Cylinder Head Acura RDX I рестайлинг

Mechanical 146 illustrations ~9634 words

Scheme 72

Scheme 72: Special Tools
Scheme 72: Special Tools

Scheme 73

Scheme 73: Component Location Index
Scheme 73: Component Location Index

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Engine Compression Inspection

Note. After the inspection, you must reset the PCM. Otherwise, the PCM will continue to stop the fuel injectors from operating.

Scheme 76

Scheme 76: Engine Compression Inspection
Scheme 76: Engine Compression Inspection
  1. Warm up the engine to normal operating temperature (cooling fan comes on).
  2. Turn the ignition switch to LOCK (0).
  3. Connect the HDS to the DLC (see «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__how-to-use-the-hds-honda) ).
  4. Turn the ignition switch to ON (II).
  5. Make sure the HDS communicates with the vehicle and the PCM. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
  6. Select ALL INJECTORS STOP in the PGM-FI INSPECTION menu with the HDS.
  7. Turn the ignition switch to LOCK (0).
  8. Remove the four ignition coils and the four spark plugs (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  9. Attach the compression gauge to the spark plug hole.
  10. Step on the accelerator pedal to open the throttle fully, then crank the engine with the starter motor, and measure the compression. Compression Pressure: Above 930 kPa (9.5 kgf/cm 2 , 135 psi)
  11. Measure the compression on the remaining cylinders. Maximum Variation: Within 200 kPa (2.0 kgf/cm 2 , 28 psi)
  12. If the compression is not within specifications, perform a cylinder leak down test to determine the problem area. Then check the following items, and remeasure the compression: Incorrect valve clearance Confirmation of cam timing Damaged or worn cam lobs Damaged or worn valves and seats Damaged cylinder head gasket Damaged or worn piston rings Damaged or worn piston and cylinder bore
  13. Remove the compression gauge from the spark plug hole.
  14. Install the four spark plugs and the four ignition coils (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  15. Select the PCM reset (see «HDS CLEAR COMMAND»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__hds-clear-command) ) in the PGM-FI INSPECTION menu to cancel ALL INJECTORS STOP with the HDS.

VTEC Rocker Arm Test

Special Tools Required

  1. Air Pressure Regulator 07AAJ-PNAA101
  2. VTEC Air Adapter 07ZAJ-PNAA101 (2)
  3. VTEC Air Stopper 07ZAJ-PNAA200
  4. Air Joint Adapter 07ZAJ-PNAA300

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79
  1. Start the engine, and let it run for 5 minutes, then turn the ignition switch to LOCK (0).
  2. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  3. Set the No. 1 piston at top dead center (TDC) (see step 6 ).
  4. Verify that the intake primary rocker arm (A) move independently of the intake secondary rocker arm (B). If the intake primary rocker arm does not move, remove the primary and secondary rocker arms as an assembly and check that the pistons in the secondary and primary rocker arms move smoothly (see «ROCKER ARM AND SHAFT INSPECTION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ). If any rocker arm needs replacing, replace the primary and secondary rocker arms as an assembly, then retest. If the intake primary rocker arm moves freely, go to step 5.
  5. Repeat step 4 on the remaining intake primary rocker arms with each piston at TDC. When all the primary rocker arms pass the test, go to step 6.
  6. Check that the air pressure on the shop air compressor gauge indicates over 400 kPa (4.08 kgf/cm 2 , 58.0 psi).
  7. Inspect the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-clearance-adjustment) ).
  8. Remove the sealing bolt (A) from the relief hole, and install the VTEC air stopper (B).
  9. Remove the No. 2 and No. 3 camshaft holder bolts, and install the VTEC air adapters (C) finger-tight.
  10. Connect the air joint adapter (D) and air pressure regulator (E).
  11. Loosen the valve on the air pressure regulator, and apply the specified air pressure. Specified Air Pressure: 290 kPa (2.96 kgf/cm 2 , 42.1 psi) NOTE: If the rocker arm piston does not move after applying air pressure; move the primary or secondary rocker arm up and down manually by rotating the crankshaft clockwise.
  12. With the specified air pressure applied, move the intake primary rocker arm (A) for the No. 1 cylinder. The primary rocker arm and secondary rocker arm (B) should move together. If the intake secondary rocker arm does not move, remove the primary and secondary rocker arms as an assembly, and check that the pistons in the primary and secondary rocker arms move smoothly. If any rocker arm needs replacing, replace the primary and secondary rocker arms as an assembly, and test.
  13. Remove the air pressure regulator, the air joint adapter, the VTEC air adapters, and the VTEC air stopper.
  14. Tighten the camshaft holder mounting bolts to 22 N.m (2.2 kgf.m, 16 lbf.ft).
  15. Tighten the sealing bolt to 20 N.m (2.0 kgf.m, 14 lbf.ft).
  16. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).

Scheme 80

Scheme 80: VTC Actuator Inspection
Scheme 80: VTC Actuator Inspection

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83
  1. Remove the cam chain (see «CAM CHAIN REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-removal) ).
  2. Loosen the rocker arm adjusting screws (see step 2 ).
  3. Remove the camshaft holder (see step 3 ).
  4. Remove the intake camshaft.
  5. Check that the VTC actuator is locked by turning the VTC actuator counterclockwise. If it is not locked, turn the VTC actuator clockwise until it stops, then recheck it. If it is still not locked, replace the VTC actuator.
  6. Seal the retard holes (A) in the No. 1 camshaft journal with tape and a wire tie.
  7. Seal one of the advance holes (A) with tape.
  8. Apply air to the unsealed advance hole to release the lock.
  9. Check that the VTC actuator moves smoothly. If the VTC actuator does not move smoothly, replace the VTC actuator.
  10. Remove the wire tie, the tape, and adhesive residue from the No. 1 camshaft journal.
  11. Make sure the punch marks on the VTC actuator and the exhaust camshaft sprocket are facing up, then set the camshafts in the cylinder head (see step 6 ).
  12. Set the camshaft holders and cam chain guide B in place (see step 7 ).
  13. Tighten the camshaft holder bolts to the specified torque (see step 8 ).
  14. Hold the camshaft and turn the VTC actuator clockwise until you hear it click. Make sure to lock the VTC actuator by turning it.
  15. Install the cam chain (see «CAM CHAIN INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-installation) ).
  16. Adjust the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-clearance-adjustment) ).

Valve Clearance Adjustment

Special Tools Required

  1. Adjuster 07MAA-PR70110
  2. Locknut Wrench 07MAA-PR70120

Note. Connect the HDS to the DLC (see HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM) ), and monitor the ECT sensor 1. Adjust the valve clearance only when the ECT is less than 100°F (38°C).

