Contents Section: Testing & Diagnostics All sections

Idle Control System Acura RDX I рестайлинг

Testing & Diagnostics 19 illustrations ~3930 words

Scheme 304

Scheme 304: Component Location Index
Scheme 304: Component Location Index

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, then let it idle 20 seconds or more.
  4. Check under these DATA LIST parameter conditions with the HDS: ECT SENSOR 1 above 158 °F (70 °C) IAT SENSOR above 32 °F (0 °C) Vehicle speed is 0 mph (0 km/h) ST FUEL TRIM between 0.69-1.47 FSS is CLOSED
  5. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Go to step 6. NO -If the HDS indicates PASSED, go to step 15 . If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, go to step 4 and recheck.
  6. Remove the charge air cooler (see «REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  7. Check for dirt, carbon, or damage in the throttle bore. Is there dirt, carbon, or damage in the throttle bore? YES -If there is dirt or carbon, clean the throttle body (see «THROTTLE BODY TEST»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system__throttle-body-test) ). Also check for damage to the air cleaner element (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ), then go to step 9 . If there is damage in the throttle bore, go to step 8. NO -Check the A/C system or power steering system, then go to step 9 .
  8. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
  9. Reset the PCM with the HDS.
  10. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  11. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, then let it idle 20 seconds or more.
  12. Check under these DATA LIST parameter conditions with the HDS: ECT SENSOR 1 above 158 °F (70 °C) IAT SENSOR above 32 °F(0°C) Vehicle speed is 0 mph (0 km/h) ST FUEL TRIM between 0.69-1.47 FSS is CLOSED
  13. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0506 indicated? YES -Go to step 1 , and recheck. NO -Go to step 14.
  14. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 13 , go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) . NO -If the HDS indicates FAILED, check the A/C system and/or the power steering system, then go to step 1 . If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, go to step 12 .
  15. Remove the charge air cooler (see «REMOVAL»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
  16. Check for dirt, carbon, or damage in the throttle bore. Is there dirt, carbon, or damage in the throttle bore? YES -If there is dirt or carbon, clean the throttle body (see «THROTTLE BODY TEST»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system__throttle-body-test) ). Also check for damage to the air cleaner element (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(/acura/rdx/i-2009-2012/remont/mechanical/#intake-air-system) ), then go to step 9 . If there is damage in the throttle bore, go to step 8 . NO -Go to step 17.
  17. Recheck with different load conditions (turn on the headlights, blower motor, rear window defogger and/or A/C, change the gear position, etc.).
  18. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Intermittent failure, the system is OK at this time. NO -If the HDS indicates FAILED, check the A/C system and/or power steering system, then go to step 1 and recheck. If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, go to step 12 and recheck.

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, then let it idle for 20 seconds.
  4. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Go to step 5. NO -If the HDS indicates PASSED, intermittent failure, the system is OK at this time. If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, recheck with different load conditions (electrical, A/C, gear position, etc.), then go to step 3 .
  5. Check for vacuum leaks at these parts: PCV valve PCV hose EVAP canister purge valve Throttle body Intake air duct (air flow tube) Intake manifold Turbocharger Intake air duct (turbocharger inlet tube and pipe) Intake air duct (turbocharger outlet pipe) Charge air cooler Intake air duct (charge air cooler inlet hose) Intake air duct (charge air cooler outlet tube) Turbocharger bypass control solenoid valve Pressure regulator Brake booster hose Brake booster Are there any leaks? YES -Repair or replace the leaking part(s), then go to step 6. NO -Go to step 6.
  6. Turn the ignition switch to ON (II).
  7. Reset the PCM with the HDS.
  8. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  9. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, then let it idle for 20 seconds.
  10. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0507 indicated? YES -Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO -Go to step 11.
  11. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 10 , go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) . NO -If the HDS indicates FAILED, check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, go to step 9 .

DTC P0532: A/C Pressure Sensor Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 305

Scheme 305: DTC P0532: A/C Pressure Sensor Circuit Low Voltage
Scheme 305: DTC P0532: A/C Pressure Sensor Circuit Low Voltage

