Voice Control Switch Replacement Acura MDX II рестайлинг

Voice Control Switch Replacement

SRS components are located in this area. Review the SRS component location (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 541

1. Remove these items: Driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/mdx/ii-2010-2013/remont/airbag/#srs-supplemental-restraint-system__drivers-airbag-replacement) ). Steering wheel (see «STEERING WHEEL REMOVAL»(/acura/mdx/ii-2010-2013/remont/manual-power-steering/#steering) ). Paddle shifter (see «PADDLE SHIFTER REPLACEMENT»(/acura/mdx/ii-2010-2013/remont/automatic-trans/#automatic-transmission__paddle-shifter-replacement) ). Distance switch (see «ADAPTIVE CRUISE CONTROL (ACC) COMBINATION SWITCH/DISTANCE SWITCH REMOVAL/INSTALLATION»(/acura/mdx/ii-2010-2013/remont/cruise-control-systems/#adaptive-cruise-control-acc) ).
2. Remove the screws and the HFL-navigation voice control switch (A).
3. Install the HFL-navigation voice control switch in the reverse order of removal.

Scheme 542

1. Remove the tailgate lower trim panel (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/mdx/ii-2010-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) ).
2. Disconnect the rearview camera 6P connector (A), then remove the rearview camera cover and the rear license trim (see «REAR LICENSE TRIM REPLACEMENT»(/acura/mdx/ii-2010-2013/remont/exteriorinterior-trim/#exterior-trim__rear-license-trim-replacement) ).
3. Remove the screws and the rearview camera (B).
4. Install the rearview camera in the reverse order of removal.
