Fuse-To-Components Index Acura RL II рестайлинг

Body Electrical 5 illustrations

Auxiliary Under-dash Fuse/Relay Box

Fuse Number	Amps	Wire Color	Component(s) or Circuit(s) Protected
31	7.5 A	BLU	Ignition switch (ST)
31	7.5 A	LT BLU	PCM (STS)
32	7.5 A	RED	Starter cut relay 1
32	7.5 A	PNK	PCM (STRLD)

AUXILIARY UNDER-DASH FUSE/RELAY BOX REFERENCE CHART

Scheme 66

Scheme 66

Scheme 66

Battery Terminal Fuse Box

Fuse Number	Amps	Wire Color	Component(s) or Circuit(s) Protected
34	50 A	BLK	Radiator fan control (RFC) unit
35			Not used

BATTERY TERMINAL FUSE BOX REFERENCE CHART

Scheme 67

Scheme 67

Scheme 67

Under-hood Fuse/Relay Box

Fuse Number	Amps	Component(s) or Circuit(s) Protected
1	15A	Left headlight (HID unit)
2	30 A	Relay control module. Rear window defogger coil
3	10A	Left headlight (High beam)
4	15A	Front parking lights, Dash light, License plate lights, Roof console lights, Taillights, Rear door ashtray lights. Seat heater switches light, Seat ventilation switch lights (1) , No. 7 (7.5 A) fuse in the passenger's under-dash fuse/relay box
5	10A	Right headlight (High beam)
6	15A	Right headlight (HID unit)
7	7.5 A	Relay control module
8	15A	PGM-FI main relay 1, Data link connector
8	15A	Via PGM-FI main relay 1: PGM-FI main relay 2, CKP sensor A/B, CMP sensor, Injectors, PCM, Throttle actuator control relay
9	30 A	Windshield wiper motor (via windshield wiper motor relay)
10	30 A	Headlight washer motor (via headlight washer relay) (1)
11	10A	Fog lights
12	7.5 A	A/C compressor clutch
13	15A	Brake lights, High mount brake light, Adaptive cruise control unit (via adaptive cruise control relay)
13	15A	Horns (via relay control module)
14	40 A	Rear window defogger, Noise condenser (via driver's under-dash fuse/relay box)
15	40 A	No. 5, No. 6, No. 7, No. 8 and No. 9 fuses in the driver's under-dash fuse/relay box
16	15A	Turn signal/hazard relay, MICU
17	30 A	VSA modulator-control unit
18	40 A	VSA modulator-control unit
19	40 A	No. 1, No. 2, No. 3 and No. 4 fuse in the driver's under-dash fuse/relay box
20	40 A	No. 12, No. 13, No. 14, No. 15, No. 16 and No. 17 fuse in the driver's under-dash fuse/relay box
21	40 A	Blower motor
22	120 A (BAT)	Battery, Power distribution
22	70 A (AS F/B)	Passenger's under-dash fuse/relay box
23	50 A (IG)	Ignition switch (BAT), Starter motor (via starter cut relay 1, 2)
23	50 A (P/W)	No. 24, No. 25, No. 26, No. 27 and No. 28 fuse in the driver's under-dash fuse/relay box. Power windows
(1) Canada models