Scheme 306

Scheme 306
Scheme 306

Scheme 307

Scheme 307
Scheme 307
  1. Start the engine, and let it idle.
  2. Turn the blower switch on.
  3. Turn the A/C switch on.
  4. Check the A/C PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 0.3 V or less? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the A/C pressure sensor and the PCM.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the A/C pressure sensor 3P connector.
  7. Turn the ignition switch to ON (II).
  8. Check the A/C PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 0.3 V or less? YES -Go to step 10 . NO -Go to step 9.
  9. Measure the voltage between A/C pressure sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES -Go to step 18 . NO -Go to step 14.
  10. Turn the ignition switch to LOCK (0).
  11. Jump the SCS line with the HDS.
  12. Disconnect PCM connector A (44P).
  13. Check for continuity between A/C pressure sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (A16) and the A/C pressure sensor, then go to step 20 . NO -Go to step 28 .
  14. Turn the ignition switch to LOCK (0).
  15. Jump the SCS line with the HDS.
  16. Disconnect PCM connector A (44P).
  17. Check for continuity between PCM connector terminal A19 and A/C pressure sensor 3P connector terminal No. 1. Is there continuity? YES -Go to step 28 . NO -Repair an open in the wire between the PCM (A19) and the A/C pressure sensor, then go to step 20 .
  18. Turn the ignition switch to LOCK (0).
  19. Replace the A/C pressure sensor (see «A/C LINE REPLACEMENT»(/acura/rdx/i-2009-2012/remont/automatic-hvac-system/#climate-control) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch to ON (II).
  22. Reset the PCM with the HDS.
  23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  24. Start the engine, and let it idle.
  25. Turn the blower switch on.
  26. Turn the A/C switch on.
  27. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0532 indicated? YES -Check for poor connections or loose terminals at the A/C pressure sensor and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) .
  28. Reconnect all connectors.
  29. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  30. Start the engine, and let it idle.
  31. Turn the blower switch on.
  32. Turn the A/C switch on.
  33. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0532 indicated? YES -Check for poor connections or loose terminals at the A/C pressure sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 30 . If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) .

DTC P0533: A/C Pressure Sensor Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 308

Scheme 308: DTC P0533: A/C Pressure Sensor Circuit High Voltage
Scheme 308: DTC P0533: A/C Pressure Sensor Circuit High Voltage

Scheme 309

Scheme 309
Scheme 309

Scheme 310

Scheme 310
Scheme 310

Scheme 311

Scheme 311
Scheme 311
  1. Start the engine, and let it idle.
  2. Turn the blower switch on.
  3. Turn the A/C switch on.
  4. Check the A/C PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 4.75 V or more? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the A/C pressure sensor and the PCM.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the A/C pressure sensor 3P connector.
  7. Connect A/C pressure sensor 3P connector terminals No. 2 and No. 3 with a jumper wire.
  8. Turn the ignition switch to ON (II).
  9. Check the A/C PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 4.75 V or more? YES -Go to step 10. NO -Go to step 22 .
  10. Turn the ignition switch to LOCK (0).
  11. Remove the jumper wire from the A/C pressure sensor 3P connector.
  12. Turn the ignition switch to ON (II).
  13. Measure the voltage between A/C pressure sensor 3P connector terminal No. 1 and No. 3. Is there about 5 V? YES -Go to step 14. NO -Go to step 18 .
  14. Turn the ignition switch to LOCK (0).
  15. Jump the SCS line with the HDS.
  16. Disconnect PCM connector A (44P).
  17. Check for continuity between PCM connector terminal A16 and A/C pressure sensor 3P connector terminal No. 2. Is there continuity? YES -Go to step 32 . NO -Repair an open in the wire between the PCM (A16) and the A/C pressure sensor, then go to step 24 .
  18. Turn the ignition switch to LOCK (0).
  19. Jump the SCS line with the HDS.
  20. Disconnect PCM connector A (44P).
  21. Check for continuity between PCM connector terminal A9 and A/C pressure sensor 3P connector terminal No. 3. Is there continuity? YES -Go to step 32 . NO -Repair an open in the wire between the PCM (A9) and the A/C pressure sensor, then go to step 24 .
  22. Turn the ignition switch to LOCK (0).
  23. Replace the A/C pressure sensor (see «A/C LINE REPLACEMENT»(/acura/rdx/i-2009-2012/remont/automatic-hvac-system/#climate-control) ).
  24. Reconnect all connectors.
  25. Turn the ignition switch to ON (II).
  26. Reset the PCM with the HDS.
  27. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  28. Start the engine, and let it idle.
  29. Turn the blower switch on.
  30. Turn the A/C switch on.
  31. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0533 indicated? YES -Check for poor connections or loose terminals at the A/C pressure sensor and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) .
  32. Reconnect all connectors.
  33. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  34. Start the engine, and let it idle.
  35. Turn the blower switch on.
  36. Turn the A/C switch on.
  37. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0533 indicated? YES -Check for poor connections or loose terminals at the A/C pressure sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 34 . If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system) .

