Clock Acura MDX II

Scheme 36

The clock shows day, date, and time information on the center information display. If the clock display does not appear normal, use the self-diagnosis function to test it.

Self-diagnosis function Mode 1 and Mode 2 force all possible segments on. If any of the segments do not appear as illustrated, the clock is faulty. Mode 3 forces all segments off. If there are any segments appearing, the clock is faulty.

If the clock is faulty, replace the center information display (see CENTER INFORMATION DISPLAY INPUT TEST ).

Scheme 37

1. Press and hold the "SET" button, the arrow down button, and the arrow up button, then turn the ignition switch to ON (II).
2. Release all buttons after one second.
3. Within 3 seconds, press and release the "SET" button, press and release the arrow down button, and finally press and release the arrow up button.
4. The self-diagnosis function begins with a blank display. Press and release the arrow up button to scroll through the three modes.
5. Press the "SET" button to exit the self-diagnosis function.

Scheme 38

See also:
• CENTER INFORMATION DISPLAY INPUT TEST