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90
  1. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Set the No. 1 piston at top dead center (TDC). The punch mark (A) on the VTC actuator and the punch mark (B) on the exhaust camshaft sprocket should be at the top. Align the TDC marks (C) on the VTC actuator and exhaust camshaft sprocket.
  3. Select the correct feeler gauge for the valve clearance you are going to check. Valve Clearance Intake: 0.21-0.25 mm (0.009-0.009 in) Exhaust: 0.28-0.32 mm (0.011-0.012 in)
  4. Insert the feeler gauge (A) between the adjusting screw (B) and the end of the valve stem on the No. 1 cylinder, and slide it back and forth; you should feel a slight amount of drag.
  5. If you feel too much or too little drag, loosen the locknut with the locknut wrench and the adjuster, and turn the adjusting screw until the drag on the feeler gauge is correct.
  6. Tighten the locknut to the specified torque and recheck the clearance. Repeat the adjustment if necessary. Specified Torque Intake: 7 x 0.75 mm 20 N.m (2.0 kgf.m, 14 lbf.ft) Apply engine oil to the nut threads. Exhaust: 7 x 0.75 mm 14 N.m (1.4 kgf.m, 10 lbf.ft) Apply engine oil to the nut threads.
  7. Rotate the crankshaft 180° clockwise (camshaft pulley turns 90°).
  8. Check and, if necessary, adjust the valve clearance on the No. 3 cylinder.
  9. Rotate the crankshaft 180° clockwise (camshaft pulley turns 90°).
  10. Check and, if necessary, adjust the valve clearance on the No. 4 cylinder.
  11. Rotate the crankshaft 180° clockwise (camshaft pulley turns 90°).
  12. Check and, if necessary, adjust the valve clearance on the No. 2 cylinder.
  13. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).

Crankshaft Pulley Removal and Installation

Special Tools Required

  1. Holder Handle 07JAB-001020B
  2. Crankshaft Pulley Holder 07AAB-RJAA100
  3. Socket, 19 mm 07JAA-001020A or equivalent

Scheme 91

Scheme 91: Removal
Scheme 91: Removal
  1. Raise the vehicle on the lift.
  2. Remove the right front wheel.
  3. Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  4. Remove the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  5. Hold the pulley with the holder handle (A) and the holder attachment (B).
  6. Remove the bolt with a socket, 19 mm (C) and a breaker bar, then remove the crankshaft pulley.

Scheme 92

Scheme 92: Installation
Scheme 92: Installation

Scheme 93

Scheme 93
Scheme 93
  1. Remove any oil and clean the crankshaft pulley (A), the crankshaft (B), the bolt (C), and the washer (D). Lubricate with new engine oil as shown in illustration.
  2. Install the crankshaft pulley, and hold the pulley with the holder handle (A) and the crankshaft pulley holder (B).
  3. Torque the bolt to 50 N.m (5.0 kgf.m, 36 lbf.ft) with a torque wrench and a 19 mm socket (C). If the pulley bolt or crankshaft are new, torque the bolt to 180 N.m (18.0 kgf.m, 133 lbf.ft), then loosen the bolt and torque it to 50 N.m (5.0 kgf.m, 36 lbf.ft).
  4. Tighten the pulley bolt an additional 90°.
  5. Install the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  6. Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  7. Install the right front wheel.

Cam Chain Removal

Note. Keep the cam chain away from magnetic fields.

Scheme 94

Scheme 94: Cam Chain Removal
Scheme 94: Cam Chain Removal

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. Remove the front wheels.
  2. Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  3. Remove the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  4. Turn the crankshaft so its white mark (A) line up with the pointer (B).
  5. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  6. Check the No. 1 piston at top dead center (TDC). The punch mark (A) on the VTC actuator and the punch mark (B) on the exhaust camshaft sprocket should be at the top. Align the TDC marks (C) on the VTC actuator and exhaust camshaft sprocket.
  7. Remove the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#vtecvtc) ).
  8. Remove the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__crankshaft-pulley-removal-and-installation) ).
  9. Support the engine with a jack and a wood block under the oil pan.
  10. Remove the torque rod stiffener (A) and upper torque rod (B).
  11. Remove the ground cable (A), then remove the side engine mount bracket (B).
  12. Remove the water bypass pipe mounting bolt (A), then remove the engine mount bracket (B).
  13. Remove the cam chain case.
  14. Loosely install the crankshaft pulley.
  15. Turn the crankshaft counterclockwise to compress the cam chain auto-tensioner.
  16. Rotate the crankshaft counterclockwise to align the holes on the lock (A) and the cam chain auto-tensioner (B), then insert a 1.2 mm (3/64 in) diameter pin (C) into the holes. Turn the crankshaft clockwise to secure the pin. NOTE: If the holes in the lock and the cam chain auto-tensioner do not align, continue to rotate the crankshaft counterclockwise until the holes align, then install the pin.
  17. Remove the cam chain auto-tensioner.
  18. Remove the cam chain guide B.
  19. Remove the cam chain guide A and tensioner arm (B). Inspect the tensioner and the guide, and replace then if needed.
  20. Remove the cam chain.

Cam Chain Installation

Special Tools Required

Camshaft Lock Pin Set 07AAB-RWCA120

Note. Keep the cam chain away from magnetic fields. Before doing this procedure, check that the VTC actuator is locked by turning the VTC actuator counterclockwise. If not locked, turn the VTC actuator clockwise until it stops, then recheck it. If it is still not locked, replace the VTC actuator.

Scheme 105

Scheme 105: Cam Chain Installation
Scheme 105: Cam Chain Installation

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109

Scheme 110

Scheme 110
Scheme 110

Scheme 111

Scheme 111
Scheme 111

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121

Scheme 122

Scheme 122
Scheme 122

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126
  1. Set the crankshaft to top dead center (TDC). Align the TDC mark (A) on the crankshaft sprocket with the pointer (B) on the engine block.
  2. Set the camshafts to TDC. The punch mark (A) on the VTC actuator and the punch mark (B) on the exhaust camshaft sprocket should be at the top. Align the TDC marks (C) on the VTC actuator and the exhaust camshaft sprocket.
  3. To hold the intake camshaft, insert a camshaft lock pin set (A) into the maintenance hole in the CMP pulse plate A (B) and through the No. 5 rocker shaft holder (C).
  4. To hold the exhaust camshaft, insert a camshaft lock pin (A) into the maintenance hole in the CMP pulse plate B (D) and through the No. 5 rocker shaft holder (C).
  5. Install the cam chain on the crankshaft sprocket with the center of the two colored link plates (A) aligned with the mark (B) on the crankshaft sprocket.
  6. Install the cam chain on the VTC actuator and the exhaust camshaft sprocket with the punch marks (A) aligned with the center of the three colored link plates (B).
  7. Apply new engine oil to the threads of the cam chain tensioner mounting bolt.
  8. Install the cam chain guide A and tensioner arm (B).
  9. Compress the cam chain auto-tensioner when replacing the cam chain. Remove the pin or lock pin (A) from the cam chain auto-tensioner that was installed during removal. Turn the plate (B) counterclockwise, to release the lock, then press the rod (C), and set the first cam (D) to the first edge of the rack (E). Insert the 1.2 mm (3/64 in) diameter pin or lock pin into the holes (F). NOTE: If the chain tensioner is not set up as described, the tensioner will become damaged.
  10. Install the cam chain auto-tensioner.
  11. Install the cam chain guide B.
  12. Remove the pin or lock pin from the cam chain auto-tensioner.
  13. Remove the camshaft lock pin set.
  14. Check the cam chain case oil seal for damage. If the oil seal is damaged, replace the cam chain case oil seal (see «CAM CHAIN CASE OIL SEAL INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-case-oil-seal-installation) ).
  15. Remove all of the old liquid gasket from the cam chain case mating surfaces, the bolts, and the bolt holes.
  16. Clean and dry the cam chain case mating surfaces.
  17. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) to the engine block mating surfaces of the cam chain case, and to the inside edge of the threaded bolt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line (A). If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  18. Apply liquid gasket to the engine block upper surface contact areas (B) on the cam chain case and lower block upper surface contact areas (C) on the cam chain case. NOTE: Apply about 11 mm (0.43 in) diameter and about 3 mm (0.12 in) thickness of liquid gasket to areas (B) and (C).
  19. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) to the oil pan mating surface of the cam chain case, and to the inside edge of the threaded bolt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line (A). If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  20. Install the new O-ring (A) on the cam chain case. Set the edge of the cam chain case (B) to the edge of the oil pan (C), then install the cam chain case on the engine block (D). Wipe off the excess liquid gasket on the oil pan and the cam chain case mating area. NOTE: When installing the cam chain case, do not slide the bottom surface onto the oil pan mounting surface. Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cam chain case.
  21. Install the engine mount bracket (A), then install the water bypass pipe mounting bolt (B).
  22. Install the side engine mount bracket (A), then loosely tighten the side engine mount bracket mounting new bolt and nut (B), and loosely tighten the side engine mount mounting bolt (C).
  23. Install the ground cable (D).
  24. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  25. Loosen the transmission mount mounting bolt and nuts (A).
  26. Raise the lift to full height.
  27. Loosen the lower torque rod mounting bolt (A).
  28. Lower the vehicle on the lift.
  29. Tighten the side engine mount bracket mounting bolts and nut, and the side engine mount mounting bolt.
  30. Tighten the transmission mount mounting bolt and nuts.
  31. Raise the vehicle on the lift.
  32. Tighten the lower torque rod mounting bolt.
  33. Lower the vehicle on the lift.
  34. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  35. Install the upper torque rod (A) and the torque rod stiffener (B), and tighten the new stiffener mounting bolts (C), then tighten the new upper torque rod mounting bolts in the numbered sequence shown in illustration.
  36. Install the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__crankshaft-pulley-removal-and-installation) ).
  37. Install the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#vtecvtc) ).
  38. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  39. Install the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  40. Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  41. Install the front wheels.
  42. Do the CKP pattern clear/CKP learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems) ).