Scheme 312

Scheme 312: A/C Signal Circuit Troubleshooting
Scheme 312: A/C Signal Circuit Troubleshooting
  1. Start the engine, and let it idle.
  2. Turn the blower switch on.
  3. Turn the A/C switch on.
  4. Check the A/C CLUTCH in the DATA LIST with the HDS. Does it indicate ON? YES -Go to step 5. NO -Do the A/C compressor clutch circuit troubleshooting (see «A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/automatic-hvac-system/#climate-control__ac-compressor-clutch-circuit-troubleshooting) ).
  5. Check the A/C system. Does the A/C system operate? YES -The air conditioning system circuit is OK. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0).
  7. Turn the ignition switch to ON (II).
  8. Activate the A/C CLUTCH in the INSPECTION MENU with the HDS. Is there a clicking noise from the A/C compressor clutch? YES -Do the A/C system test (see «A/C SYSTEM TEST»(/acura/rdx/i-2009-2012/remont/automatic-hvac-system/#climate-control__ac-system-test) ). NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0).
  10. Jump the SCS line with the HDS.
  11. Disconnect PCM connector A (44P).
  12. Turn the ignition switch to ON (II).
  13. Momentarily connect PCM connector terminal A14 to body ground with a jumper wire several times. Is there a clicking noise from the A/C compressor clutch relay? YES -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). NO -Check for poor connections or loose terminals at the A/C compressor clutch relay and the PCM. If the connections are OK, check the A/C compressor clutch relay (see «POWER RELAY TEST»(/acura/rdx/i-2009-2012/remont/body-electrical/#relays__power-relay-test) ), then repair open in the wire between the PCM (A14) and the A/C compressor clutch relay and the other A/C systems.

Scheme 313

Scheme 313: Alternator FR Signal Circuit Troubleshooting
Scheme 313: Alternator FR Signal Circuit Troubleshooting
  1. Start the engine, and let it idle.
  2. Monitor the ALTERNATOR in the DATA LIST with the HDS.
  3. Check if the indicated percentage varies when the headlight switch is turned on. Does the percentage vary? YES -The alternator signal circuit is OK. NO -Go to step 4.
  4. Turn the headlight switch OFF, then turn the ignition switch to LOCK (0).
  5. Jump the SCS line with the HDS.
  6. Disconnect the alternator 4P connector.
  7. Disconnect PCM connector B (44P).
  8. Check for continuity between PCM connector terminal B43 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (B43) and the alternator. NO -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ).

Scheme 314

Scheme 314: PSP Switch Signal Circuit Troubleshooting
Scheme 314: PSP Switch Signal Circuit Troubleshooting

Scheme 315

Scheme 315
Scheme 315

Scheme 316

Scheme 316
Scheme 316

Scheme 317

Scheme 317
Scheme 317

Scheme 318

Scheme 318
Scheme 318
  1. Start the engine, and let it idle.
  2. Align the steering wheel straight ahead.
  3. Check the PSP SWITCH in the DATA LIST with the HDS. Does it indicate ON? YES -Go to step 4. NO -Go to step 14 .
  4. Turn the steering wheel to the full lock position.
  5. Check the PSP SWITCH in the DATA LIST with the HDS. Does it change to OFF? YES -The PSP switch signal circuit is OK. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0).
  7. Disconnect the PSP switch 2P connector.
  8. Start the engine.
  9. Check the PSP SWITCH in the DATA LIST with the HDS. Does it change to OFF? YES -Replace the PSP switch (see «POWER STEERING HOSE, LINE, AND PRESSURE SWITCH REPLACEMENT»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#hydraulic-power-steering-components__power-steering-hose-line-and-pressure) ). NO -Go to step 10.
  10. Turn the ignition switch to LOCK (0).
  11. Jump the SCS line with the HDS.
  12. Disconnect PCM connector A (44P).
  13. Check for continuity between PSP switch 2P connector terminal No. 1 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (A22) and the PSP switch. NO -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ).
  14. Turn the ignition switch to LOCK (0).
  15. Disconnect the PSP switch 2P connector.
  16. Connect PSP switch 2P connector terminals No. 1 and No. 2 with a jumper wire, then start the engine.
  17. Check the PSP SWITCH in the DATA LIST with the HDS. Does it change to ON? YES -Replace the PSP switch (see «POWER STEERING HOSE, LINE, AND PRESSURE SWITCH REPLACEMENT»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#hydraulic-power-steering-components__power-steering-hose-line-and-pressure) ). NO -Go to step 18.
  18. Turn the ignition switch to LOCK (0).
  19. Remove the jumper wire from the PSP switch 2P connector.
  20. Jump the SCS line with the HDS.
  21. Disconnect PCM connector A (44P).
  22. Connect PSP switch 2P connector terminal No. 1 to body ground with a jumper wire.
  23. Check for continuity between body ground and PCM connector terminal A22. Is there continuity? YES -Go to step 24. NO -Repair an open in the wire between the PSP switch and the PCM (A22).
  24. Check for continuity between PSP switch 2P connector terminal No. 2 and body ground. Is there continuity? YES -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). NO -Repair an open in the wire between the PSP switch and G401 (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/rdx/i-2009-2012/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).

