Basic Control

When the navigation display detects the BACK UP LIGHT signal (when the gear selector is in R) for at least 0.5 seconds, the navigation display turns on the rearview camera. The navigation display delays for the 0.5 seconds to prevent changing the screen image too frequently because of incorrect gear selection.

Scheme 352

Scheme 353

1. When the rearview camera image is displayed, pressing the interface dial in (ENTER) sends a signal from the audio-navigation unit, to the navigation display unit using the GA-Net BUS to change the camera angle view.
2. The navigation display unit recognizes the signal, and sends a signal to the rearview camera using the CAMERA BITO and CAMERA BIT1 signal lines to change the rearview camera view. Wide Normal Top Down CAMERA BITO Signal OFF (0 V) ON (8 V) OFF (0 V) CAMERA BIT1 Signal OFF (0 V) OFF (0 V) 0N (8 V)
3. The rearview camera takes the digital video using the input signal, then sends the rearview image to the navigation display unit using the NTSC lines. The rearview image appears on the navigation display unit.
