Automatic Dimming Inside Mirror Acura MDX I

System Description

The automatic dimming inside mirror has a front-facing lux level sensor (A), a rear-facing lux level sensor (B), and a control unit. The control unit receives signals from each sensor. Based on the difference between the two lux levels (the light outside the vehicle and the light from the headlights of the other vehicle, etc.), the control unit controls the electro-chromic gel to reduce the glare. This dimming function is canceled when the transmission is in reverse, or when the automatic dimming switch (C) is turned OFF.

Scheme 11

Note. The illustration shows '03 model.

Scheme 12

Scheme 13

1. Remove the front individual map light ('03 model) or roof console ('04-06 models) (see «FRONT INDIVIDUAL MAP LIGHT TEST»(/acura/mdx/i-2000-2006/remont/interiorillumination-lights/#interior-lights__front-individual-map-light-test) ).
2. Disconnect the 3P connector (A) from the automatic dimming inside mirror (B).
3. Check for continuity between No. 3 terminal and body ground. If there is continuity, go to step 4. If there is no continuity, check for: -an open in the wire. -poor ground (G652: '03 model, G551: '04-06 models).
4. Check for voltage between No. 1 terminal and body ground with the ignition switch ON (II). If there is battery voltage, go to step 5. If there is no voltage, check for: -blown No. 4 (7.5 A) fuse in the driver's under-dash fuse/relay box. -an open in the wire.
5. Check for voltage between No. 2 terminal and body ground with the ignition switch turned ON (II) and transmission range switch in R position. If there is battery voltage, replace the mirror assembly. If there is no voltage, check for: -an open in the wire. -blown No. 9 (10 A) fuse in the under-dash fuse/ relay box. -faulty reverse relay. -faulty transmission range switch.