Scheme 319

Scheme 319: Brake Pedal Position Switch Signal Circuit Troubleshooting
Scheme 319: Brake Pedal Position Switch Signal Circuit Troubleshooting

Scheme 320

Scheme 320
Scheme 320

Scheme 321

Scheme 321
Scheme 321
  1. Turn the ignition switch to ON (II).
  2. Check the BRAKE SWITCH in the DATA LIST with the HDS. Does it indicate OFF? YES -Go to step 3. NO -Inspect the brake pedal position switch (see «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical-hydraulic/#conventional-brake-system) ).
  3. Press the brake pedal, and check the BRAKE SWITCH in the DATA LIST with the HDS. Does it change to ON? YES -The brake pedal position switch signal circuit (BKSW line) is OK. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0).
  5. Jump the SCS line with the HDS.
  6. Disconnect the brake pedal position switch 4P connector.
  7. Disconnect PCM connector A (44P).
  8. Check for continuity between PCM connector terminal A40 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (A40) and the brake pedal position switch. Also replace the No. 12 HORN, STOP (15 A) fuse. NO -Go to step 9.
  9. Connect brake pedal position switch 4P connector terminal No. 2 to body ground with a jumper wire.
  10. Check for continuity between PCM connector terminal A40 and body ground. Is there continuity? YES -Repair an open in the wire between the brake pedal position switch and the No. 12 HORN, STOP (15 A) fuse. Also check the brake pedal position switch (see «BRAKE PEDAL AND BRAKE PEDAL POSITION SWITCH ADJUSTMENT»(/acura/rdx/i-2009-2012/remont/mechanical-hydraulic/#conventional-brake-system) ). NO -Repair an open in the wire between the PCM (A40) and the brake pedal position switch.

Idle Speed Inspection

Note. Before checking the idle speed, check these items: -The malfunction indicator lamp (MIL) has not been reported on, and there are no DTCs. Ignition timing Sparkplugs Air cleaner PCV system Apply the parking brake. Make sure the headlights or the daytime running lights are off.

Scheme 322

Scheme 322: Idle Speed Inspection
Scheme 322: Idle Speed Inspection
  1. Disconnect the evaporative emission (EVAP) canister purge valve connector.
  2. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
  3. Turn the ignition switch to ON (II).
  4. Make sure the HDS communicates with the PCM. If it does not, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
  5. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, then let it idle.
  6. Check the idle speed under no load conditions: headlights, blower fan, radiator fan, audio system, and air conditioner off. Idle speed should be: 720 ± 50 RPM
  7. Let the engine idle for 1 minute with high electric load (A/C switch on, temperature set to max cool, blower fan on High, and headlights on high beam). Idle speed should be: 720 ± 50 RPM NOTE: If the idle speed is not within specification, do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2009-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ). If the idle speed is still not within specification, go to symptom troubleshooting.
  8. Reconnect the EVAP canister purge valve connector.

PCM Idle Learn Procedure

The idle learn procedure must be done so the PCM can learn the engine idle characteristics.

Do the idle learn procedure whenever you do any of these actions

  1. Replace the PCM.
  2. Reset the PCM.
  3. Update the PCM.
  4. Replace or clean the throttle body.
  5. Disassemble the engine or the transmission.

Note. Erasing DTCs with the HDS does not require you to do the idle learn procedure.

Procedure

  1. Make sure all electrical items (the A/C, the audio, the lights, etc.) are off.
  2. Reset the PCM with the HDS.
  3. Turn the ignition switch to ON (II), and wait 2 seconds.
  4. Start the engine. Hold the engine speed at 3, 000 RPM without load (in P or N) until the radiator fan comes on, or until the engine coolant temperature reaches 194°F(90°C).
  5. Let the engine idle for about 5 minutes with the throttle fully closed. NOTE: If the radiator fan comes on, do not include its running time in the 5 minutes.

More articles — Engine Performance