Scheme 127

Scheme 127: Removal
Scheme 127: Removal

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130
  1. Remove the cam chain case cover.
  2. Turn the crankshaft counterclockwise to compress the cam chain auto-tensioner.
  3. Rotate the crankshaft counterclockwise to align the holes on the lock (A) and the cam chain auto-tensioner (B), then insert a 1.2 mm (3/64 in) diameter pin (C) into the holes. Turn the crankshaft clockwise to secure the pin. NOTE: If the holes in the lock and the cam chain auto-tensioner do not align, continue to rotate the crankshaft counterclockwise until the holes align, then install the pin.
  4. Remove the cam chain auto-tensioner.

Scheme 131

Scheme 131: Installation
Scheme 131: Installation

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133

Scheme 134

Scheme 134
Scheme 134
  1. Install the cam chain auto-tensioner. NOTE: Check the cam chain auto-tensioner cam position. If the position is not aligned, set the first cam to the first edge of the rack (see step 9 ).
  2. Remove the pin or lock pin from the cam chain auto-tensioner.
  3. Remove all of the old liquid gasket from the cam chain case cover mating surfaces, the bolts, and the bolt holes.
  4. Clean and dry the cam chain case cover mating surfaces.
  5. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) to the cam chain case mating surface of the cam chain case cover and to the inside edge of the threaded belt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line (A). If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  6. Install the cam chain case cover. NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cam chain case.

Cam Chain Case Oil Seal Installation

Special Tools Required

  1. Driver Handle, 15 x 135L 07749-0010000
  2. Bearing Driver Attachment, 52 x 55 mm 07746-0010400

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136
  1. Clean and dry the crankshaft oil seal housing.
  2. Apply a light coat of new engine oil to the lip of the cam chain case oil seal.
  3. Use the driver handle, 15 x 135L and bearing driver attachment, 52 x 55 mm to drive in the new oil seal squarely into the cam chain case to the specified installed height.
  4. Measure the distance between the cam chain case surface and oil seal. Oil Seal Installed Height: 33.0-33.7 mm (1.299-1.326 in)

Cam Chain Inspection

Special Tools Required

Cam Chain Inspection Gauge 07AAJ-RWCA100

Scheme 137

Scheme 137: Cam Chain Inspection
Scheme 137: Cam Chain Inspection

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139
  1. Remove the front wheels.
  2. Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  3. Remove the four ignition coils and the four spark plugs (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  4. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  5. Rotate the crankshaft pulley two turns clockwise.
  6. Set the No. 1 piston at top dead center (TDC). The punch mark (A) on the VTC actuator and the punch mark (B) on the exhaust camshaft sprocket should be at the top. Align the TDC marks (C) on the VTC actuator and exhaust camshaft sprocket.
  7. Measure the clearance between the cam chain (A) and the tensioner arm (B) with the cam chain inspection gauge. If the clearance is OK, Go to step 22 . If the clearance is more than the service limit. Go to step 8. Chain-to-Arm Clearance Service Limit: MIL on with P0341: 4.3 mm Without MIL: 5.5 mm
  8. Remove the cam chain (see «CAM CHAIN REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-removal) ), and check the teeth on the crankshaft sprocket, the VTC actuator, and the exhaust camshaft sprocket for wear and damage. If any of them are worn or damaged, replace if necessary.
  9. Check the oil passage on the cam chain auto-tensioner for clogs. If the cam chain auto-tensioner is clogged, replace it.
  10. Remove the power steering pump. Do not disconnect the power steering hoses from the pump (see step 19 under «PUMP REPLACEMENT»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#hydraulic-power-steering-components) ).
  11. Attach the universal eyelet to the drive belt auto-tensioner (see step 54 under «ENGINE REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#engine-assembly__engine-removal) ).
  12. Remove the top corner clip from the front grill on both sides. Place the engine support mount pads over the hood edge cushions, and align the pins with the clip hole. Remove the lids from both sides of the cowl cover. Install the engine support hanger (AAR-T-1256), then attach the hook to the universal eyelet. Tighten the wing nut by hand to lift and support the engine/transmission (see step 6 under «OIL PUMP CHAIN REPLACEMENT»(/acura/rdx/i-2009-2012/remont/lubrication-system/#engine-lubrication__oil-pump-chain-replacement) ).
  13. Remove the oil pan (see «CONNECTING ROD JOURNAL CODE LOCATION»(/acura/rdx/i-2009-2012/remont/mechanical/#engine-block) ).
  14. Measure the length of the oil pump chain auto-tensioner rod. Oil Pump Chain Auto-Tensioner Rod Length Service Limit: 13.0 mm (0.512 in)
  15. If the length is over the service limit, replace the oil pump chain (see «OIL PUMP CHAIN REPLACEMENT»(/acura/rdx/i-2009-2012/remont/lubrication-system/#engine-lubrication__oil-pump-chain-replacement) ). When replacing, check the teeth on the crankshaft sprocket and the oil pump sprocket for wear and damage. If any of them are worn or damaged, replace if necessary.
  16. Check the oil passage on the oil pump chain auto-tensioner for clogs. If the cam chain auto-tensioner is clogged, replace it.
  17. Install the oil pan (see «OIL PAN INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#engine-block) ).
  18. Support the engine with a jack and a wood block under the oil pan.
  19. Remove the special tools from the engine and vehicle.
  20. Install the new cam chain (see «CAM CHAIN INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-installation) ).
  21. Install the power steering pump (see step 39 under «PUMP REPLACEMENT»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#hydraulic-power-steering-components) ).
  22. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  23. Install the four spark plugs and the four ignition coils (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  24. Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  25. Install the front wheels.

