Power Seats Acura RDX I

Seats 16 illustrations ~601 words

Scheme 106

Scheme 106: Component Location Index
Scheme 106: Component Location Index

For the 2008 model power seat , refer to DRIVER POSITION MEMORY SYSTEM (DPMS) .

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108: Driver's Seat Without DPMS
Scheme 108: Driver's Seat Without DPMS

For the 2008 model power seat and '09 model driver's power seat , refer to CIRCUIT DIAGRAM - POWER SEAT .

Driver's Seat Without DPMS

Note. For DPMS power seat adjustment switch test/Replacement (see POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT ).

Scheme 109

Scheme 109: Driver's Seat Without DPMS
Scheme 109: Driver's Seat Without DPMS

Scheme 110

Scheme 110
Scheme 110
  1. Remove the power seat adjustment switch knobs (A) and the recline cover from the driver's power seat '07-'08 models, '09 model (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-cushion-coverpad-replacement) ), then remove the two screws and the power seat switch (B).
  2. Disconnect the 12P connector from the power seat adjustment switch.
  3. Reinstall the adjustment switch knobs to the switch.
  4. Check for continuity between the terminals in each switch position according to (Scheme 110).
  5. If the continuity is not as specified, replace the switch.

Scheme 111

Scheme 111: Front Passenger's Seat
Scheme 111: Front Passenger's Seat

Scheme 112

Scheme 112
Scheme 112
  1. Remove the front passenger's seat: '07-08 models, (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) '09 model (see
  2. Remove the power seat adjustment switch knobs (A) and the recline cover from the front passenger's seat '07-08 models, '09 model (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-cushion-coverpad-replacement) , then remove the two screws and the power seat adjustment switch (B).
  3. Disconnect the 12P connector from the power seat adjustment switch.
  4. Reinstall the adjustment switch knobs to the switch.
  5. Check for continuity between the terminals in each switch position according to the table.
  6. If the continuity is not as specified, replace the switch.

Without DPMS

Note. For DPMS power seat motor test (see DRIVER'S POWER SEAT MOTOR TEST ).

Scheme 113

Scheme 113: Without DPMS
Scheme 113: Without DPMS

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117
  1. Remove the driver's seat '07-08 models and '09 model (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
  2. Remove the power seat adjustment switch knobs and the recline cover from the seat (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-cushion-coverpad-replacement) ).
  3. Disconnect the 12P connector (A) from the power seat adjustment switch (B).
  4. Test each motor by applying battery voltage and body ground to the 12P connector terminals. Slide motor Recline motor Front up-down motor Rear up-down motor
  5. If the motor does not run or fails to run smoothly, check for an open in the driver's seat wire harness and driver's seat subharness. If the harness is OK, replace the motor (see «FRONT SEAT FRAME REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-frame-replacement) ). Slide Motor 07'-08 models (see «'07- 08 MODELS DRIVER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__07-08-models-drivers-seat) ). '09 model (see «'09 MODEL DRIVER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__09-model-drivers-seat) ). Recline Motor '07-08 models (see «'07- 08 MODELS DRIVER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__07-08-models-drivers-seat) ). Front and rear up-down motor '07-08 models (see «'07- 08 MODELS DRIVER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__07-08-models-drivers-seat) ). NOTE: If '09 model's front and rear up-down, and recline motor and faulty, replace the seat frame assembly (see «'09 MODEL DRIVER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__09-model-drivers-seat) ).

Scheme 118

Scheme 118: Front Passenger's Seat ('09 model)
Scheme 118: Front Passenger's Seat ('09 model)

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121
  1. Remove the front passenger's power seat (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-293911-S05429671762008081100000)
  2. Disconnect the 2P or 5P connector from each power seat motor. NOTE: All connector views are terminal side of male terminals.
  3. Test the motor by appling power and power and ground to the terminals according to the table. When the motor stops running, disconnect battery power immediately Slide motor Recline motor
  4. If the motor does not run or fails to run smoothly, replace the motor: Slide motor (see «'09 MODEL PASSENGER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__09-model-passengers-seat) ). Recline motor (see «'09 MODEL PASSENGER'S SEAT»(/acura/rdx/i-2006-2009/remont/seats/#seats__09-model-passengers-seat) ). NOTE: If recline motor faulty, replace the seat frame assembly.