(1)	Canada models

UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART

Scheme 68

Scheme 68

Scheme 68

Driver's Under-dash Fuse/Relay Box

Fuse Number	Amps	Component(s) or Circuit(s) Protected
1	15A	Throttle actuator control module relay (in the passenger's under-dash fuse/relay box)
2	15A	Ignition coil relay
2	15A	Ignition coils (via ignition coil relay)
3	10A	Daytime running lights control unit (USA models). Daytime running lights control relay (Canada models)
4	15A	Front A/F sensor (bank 2, sensor 1), Front SHO2S (bank 2, sensor 2), Rear A/F sensor (bank 1, sensor 1), Rear SHO2S (bank 1, sensor 2)
5	7.5 A	AcuraLink control unit (XM receiver), Audio unit, Navigation unit, XM receiver unit, HandsFreeLink control unit, Navigation display unit
6	7.5 A	Keyless access control unit, Footwell lights, Courtesy lights, Door inner handle lights. Door outer handle lights, Trunk lights, Individual map lights, Vanity mirror lights, Driver's MPCS unit, Front passenger's MPCS unit, Left and right rear power window switches, Driver's outer handle touch sensor, Front passenger's outer handle touch sensor
7	10A	Combination switch control unit, Gauge control module, Immobilizer control unit-receiver, Imoes unit, Driver's MPCS unit, Front passenger's MPCS unit, Power seat control unit, Power tilt/telescopic steering control unit, Navigation display unit. Navigation unit, Keyless access control unit. Ignition key light, Adaptive cruise control unit
7	10A	MICU
8	20 A	MICU
9	20 A	Accessory power socket relays
10	7.5 A	ODS unit, Passenger's airbag cutoff indicator, SRS unit
11	15A	Adaptive front lighting control unit. Power rear sunshade control unit, Windshield washer motor, Under-hood fuse/relay box
12	15A	Rear seat heater (via seat heater relay) (Canada models)
13	20 A	Front passenger's power seat (recline and rear up/down motors)
14	20 A	Driver's lumbar support motor, Power seat control unit (VMP1)
15	7.5 A	TPMS control unit
16	20 A	Power seat control unit (VMP2)
17	20 A	L Front passenger's lumbar support motor. Front passenger's power seat (slide and front up/down motors)
18	15A	Alternator, ELD, Engine mount control solenoid, EVAP canister purge valve, PCM, PCM (via brake pedal position switch), Steering angle sensor, VSA modulator-control unit
19	20 A	PCM, Keyless access control unit, Fuel pump (via PGM-FI main relay 2)
20	15A	Mass airflow (MAF) sensor/intake air temperature (IAT) sensor, PCM
21	10A	Seat ventilation, Automatic dimming inside mirror, Combination switch control unit, Driver's MPCS unit. Gauge control module, Imoes unit, Power seat control unit, Power tilt/telescopic steering control unit, Shift lock solenoid, Seat belt tension reducer solenoid, TPMS control unit
21	10A	AcuraLink control unit (XM receiver), Daytime running lights control unit (USA models), Navigation unit, Power steering control unit, Seat belt tension reducers, XM receiver unit, Under-hood fuse/relay box (control block)
22	10A	SRS unit
23	7.5 A	Radiator fan control (RFC) unit relay
23	7.5 A	A/F sensor relay
24	20 A	Left rear power window switch
25	20 A	Power tilt/telescopic steering control unit
26	20 A	Power tilt/telescopic steering control unit
27	30 A	Driver's MPCS unit
28	20 A	Moonroof motor/control unit
29	7.5 A	Adaptive front lighting control unit, Headlight leveling control unit (Without AFS) Power steering control unit, SH-AWD control unit, Adaptive cruise control (ACC) unit, Millimeter wave radar unit, Adaptive cruise control (ACC) relay
30	7.5 A	A/C compressor clutch relay, Blower motor relay, Climate control unit, In-car temperature sensor, Rear seat heater relay (Canada models), Rear window defogger relay, Seat heater relay
31	7.5 A	E-pretensioner unit
32	10A	AcuraLink control unit (XM receiver), Active noise cancellation unit, Audio unit, HandsFreeLink control unit, Navigation display unit, Key interlock solenoid, Microphone, Navigation unit, Shift lock solenoid, Keyless access control unit, XM receiver unit, Interface dial
32	10A	Accessory power socket relay, MICU

DRIVER'S UNDER-DASH FUSE/RELAY BOX REFERENCE CHART

Scheme 69

Scheme 69

Scheme 69

Passenger's Under-dash Fuse/Relay Box

Fuse Number	Amps	Component(s) or Circuit(s) Protected
1	30 A	SH-AWD control unit (via SH-AWD relay)
2	30 A	Audio amplifier
3	30 A	Front passenger's MPCS unit
4	30 A	E-pretensioner unit
5	20 A	Right rear power window switch
6	20 A	Seat ventilation control units (with seat ventilation), Seat heater (via seat heater relay)
7	7.5 A	Audio unit, AFS OFF/VSA OFF switch, Cable reel, Climate control unit, Console box light, Coin pocket light, Dash lights brightness controller, Navigation display unit, Hazard warning switch/passenger's airbag cutoff indicator, Glove box light, A/T gear position panel light
8	30 A	E-pretensioner unit
9	7.5 A	Climate control unit (via control motor relay). Control motor relay

PASSENGER'S UNDER-DASH FUSE/RELAY BOX REFERENCE CHART

Scheme 70

Scheme 70

Scheme 70