Scheme 140

Scheme 140: CKP Pulse Plate Replacement
Scheme 140: CKP Pulse Plate Replacement
  1. Remove the front wheels.
  2. Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  3. Remove the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  4. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  5. Set the No. 1 piston at top dead center (TDC). The punch mark on the VTC actuator and the punch mark on the exhaust camshaft sprocket should be at the top. Align the TDC marks on the VTC actuator and exhaust camshaft sprocket (see step 6 ).
  6. Remove the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#vtecvtc) ).
  7. Remove the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__crankshaft-pulley-removal-and-installation) ).
  8. Support the engine with a jack and a wood block under the oil pan.
  9. Remove the torque rod stiffener and the upper torque rod (see step 10 ).
  10. Remove the ground cable, then remove the side engine mount bracket (see step 11 ).
  11. Remove the engine mount bracket (see step 12 ).
  12. Remove the cam chain case (see step 13 ).
  13. Remove the CKP pulse plate.
  14. Install the CKP pulse plate.
  15. Check the cam chain case oil seal for damage. If the oil seal is damaged, replace the cam chain case oil seal (see «CAM CHAIN CASE OIL SEAL INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-case-oil-seal-installation) ).
  16. Remove all of the old liquid gasket from the cam chain case mating surfaces, bolt, and bolt holes.
  17. Clean and dry the cam chain case mating surfaces.
  18. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) evenly to the engine block mating surface of the cam chain case. Install the component within 5 minutes of applying the liquid gasket (see step 17 ). NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line. If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  19. Apply liquid gasket to the engine block upper surface contact areas on the cam chain case and lower block upper surface contact areas on the cam chain case (see step 18 ). NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line. If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  20. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) evenly to the oil pan mating surface of the cam chain case. Install the component within 5 minutes of applying the liquid gasket (see step 19 ). NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line. If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  21. Install the new O-ring on the cam chain case. Set the edge of the cam chain case to the edge of the oil pan, then install the cam chain case on the engine block (see step 20 ). Wipe off the excess liquid gasket on the oil pan and chain case mating area. NOTE: When installing the cam chain case, do not slide the bottom surface onto the oil pan mounting surface. Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cam chain case.
  22. Install the engine mount bracket (see step 21 ).
  23. Install the side engine mount bracket (see step 22 ).
  24. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  25. Loosen the transmission mount mounting bolt and nuts (see step 25 ).
  26. Raise the vehicle on the lift.
  27. Loosen the lower torque rod mounting bolt (see step 27 ).
  28. Lower the vehicle on the lift.
  29. Tighten the side engine mount mounting bolts and nut (see step 29 ).
  30. Tighten the transmission mount mounting bolt and nuts (see step 30 ).
  31. Raise the vehicle on the lift.
  32. Tighten the lower torque rod mounting bolt (see step 32 ).
  33. Lower the vehicle on the lift.
  34. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  35. Install the upper torque rod and torque rod stiffener (see step 35 ).
  36. Install the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__crankshaft-pulley-removal-and-installation) ).
  37. Install the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#vtecvtc) ).
  38. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  39. Install the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  40. Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
  41. Install the front wheels;.
  42. Do the CKP pattern clear/CKP learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems) ).

Scheme 141

Scheme 141: Cylinder Head Cover Removal
Scheme 141: Cylinder Head Cover Removal

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144

Scheme 145

Scheme 145
Scheme 145
  1. Remove the charge air cooler (see «REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  2. Remove the fuel injector cover.
  3. Remove the four ignition coils (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  4. Remove the power steering hose bracket (A), the breather hose (B), and the dipstick (C).
  5. Remove the bracket mounting bolts (D) from the cylinder head cover.
  6. Disconnect the rocker arm oil control solenoid connector (A), the rocker arm oil pressure switch connector (B), and the VTC oil control solenoid valve connector (C), then remove the harness clamp (D).
  7. Disconnect the A/F sensor connector (A), the oil pressure switch connector (B), and the CKP sensor connector (C), then remove the harness clamps (D).
  8. Remove the cylinder head cover.

Scheme 146

Scheme 146: Cylinder Head Cover Installation
Scheme 146: Cylinder Head Cover Installation

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148

Scheme 149

Scheme 149
Scheme 149

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153
  1. Check the spark plug seals for damage. If any seal is damaged, replace it.
  2. Thoroughly clean the head cover gasket and the groove of the cylinder head cover. NOTE: Check and if necessary, replace the head cover gasket.
  3. Install a head cover gasket (A) in the groove of the cylinder head cover (B). Make sure the head cover gasket is seated securely.
  4. Remove all of the old liquid gasket from the rocker shaft holder and the cylinder head.
  5. Clean the head cover contacting surfaces with a shop towel.
  6. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) on the cam chain case (A) and the No. 5 rocker shaft holder mating areas (B). Install the component within 5 minutes of applying the liquid gasket. NOTE: If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  7. Set the spark plug seals (A) on the spark plug tubes. Place the cylinder head cover (B) on the cylinder head, then slide the cover slightly back and forth to seat the head cover gasket.
  8. Inspect the cover washers (C). Replace any washer that is damaged or deteriorated.
  9. Tighten the bolts in three steps. In the final step torque all bolts, in sequence, to 12 N.m (1.2 kgf.m, 9 lbf.ft). NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the head cover.
  10. Connect the A/F sensor connector (A), the oil pressure switch connector (B), and the CKP sensor connector (C), then install the harness clamps (D).
  11. Connect the rocker arm oil control solenoid connector (A), the rocker arm oil pressure switch connector (B), and the VTC oil control solenoid valve connector (C), then install the harness clamp (D).
  12. Install the power steering hose bracket (A), the breather hose (B), and the dipstick (C).
  13. Install the bracket mounting bolts (D) to the cylinder head cover.
  14. Install the four ignition coils (see «IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).
  15. Install the fuel injector cover.
  16. Install the charge air cooler (see «INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).

Note. Use fender covers to avoid damaging painted surfaces. To avoid damage, unplug the wiring connectors carefully while holding the connector portion. Connect the HDS to the DLC (see HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM) ), and monitor the ECT sensor 1. To avoid damaging the cylinder head, wait until the ECT drops below 100°F (38°C) before loosening the cylinder head bolts. Mark all wiring and hoses to avoid misconnection. Also, be sure that they do not contact other wiring or hoses, or interfere with any other parts.

