or service.

Scheme 23

Scheme 24

Scheme 25

1. Before installing the retractor, check that the seat belt can be pulled out freely.
2. Make sure that the seat belt does not lock when the retractor (A) is leaned slowly up to 15° from the mounted position. The seat belt should lock when the retractor is leaned over 40°. Do not attempt to disassemble the retractor. Front Rear Rear center
3. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.

In-vehicle

1. Check that the seat belt is not twisted or caught on anything.
2. After installing the anchors, check for free movement on the anchor bolts. If necessary, remove the anchor bolts and check that the washers and other parts are not damaged or improperly installed.
3. Check the seat belts for damage or discoloration. If necessary, clean the seat belts with soap and water only, then wipe them off with a clean towel. NOTE: Dirt buildup in the metal loops of the upper anchors can cause the seat belts to retract slowly. Wipe the inside of the loops with a clean cloth dampened in isopropyl alcohol.
4. Check that the seat belt does not lock when pulled out slowly. The seat belt is designed to lock only during a sudden stop or impact.
5. Make sure that the seat belt will retract automatically when released.
6. For front passenger's seat belt and all rear seat belts, check the seat belt retractor locking mechanism ALR (automatic locking retractor). This function is for securing child seats. -1 Pull the seat belt all the way out to engage the ALR. The seat belt should retract with a soft, ratcheting sound, but not extend. This is normal. -2 To disengage the ALR, release the seat belt and allow it to fully retract, then pull the seat belt out part-way. The seat belt should retract and extend normally.
7. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.
