Power Relay Test
Special Tools Required
Relay Puller 07AAC-000A2A1 or 07AAC-000A1A0
Use this chart to identify the type of relay, then do the test listed for it.
| Relay | Test |
|---|---|
| A/C compressor clutch relay (1) | Normally-open four-terminal type |
| A/C condenser fan relay (1) | |
| Blower motor relay (1) (1) | |
| Driver's seat heater relay (HIGH) | |
| Electric vacuum pump relay 1, 2 | |
| Electronic throttle control system (ETCS) control relay (1) | |
| Fog light relay | |
| Front accessory power socket relay | |
| Front passenger's seat heater relay (HIGH) | |
| Ignition coil relay (1) | |
| PGM-FI main relay 1 (1) 2 (1) | |
| PGM-FI subrelay (1) | |
| Power mirror defogger relay (1) | |
| Power window relay (1) | |
| Radiator fan relay (1) | |
| Console accessory power socket relay | |
| Rear window defogger relay (1) | |
| SH-AWD relay | |
| Starter cut relay 1, 2 (1) | |
| ACC cut relay | Five-terminal type |
| Driver's seat heater relay (LOW) | |
| Fan control relay | |
| Front passenger's seat heater relay (LOW) | |
| IG2 cut relay | |
| Rear window wiper relay (1) | |
| (1) Carefully remove the relay from the fuse/relay box using the relay puller. Do not use pliers. Pliers will damage the relay. | |
| (1) | Carefully remove the relay from the fuse/relay box using the relay puller. Do not use pliers. Pliers will damage the relay. |
Scheme 10
Normally-Open Four-Terminal Type
Check for continuity between the terminals.
Scheme 11
- There should be continuity between terminals No. 1 and No. 2 when the battery power is connected to terminal No. 4, and body ground is connected to terminal No. 3.
- There should be no continuity between terminals No. 1 and No. 2 when power is disconnected.
Five-Terminal Type
Check for continuity between the terminals.
Scheme 12
- There should be continuity between terminals No. 1 and No. 2 when the battery power is connected to terminal No. 5, and body ground is connected to terminal No. 3.
- There should be continuity between terminals No. 1 and No. 4 when power is disconnected.