Scheme 154

Scheme 154: Cylinder Head Removal
Scheme 154: Cylinder Head Removal

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157

Scheme 158

Scheme 158
Scheme 158
  1. Relieve fuel pressure (see «FUEL PRESSURE RELIEVING»(/acura/rdx/i-2009-2012/remont/fuel-system/#fuel-supply-system__fuel-pressure-relieving) ).
  2. Drain the engine coolant (see «COOLANT CHECK»(/acura/rdx/i-2009-2012/remont/cooling-fan/#engine-cooling-system) ).
  3. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  4. Remove the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  5. Remove the intake manifold (see «REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  6. Remove the exhaust manifold (see «REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  7. Remove the engine wire harness connectors and wire harness clamps from the cylinder head. ECT sensor 1 connector CMP sensor A (Intake) connector CMP sensor B (Exhaust) connector EVAP canister purge valve connector
  8. Remove the quick-connect fitting cover (A), then disconnect the fuel feed hose (B) (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(/acura/rdx/i-2009-2012/remont/fuel-system/#fuel-supply-system__fuel-linequick-connect-fitting-removal) ).
  9. Disconnect the EVAP canister hose (A), the brake booster vacuum hose (B) and the vacuum hose (C).
  10. Remove the two bolts (A) securing the EVAP canister purge control valve mounting bracket, then remove the harness clamps (B).
  11. Disconnect the upper radiator hose (A), the heater hose (B), and the water bypass hose (C).
  12. Remove the cam chain (see «CAM CHAIN REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-removal) ).
  13. Remove the rocker arm assembly (see «ROCKER ARM ASSEMBLY REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  14. Remove the cylinder head bolts. To prevent warpage, loosen the bolts in sequence 1/3 turn at a time; repeat the sequence Until all bolts are loosened.
  15. Remove the cylinder head.

Scheme 159

Scheme 159: CMP Pulse Plate A Replacement
Scheme 159: CMP Pulse Plate A Replacement

Scheme 160

Scheme 160
Scheme 160
  1. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Remove the CMP sensor A (see «CMP SENSOR A REPLACEMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#vtecvtc) ).
  3. Hold the camshaft with an open-end wrench, then loosen the bolt.
  4. Remove the CMP pulse plate A.
  5. Install the CMP pulse plate A in the reverse order of removal.

Scheme 161

Scheme 161: CMP Pulse Plate B Replacement
Scheme 161: CMP Pulse Plate B Replacement

Scheme 162

Scheme 162
Scheme 162
  1. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Remove the CMP sensor B (see «CMP SENSOR B REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system) ).
  3. Hold the camshaft with an open-end wrench, then loosen the bolt.
  4. Remove the CMP pulse plate B.
  5. Install the CMP pulse plate B in the reverse order of removal.

Scheme 163

Scheme 163: VTC Actuator, Exhaust Camshaft Sprocket Replacement
Scheme 163: VTC Actuator, Exhaust Camshaft Sprocket Replacement

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168

Scheme 169

Scheme 169
Scheme 169

Scheme 170

Scheme 170
Scheme 170
  1. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Hold the camshaft with an open-end wrench, then loosen the VTC actuator mounting bolt and the exhaust camshaft sprocket mounting bolt. NOTE: Do not remove the VTC actuator and the exhaust camshaft sprocket mounting bolts.
  3. Set the No. 1 piston at top dead center (TDC). The punch mark (A) on the VTC actuator and the punch mark (B) on the exhaust camshaft sprocket should be at the top. Align the TDC marks (C) on the VTC actuator and the exhaust camshaft sprocket.
  4. Remove the cam chain case cover.
  5. Rotate the crankshaft counterclockwise and align the holes on the lock (A) and the cam chain auto-tensioner (B), then insert a 1.2 mm (3/64 in) diameter pin or lock pin (C) into the holes.
  6. Turn the crankshaft clockwise to secure the pin and the TDC on the No. 1 cylinder.
  7. Loosen the rocker arm adjusting screws (see step 2 ).
  8. Remove the camshaft holder bolts (see step 3 ).
  9. Remove the five camshaft holders and cam chain guide B.
  10. Carefully tip up the intake camshaft on the transmission side of the engine until there is enough slack in the chain to lift the chain off of the VTC gear.
  11. Remove the intake and exhaust camshafts while keeping some tension on the cam chain.
  12. Secure the cam chain to the A/C compressor suction hose or the power steering hose with the wire tie to prevent the chain from falling down into the cam chain case.
  13. Remove the VTC actuator and the exhaust camshaft sprocket.
  14. Install the VTC actuator and the exhaust camshaft sprocket. NOTE: Install the VTC actuator while in the unlock position.
  15. Apply new engine oil to the threads of the VTC actuator and the exhaust camshaft sprocket mounting bolts, then loosely install them.
  16. Turn the VTC actuator clockwise until you hear it clock. Make sure to lock the VTC actuator by turning it.
  17. Remove the wire tie while keeping light tension on the cam chain.
  18. Slide the intake and exhaust camshafts in at an angle to allow the cam chain to slip over the VTC actuator's teeth and the exhaust sprocket's teeth.
  19. Line up the marks made in step 3 for each cam.
  20. Apply new engine oil to the camshaft journals and lobes on both cams, and reinstall the five camshaft holders and cam chain guide B in place.
  21. Tighten the camshaft holder bolts to the specified torque (see step 8 ).
  22. Hold the camshaft with an open-end wrench, then tighten the bolts. Specified Torque VTC Actuator Mounting Bolt: 12x1.25 mm 113 N.m (11.5 kgf.m, 83 lbf.ft) Exhaust Camshaft Sprocket Mounting Bolt: 10 x 1.25 mm 72 N.m (7.3 kgf.m, 53 lbf.ft)
  23. Remove the pin or lock pin from the cam chain auto-tensioner.
  24. Remove all of the old liquid gasket from the cam chain case cover mating surfaces, the bolts, and the bolt holes.
  25. Clean and dry the cam chain case cover mating surfaces.
  26. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) to the cam chain case mating surface of the cam chain case cover and to the inside edge of the threaded belt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line (A). If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  27. Install the cam chain case cover. NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cam chain case.
  28. Adjust the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-clearance-adjustment) ).
  29. Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).

Scheme 171

Scheme 171: Cylinder Head Inspection for Warpage
Scheme 171: Cylinder Head Inspection for Warpage
  1. Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Inspect the camshaft (see «CAMSHAFT INSPECTION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__camshaft-inspection) ).
  3. Check the cylinder head for warpage. Measure along the edges, and across the center. If warpage is less than 0.05 mm (0.002 in), cylinder head resurfacing is not required. Maximum resurface limit to the cylinder head height standard as shown in illustration. Cylinder Head Warpage Standard (New): 0.0S mm (0.002 in) max. Cylinder Head Height Standard (New): 103.95-104.05 mm (4.093-4.096 in)

Scheme 172

Scheme 172: Rocker Arm Assembly Removal
Scheme 172: Rocker Arm Assembly Removal

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174
  1. Remove the cam chain (see «CAM CHAIN REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-removal) ).
  2. Loosen the locknuts and the rocker arm adjusting screws (A).
  3. Remove the camshaft holder bolts. To prevent damaging the camshafts, loosen the bolts, in sequence, two turns at a time. NOTE: Bolt (1) is not on all engines.
  4. Remove the cam chain guide B, the camshaft holders, and the camshafts.
  5. Insert the bolts (A) into the rocker shaft holder, then remove the rocker arm assembly (B).

