DTC P2552: Throttle Actuator Control Module Relay Malfunction Acura RL II facelift

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 303

Scheme 304

1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS. Is the RELAY circuit OK? YES -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle actuator control module relay, the throttle actuator control module, and the PCM. NO -Go to step 4.
4. Turn the ignition switch to LOCK (0).
5. Remove the throttle actuator control module relay (A) from the passenger's under-dash fuse/ relay box.
6. Test the throttle actuator control module relay (see «POWER RELAY TEST»(ref-348527-S40346938242009112400000) ). Is the relay OK? YES -Go to step 7. NO -Replace the throttle actuator control module relay, then go to step 10 .
7. Jump the SCS line with the HDS.
8. Disconnect PCM connector E (31P).
9. Check for continuity between PCM connector terminal E3 and body ground. Is there continuity? YES -Repair short in the wire between the throttle actuator control module relay and the PCM (E3), then go to step 10. NO -Go to step 17 .
10. Reconnect PCM connector E (31P).
11. Turn the ignition switch to ON (II).
12. Reset the PCM with the HDS.
13. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-348529-S13364648212009112400000) ).
14. Turn the ignition switch to LOCK (0).
15. Turn the ignition switch to ON (II), and wait 10 seconds.
