Scheme 21
Scheme 22
MICU Input Test
Note. Before testing, troubleshoot the multiplex integrated control unit (MICU) first, using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).
Scheme 23
- Check the No. 10 (7.5 A) fuse in the under-dash fuse/relay box. If the fuse is blown, replace it and go to step 2.
- Disconnect under-dash fuse/relay box connectors E, F, K, R, and T. NOTE: All connector views are shown from wire side of female terminals.
- Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 4.
- With the connectors still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained K4 PNK Interior light switch in middle (DOOR) position Attach to ground: The ceiling light and front individual map lights should come on. Blown No. 22 (7.5 A) fuse in the under-hood fuse/relay box Blown bulb(s) Faulty ceiling light Faulty front individual map light Faulty interior light switch Faulty junction box An open or high resistance in the wire
- Reconnect the connectors to the under-dash fuse/relay box, turn the ignition switch to ON (II), and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the MICU must be faulty; replace the under-dash fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/fuses-circuit-breakers/#under-dash-fuserelay-box__removal-and-installation) ). Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained E6 BLK In all ignition switch positions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G601) An open or high resistance in the ground wire E33 BLK In all ignition switch positions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G601) An open or high resistance in the ground wire F20 BLK In all ignition switch positions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G451) An open or high resistance in the ground wire T34 BLK In all ignition switch positions Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G501) An open or high resistance in the ground wire E37 GRN Driver's door open Measure the voltage to ground: There should be less than 0.2 V. Faulty driver's door switch Faulty driver's door switch ground An open or high resistance in the wire Driver's door closed Measure the voltage to ground: There should be at least 5 V. Faulty driver's door switch A short to ground in the wire E3 LT GRN Front passenger's door open Measure the voltage to ground: There should be less than 0.2 V. Faulty front passenger's door switch Faulty front passenger's door switch ground An open or high resistance in the wire Front passenger's door closed Measure the voltage to ground: There should be at least 5 V. Faulty front passenger's door switch A short to ground in the wire E2 LT BLU Right rear door open Measure the voltage to ground: There should be less than 0.2 V. Faulty right rear door switch Faulty right rear door switch ground An open or high resistance in the wire Right rear door closed Measure the voltage to ground: There should be at least 5 V. Faulty right rear door switch A short to ground in the wire E17 BRN Left rear door open Measure the voltage to ground: There should be less than 0.2 V. Faulty left rear door switch Faulty left rear door switch ground An open or high resistance in the wire Left rear door closed Measure the voltage to ground: There should be at least 5 V. Faulty left rear door switch A short to ground in the wire R6 PNK Ignition key inserted into the ignition switch Measure the voltage to ground: There should be less than 0.2 V. Poor ground(G502)or an open in the ground wire Faulty ignition key switch An open or high resistance in the wire Ignition key removed from the ignition switch Measure the voltage to ground: There should be at least 5 V. Faulty ignition key switch A short to ground in the wire T31 BRN Driver's door key cylinder switch in UNLOCK Measure the voltage to ground: There should be less than 0.2 V. Poor ground(G501)or an open in the ground wire Faulty driver door key cylinder switch An open or high resistance in the wire Driver's door key cylinder switch in neutral or LOCK Measure the voltage to ground: There should be at least 5 V. Faulty driver's door key cylinder switch A short to ground in the wire T32 PNK Driver's door key cylinder switch in LOCK Measure the voltage to ground: There should be less than 0.2 V. Poor ground(G501) or an open in the ground wire Faulty driver's door key cylinder switch An open or high resistance in the wire Driver's door key cylinder switch in neutral or UNLOCK Measure the voltage to ground: There should be at least 5 V. Faulty driver's door key cylinder switch A short to ground in the wire
Ignition Key Switch Test
Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.
Scheme 24
Scheme 25
- Remove the steering column upper and lower covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#dashboard__column-cover-removalinstallation) ).
- Disconnect the 6P connector (A).
- Check for continuity between terminals No. 1 and No. 2. with the ignition key in each condition according to the table.
- If the continuity is not as specified, the ignition key switch is faulty; replace the steering lock (see «CHECK OF LOCK LEVER FORCE»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#steering) ).
Ignition Key Light Test
Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.
Scheme 26
- Remove the steering column upper and lower covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#dashboard__column-cover-removalinstallation) ).
- Disconnect the 6P connector (A).
- The LED should come on when power is connected to terminal No. 6 and ground is connected to terminal No. 5.
- If the LED does not come on, the ignition key light is faulty, replace the steering lock (see «CHECK OF LOCK LEVER FORCE»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#steering) ).