Rocker Arm and Shaft Disassembly/Reassembly

Note. Identify parts as they are removed so they can be reinstalled in their original locations. Inspect the rocker arm shaft and rocker arms (see ROCKER ARM AND SHAFT INSPECTION ). If reused, the rocker arms must be installed in their original locations. When removing, or installing the rocker arm assembly, do not remove the camshaft holder bolts. The bolts will keep the holders and rocker arms on the shaft. Bundle the rocker arms with rubber bands to keep them together as a set, and remove the bands after the rocker arms have been installed. Prior to reassembling, clean all the parts in solvent, dry them, and apply new engine oil to all the contact points. When replacing the intake rocker arm assembly, remove the fastening hardware from the new intake rocker arm assembly.

Scheme 175

Scheme 175: Rocker Arm and Shaft Disassembly/Reassembly
Scheme 175: Rocker Arm and Shaft Disassembly/Reassembly

Scheme 176

Scheme 176: Rocker Arm and Shaft Inspection
Scheme 176: Rocker Arm and Shaft Inspection

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179
  1. Remove the rocker arm assembly (see «ROCKER ARM ASSEMBLY REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Disassemble the rocker arm assembly (see «ROCKER ARM AND SHAFT DISASSEMBLY/REASSEMBLY»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__rocker-arm-and-shaft-disassemblyreassembly) ).
  3. Measure the diameter of the shaft at the first rocker location.
  4. Zero the gauge (A) to the shaft diameter.
  5. Measure the inside diameter of the rocker arm, and check it for an out-of-round condition. Rocker Arm-to-Shaft Clearance Standard (New): Intake: 0.025-0.052 mm (0.00098-0.00205 in) Exhaust: 0.018-0.056 mm (0.00071-0.00220 in) Service Limit: Intake: 0.08 mm (0.0031 in) Exhaust: 0.08 mm (0.0031 in)
  6. Repeat for all rockers and both shafts. If the clearance is over the limit, replace the rocker shaft and all over-tolerance rocker arms. If any intake rocker arm needs replacement, replace all rocker arms in that set (primary and secondary). VTEC Rocker Arms
  7. Inspect the rocker arm pistons (A). Slide them into the rocker arms. If they do not move smoothly, replace the rocker arm set. NOTE: Apply new engine oil to the rocker arm pistons when reassembling.
  8. Reassemble the rocker arm assembly (see «ROCKER ARM AND SHAFT DISASSEMBLY/REASSEMBLY»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__rocker-arm-and-shaft-disassemblyreassembly) ).
  9. Install the rocker arm assembly (see «ROCKER ARM ASSEMBLY INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).

Camshaft Inspection

Note. Do not rotate the camshaft during inspection.

Scheme 180

Scheme 180: Camshaft Inspection
Scheme 180: Camshaft Inspection

Scheme 181

Scheme 181
Scheme 181

Scheme 182

Scheme 182
Scheme 182

Scheme 183

Scheme 183
Scheme 183

Scheme 184

Scheme 184
Scheme 184
  1. Remove the rocker arm assembly (see «ROCKER ARM ASSEMBLY REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Put the rocker shaft holders, the camshaft, and the camshaft holders on the cylinder head, then tighten the bolts in sequence, to the specified torque. NOTE: If the engine does not have bolt (2)1, skip it and continue the torque sequence. Specified Torque 8 x 1.25 mm 22 N.m (2.2 kgf.m, 16 lbf.ft) 6 x 1.0 mm 12 N.m (1.2 kgf.m, 8.8 lbf.ft) 6 x 1.0 mm Bolts: (2)1, (2)2, (2)3
  3. Seat the camshaft by pushing it away from the camshaft pulley end of the cylinder head.
  4. Zero the dial indicator against the end of the camshaft. Push the camshaft back and forth and read the end play. If the end play is beyond the service limit, replace the cylinder head and recheck. If it is still beyond the service limit, replace the camshaft. Camshaft End Play Standard (New): 0.05-0.20 mm (0.0020-0.0079 in) Service Limit: 0.4 mm (0.016 in)
  5. Loosen the camshaft holder bolts two turns at a time, in a crisscross pattern. Then remove the camshaft holders from the cylinder head.
  6. Lift the camshafts out of the cylinder head, and wipe them clean, then inspect the lift ramps. Replace the camshaft if any lobes are pitted, scored, or excessively worn.
  7. Clean the camshaft journal surfaces in the cylinder head, then set the camshafts back in place. Place a plastigage strip across each journal.
  8. Install the camshaft holders, then tighten the bolts to the specified torque as shown in step 2 .
  9. Remove the camshaft holders. Measure the widest portion of plastigage on each journal. If the camshaft-to-holder clearance is within the service limits, go to step 11 . If the camshaft-to-holder clearance is beyond the service limit, and the camshaft has been replaced, replace the cylinder head. If the camshaft-to-holder clearance is beyond the service limit, and the camshaft has not been replaced, go to step 10. Camshaft-to-Holder Oil Clearance Standard (New): No. 1 Journal: 0.030-0.069 mm (0.00118-0.00272 in) No. 2, 3, 4, 5 Journals: 0.060-0.099 mm (0.00236-0.00390 in) Service Limit: 0.15 mm (0.0059 in)
  10. Check the total runout with the camshaft supported on V-blocks. If the total runout of the camshaft is within the standard, replace the cylinder head. If the total runout is beyond the standard, replace the camshaft, and recheck the camshaft-to-holder oil clearance. If the oil clearance is still out of tolerance, replace the cylinder head. Camshaft Total Runout Standard (New): 0.03 mm (0.0012 in) max.
  11. Measure cam lobe height. CAM LOBE HEIGHT STANDARD (NEW) INTAKE EXHAUST PRI 33.925 mm (1.33563 in) 34.092 mm (1.34220 in) SEC 29.638 mm (1.16685 in) PRI: Primary SEC: Secondary C/C: Cam Chain

Valve, Spring, and Valve Seal Removal

Special Tools Required

Valve Spring Compressor Attachment 07757-PJ1010A

Identify the valves and valve springs as they are removed so that each item can be reinstalled in its original position.

Scheme 185

Scheme 185: Valve, Spring, and Valve Seal Removal
Scheme 185: Valve, Spring, and Valve Seal Removal

Scheme 186

Scheme 186
Scheme 186

Scheme 187

Scheme 187
Scheme 187

Scheme 188

Scheme 188
Scheme 188
  1. Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. Remove the rocker arm assembly (see «ROCKER ARM ASSEMBLY REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  3. Using an appropriate-sized socket (A) and plastic mallet (B), lightly tap the valve retainer to loosen the valve cotters.
  4. Install the valve spring compressor attachment and the valve spring compressor. Compress the spring, and remove the valve cotters.
  5. Remove the valve spring compressor attachment and the valve spring compressor, then remove the spring retainer, the valve spring and the valve.
  6. Install the valve guide seal remover.
  7. Remove the valve seal.
  8. Remove the valve spring seat.

