Body Electrical (general Troubleshooting) — Electrical — Body Electrical

Scheme 43

Scheme 43: Special Tools

Tips and Precautions

Before Troubleshooting

Scheme 44

Scheme 44: Tips and Precautions

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Check applicable fuses in the appropriate fuse/relay box.
Check the battery for damage, state of charge, and clean and tight connections. NOTE: Do not quick-charge a battery unless the battery ground cable has been disconnected, otherwise you will damage the alternator diodes. Do not attempt to crank the engine with the battery ground cable loosely connected or you will severely damage the wiring. Handling Connectors Make sure the connectors are clean and have no loose wire terminals. Make sure multiple cavity connectors are packed with dielectric grease (except watertight connectors). All connectors have push-down release type locks (A). Some connectors have a clip on their side used to attach them to a mount bracket on the body or on another component. This clip has a pull type lock. Some mounted connectors cannot be disconnected unless you first release the lock and remove the connector from its mount bracket (A). Never try to disconnect connectors by pulling on their wires; pull on the connector halves instead. Always reinstall plastic covers. Before connecting connectors, make sure the terminals (A) are in place and not bent. Check for loose retainer (A) and rubber seals (B). The backs of some connectors are packed with dielectric grease. Add grease if necessary. If the grease is contaminated, replace it. Insert the connector all the way and make sure it is securely locked. Position wires so that the open end of the cover faces down. Handling Wires and Harnesses Secure wires and wire harnesses to the frame with their respective wire ties at the designated locations. Remove clips carefully; don't damage their locks (A). After installing harness clips, make sure the harness doesn't interfere with any moving parts. Keep wire harnesses away from exhaust pipes and other hot parts, from sharp edges of brackets and holes, and from exposed screws and bolts. Seat grommets in their grooves properly (A). Do not leave grommets distorted (B). Testing and Repairs Do not use wires or harnesses with broken insulation. Replace them or repair them by wrapping the break with electrical tape. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage in SRS wiring or terminals, replace the harness. After installing parts, make sure that no wires are pinched under them. When using electrical test equipment, follow the manufacturer's instructions and those described in this manual. If possible, insert the probe of the tester from the wire side (except waterproof connector). Use back probe adaptor 07TAZ-001020A. Refer to the instructions in the Honda Terminal Kit for identification and replacement of connector terminals.

Five-step Troubleshooting

Verify The Complaint Turn on all the components in the problem circuit to verify the clients complaint. Note the symptoms. Do not begin disassembly or testing until you have narrowed down the problem area.
Analyze The Schematic Look up the schematic for the problem circuit. Determine how the circuit is supposed to work by tracing the current paths from the power feed through the circuit components to ground. If several circuits fail at the same time, the fuse or ground is a likely cause. Based on the symptoms and your understanding of the circuit operation, identify one or more possible causes of the problem.
Isolate The Problem By Testing The Circuit Make circuit tests to check the diagnosis you made in step 2. Keep in mind that a logical, simple procedure is the key to efficient troubleshooting. Test for the most likely cause of failure first. Try to make tests at points that are easily accessible.
Fix The Problem Once the specific problem is identified, make the repair. Be sure to use proper tools and safe procedures.
Make Sure The Circuit Works Turn on all components in the repaired circuit in all modes to make sure you've fixed the entire problem. If the problem was a blown fuse, be sure to test all of the circuits on the fuse. Make sure no new problems turn up and the original problem does not recur.

Wire Color Codes

The following abbreviations are used to identify wire colors in the circuit schematics

WHT	White
YEL	Yellow
BLK	Black
BLU	Blue
GRN	Green
RED	Red
ORN	Orange
PNK	Pink
BRN	Brown
GRY	Gray
PUR	Purple
LT BLU	Light Blue
LT GRN	Light Green

WIRE COLOR CODES CHART

The wire insulation has one color or one color with another color stripe. The second color is the stripe.

Scheme 55

How to Check for DTCs with the Honda Diagnostic System (HDS)

Note. For specific operations, refer to the user's manual that cam with the Honda Diagnostic System (HDS). Make sure the HDS is loaded with the latest software.

Scheme 56

Scheme 56: How to Check for DTCs with the Honda Diagnostic System (HDS)

Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (A) located under the driver's side of the dashboard.
Turn the ignition switch to ON (II).
Make sure the HDS communicates with the vehicle, if it doesn't troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
Enter the BODY ELECTRICAL, then select the desired TEST MODE menu.
Check for DTCs with the HDS. NOTE: If the DTCs do not pertain to the selected menu, select the All DTC Check icon to view all Body Electrical DTCs.
If any DTCs are indicated, note them, and go to the indicated DTC troubleshooting.

Keyless Access System

Registration by the HDS is necessary when

Any of the remotes (A) are replaced.
All of the remotes (A) are replaced.
A new remote (A) is added.
New remotes (A) are added.
The keyless access control unit (B) is replaced.
The ignition switch control unit (C) is replaced.
The imoes unit (D) is replaced.
Deleting the registration of a lost remote(s).
The PCM is replaced.

Note. The keyless access control unit can store up to six remotes.

Scheme 57

Immobilizer System