Scheme 189

Scheme 189: Valve Inspection
Scheme 189: Valve Inspection
  1. Remove the valves (see «VALVE, SPRING, AND VALVE SEAL REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-spring-and-valve-seal-removal) ).
  2. Measure the valve in these areas. Intake Valve Dimensions A Standard (New): 34.85-35.15 mm (1.3720-1.3839 in) B Standard (New): 108.7-109.5 mm (4.280-4.311 in) C Standard (New): 5.475-5.485 mm (0.21555-0.21594 in) C Service Limit: 5.445 mm (0.21437 in) Exhaust Valve Dimensions A Standard (New): 29.85-30.15 mm (1.1752-1.1870 in) B Standard (New): 108.4-109.0 mm (4.268-4.291 in) C Standard (New): 5.450-5.460 mm (0.21457-0.21496 in) C Service Limit: 5.420 mm (0.21339 in)

Scheme 190

Scheme 190: Valve Stem-to-Guide Clearance Inspection
Scheme 190: Valve Stem-to-Guide Clearance Inspection
  1. Remove the valves (see «VALVE, SPRING, AND VALVE SEAL REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-spring-and-valve-seal-removal) ).
  2. Subtract the O.D. of the valve stem, measured with a micrometer, from the I.D. of the valve guide, measured with an inside micrometer or a ball gauge. Take the measurements in three places along the valve stem and three places inside the valve guide. The difference between the largest guide measurement and the smallest stem measurement should not exceed the service limit. Intake Valve Stem-to-Guide Clearance Standard (New): 0.030-0.055 mm (0.00118-0.00217 in) Service Limit: 0.08 mm (0.0031 in) Exhaust Valve Stem-to-Guide Clearance Standard (New): 0.055-0.080 mm (0.00217-0.00315 in) Service Limit: 0.11 mm (0.0043 in)

Valve Guide Replacement

Special Tools Required

  1. Valve Guide Driver, 5.35 x 9.7 07742-0010100
  2. Valve Guide Reamer, 5.5 mm 07HAH-PJ7A100

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195
  1. Inspect the valve stem-to-guide clearance (see «VALVE STEM-TO-GUIDE CLEARANCE INSPECTION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  2. As illustrated, use a commercially available air-impact valve guide driver (A) modified to fit the diameter of the valve guides. In most cases, the same procedure can be done using the valve guide driver and a conventional hammer.
  3. Select the proper replacement guides, and chill them in the freezer section of a refrigerator for about an hour.
  4. Use a hot plate or oven to evenly heat the cylinder head to 300°F (150°C). Monitor the temperature with a cooking thermometer. Do not get the head hotter than 300°F (150°C); excessive heat may loosen the valve seats.
  5. Working from the camshaft side, use the valve guide driver and an air hammer to drive the guide about 2 mm (0.08 in) towards the combustion chamber. This will knock off some of the carbon and make removal easier. Hold the air hammer directly in line with the valve guide to prevent damaging the driver. Wear safety goggles or a face shield.
  6. Turn the head over, and drive the guide out toward the camshaft side of the head.
  7. If a valve guide still will not move, drill it out with an 8 mm (5/16 in) drill bit, then try again. NOTE: Drill guides only in extreme cases; you could damage the cylinder head if the guide breaks.
  8. Remove the new guide(s) from the freezer, one at a time, as you need them.
  9. Apply a thin coat of new engine oil to the outside of the new valve guide. Install the guide from the camshaft side of the head; use the 5.5 mm valve guide driver to drive the guide to the specified installed height (A) of the guide (B). If you have all 16 guides to do, you may have to reheat the head. Valve Guide Installed Height Intake: 15.2-16.2 mm (0.598-0.638 in) Exhaust: 15.5-16.5 mm (0.610-0.650 in)
  10. Coat both valve guide reamer and the valve guide with cutting oil.
  11. Rotate the reamer clockwise the full length of the valve guide bore.
  12. Continue to rotate the reamer clockwise while removing it from the bore.
  13. Thoroughly wash the guide in detergent and water to remove any cutting residue.
  14. Check the valve stem-to-guide clearances with a valve (see «VALVE STEM-TO-GUIDE CLEARANCE INSPECTION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ). Verify that a valve slides into the intake and exhaust valve guides without sticking.
  15. Inspect the valve seating. If necessary renew the valve seat using a valve seat cutter (see «VALVE SEAT RECONDITIONING»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).

Scheme 196

Scheme 196: Valve Seat Reconditioning
Scheme 196: Valve Seat Reconditioning

Scheme 197

Scheme 197
Scheme 197

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199
  1. Inspect the valve stem-to-guide clearance (see «VALVE STEM-TO-GUIDE CLEARANCE INSPECTION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ). If the valve guides are worn, replace them (see «VALVE GUIDE REPLACEMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-guide-replacement) ) before cutting the valve seats.
  2. Renew the valve seats in the cylinder head using a valve seat cutter.
  3. Carefully cut a 45° seat, removing only enough material to ensure a smooth and concentric seat.
  4. Bevel the upper and lower edges at the angles shown in the illustration. Check the width of the seat and adjust accordingly.
  5. Make one more very light passes with the 45° cutter to remove any possible burrs caused by the other cutters. Valve Seat Width Standard (New): 1.25-1.55 mm (0.0492-0.0610 in) Service Limit: 2.00 mm (0.0787 in)
  6. After resurfacing the seat, inspect for even valve seating. Apply Prussian Blue compound (A) to the valve face. Insert the valve in its original location in the head, then lift it and snap it closed against the seat several times.
  7. The actual valve seating surface (B), as shown by the blue compound, should be centered on the seat. If it is too high (closer to the valve stem), you must make a second cut with the 67.5° cutter to move it down, then one more cut with the 45° cutter to restore seat width. If it is too low (close to the valve edge), you must make a second cut with the 35° cutter (intake side) or the 30° cutter (exhaust side) to move it up, then make one more cut with the 45° cutter to restore seat width. NOTE: The final cut should always be made with the 45° cutter.
  8. Insert the intake and exhaust valves in the head, and measure valve stem installed height (A). Intake Valve Stem Installed Height Standard (New): 44.0-44.5 mm (1.732-1.752 in) Service Limit: 44.7 mm (1.760 in) Exhaust Valve Stem Installed Height Standard (New): 44.1-44.6 mm (1.736-1.756 in) Service Limit: 44.8 mm (1.764 in)
  9. If the valve stem installed height is over the service limit, replace the valve and recheck. If it is still over the service limit, replace the cylinder head; the valve seat in the head is too deep.

Valve, Spring, and Valve Seal Installation

Special Tools Required

  1. Stem Seal Driver 07PAD-0010000
  2. Valve Spring Compressor Attachment 07757-PJ1010A

Scheme 200

Scheme 200
Scheme 200

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202
  1. Coat the valve stems with new engine oil. Install the valves in the valve guides.
  2. Check that the valves move up and down smoothly.
  3. Install the spring seats on the cylinder head.
  4. Install the new valve seals (A) using the 5.5 mm side of the stem seal driver (B). NOTE: The exhaust valve seals (C) has a black spring (D), and the intake valve seals (E) has a white spring (F). They are not interchangeable.
  5. Install the valve spring and the valve retainer. Place the end of the valve spring with the closely wound coils toward the cylinder head.
  6. Install the valve spring compressor and the valve spring compressor attachment. Compress the spring, and install the valve cotters.
  7. Remove the valve spring compressor and the valve spring compressor attachment.
  8. Lightly tap the end of each valve stem two or three times with a plastic mallet (A) to ensure proper seating of the valve and valve cotters. Tap the valve stem only along its axis so you do not bend the stem.

Scheme 203

Scheme 203: Rocker Arm Assembly Installation
Scheme 203: Rocker Arm Assembly Installation

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205

Scheme 206

Scheme 206
Scheme 206
  1. Reassemble the rocker arm assembly (see «ROCKER ARM AND SHAFT DISASSEMBLY/REASSEMBLY»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__rocker-arm-and-shaft-disassemblyreassembly) ).
  2. Clean and dry the No. 5 rocker shaft holder mating surface.
  3. Apply liquid gasket (P/N 08717-0004, 08718-0003, 08718-0004, or 08718-0009) to the cylinder head mating surface of the No. 5 rocker shaft holder and to the inner threads of the bolt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 3 mm (0.12 in) diameter bead of liquid gasket along the broken line (A). If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
  4. Insert the bolts (A) into the rocker shaft holder, then install the rocker arm assembly (B) on the cylinder head. NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the rocker arm assembly.
  5. Remove the bolts from the rocker shaft holder.
  6. Make sure the punch marks on the VTC actuator and the exhaust camshaft sprocket are facing up, then set the camshafts (A) in the holder. Apply new engine oil to the camshaft journals and lobs.
  7. Set the camshaft holders (B) and cam chain guide B (C) in place.
  8. Tighten the bolts to the specified torque. NOTE: If the engine does not have bolt (2)1, skip it and continue the torque sequence. Specified Torque 8 x 1.25 mm 22 N.m (2.2 kgf.m, 16 lbf.ft) 6 x 1.0 mm 12 N.m (1.2 kgf.m, 9 lbf.ft) 6 x 1.0 mm Bolts: (2)1, (2)2, (2)3
  9. Install the cam chain (see «CAM CHAIN INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-installation) ), then adjust the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__valve-clearance-adjustment) ).

Scheme 207

Scheme 207: Cylinder Head Installation
Scheme 207: Cylinder Head Installation

Scheme 208

Scheme 208
Scheme 208

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210

Scheme 211

Scheme 211
Scheme 211

Scheme 212

Scheme 212
Scheme 212

Scheme 213

Scheme 213
Scheme 213

Scheme 214

Scheme 214
Scheme 214

Scheme 215

Scheme 215
Scheme 215

Scheme 216

Scheme 216
Scheme 216
  1. Clean the cylinder head and the engine block surface.
  2. Install a new coolant separator in the engine block whenever the engine block is replaced.
  3. Install the dowel pins (A) and the new cylinder head gasket (B) on the engine block.
  4. Set the crankshaft to top dead center (TDC). Align the TDC mark (A) on the crankshaft sprocket with the pointer (B) on the engine block.
  5. Install the cylinder head on the engine block.
  6. Measure the diameter of each cylinder head bolt at point A and point B.
  7. If either diameter is less than 10.6 mm (0.417 in), replace the cylinder head bolt.
  8. Apply new engine oil to the threads and under the bolt heads of all cylinder head bolts.
  9. Torque the cylinder head bolts in sequence to 39 N.m (4.0 kgf.m, 29 lbf.ft), using a beam-type torque wrench. When using a preset click-type torque wrench, be sure to tighten slowly and do not overtighten. If a bolt makes any noise while you are torquing it, loosen the bolt and retighten it from the first step.
  10. After torquing, tighten all cylinder head bolts in two steps (90° per step) using the sequence shown in step 9 . If you are using a new cylinder head bolt, tighten the bolt an extra 90°. NOTE: Remove the cylinder head bolt if you tightened it beyond the specified angle, and go back to step 6 of the procedure. Do not loosen it back to the specified angle.
  11. Install the rocker arm assembly (see «ROCKER ARM ASSEMBLY INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head) ).
  12. Install the cam chain (see «CAM CHAIN INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#cylinder-head__cam-chain-installation) ).
  13. Connect the upper radiator hose (A), the heater hose (B), and the water bypass hose (C).
  14. Install the harness clamps (A), then install the two bolts (B) securing the EVAP canister purge control valve mounting bracket.
  15. Connect the EVAP canister hose (A), the brake booster vacuum hose (B), and the vacuum hose (C).
  16. Connect the fuel feed hose (A) (see «FUEL LINE/QUICK-CONNECT FITTING INSTALLATION»(/acura/rdx/i-2009-2012/remont/fuel-system/#fuel-supply-system__fuel-linequick-connect-fitting-installation) ), then install the quick-connect fitting cover (B).
  17. Connect the engine wire harness connectors and wire harness clamps to the cylinder head. ECT sensor 1 connector CMP sensor A (Intake) connector CMP sensor B (Exhaust) connector EVAP canister purge valve connector
  18. Install the exhaust manifold and turbocharger (see «INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  19. Install the intake manifold (see «INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  20. Install the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
  21. Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ).
  22. After install at ion, check that all tubes, hoses and connectors are installed correctly.
  23. Inspect for fuel leaks: Turn the ignition switch to ON (II) (do not operate the starter) so the fuel pump runs for about 2 seconds and pressurizes the fuel line. Repeat this operation three times, then check for fuel leakage at any point in the fuel line.
  24. Refill the radiator with engine coolant, and bleed the air from the cooling system with the heater valve open (see «COOLANT CHECK»(/acura/rdx/i-2009-2012/remont/cooling-fan/#engine-cooling-system) ).
  25. Do the CKP pattern clear/CKP pattern lean procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems) ).
  26. Inspect the idle speed (see «IDLE SPEED INSPECTION»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__idle-speed-inspection) ).
  27. Inspect the ignition timing (see «IGNITION TIMING INSPECTION»(/acura/rdx/i-2009-2012/remont/ignition-system/#ignition-system) ).

Sealing Bolt Installation

Note. When installing the sealing bolt, always use a new washer.

Scheme 217

Scheme 217: Sealing Bolt Installation
Scheme 217: Sealing Bolt Installation

See also:
• HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)
• DLC CIRCUIT TROUBLESHOOTING
• IGNITION COIL AND SPARK PLUG REMOVAL/INSTALLATION
• HDS CLEAR COMMAND
• FRONT SPLASH SHIELD REPLACEMENT
• DRIVE BELT REMOVAL/INSTALLATION
• VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION
• AIR CLEANER REMOVAL/INSTALLATION
• CKP PATTERN CLEAR/CKP PATTERN LEARN
• PUMP REPLACEMENT
• ENGINE REMOVAL
• OIL PUMP CHAIN REPLACEMENT
• CONNECTING ROD JOURNAL CODE LOCATION
• REMOVAL
• FUEL PRESSURE RELIEVING
• COOLANT CHECK
• FUEL LINE/QUICK-CONNECT FITTING REMOVAL
• CMP SENSOR B REPLACEMENT
• FUEL LINE/QUICK-CONNECT FITTING INSTALLATION
• IDLE SPEED INSPECTION
• CYLINDER HEAD COVER REMOVAL
• VALVE CLEARANCE ADJUSTMENT
• CAM CHAIN REMOVAL
• CAM CHAIN INSTALLATION
• CRANKSHAFT PULLEY REMOVAL AND INSTALLATION
• CAM CHAIN CASE OIL SEAL INSTALLATION
• CAMSHAFT INSPECTION
• ROCKER ARM AND SHAFT DISASSEMBLY/REASSEMBLY
• VALVE, SPRING, AND VALVE SEAL REMOVAL
• VALVE GUIDE REPLACEMENT

More articles — Engine
