GEAR-SHIFT POSITION SENSOR, POSITION Volvo XC90 I

GEAR-SHIFT POSITION SENSOR, POSITION

Special tools

9997077

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information is always correct.

Ignition off.

Remove the air cleaner housing ACL assembly with the intake pipe.

Scheme 739

Remove the transmission cable from the lever. Use jimmy bar 9997077 and the cable mounting from the transmission.

Unhook the mounting and the connector for the transmission from the bracket.

Remove the tie straps for the cable harness and the mounting in the cover for the control system.

Separate connector A for the gear-shift position sensor. Remove the gear-shift position sensor from the mounting.

Scheme 740

Remove

1. the lever for the gear shift linkage rod
2. the nut, locking washer and rubber seal securing the gear-shift position sensor to the gear shift linkage rod
3. the 2 screws
4. the gear-shift position sensor.

Note. For tightening torques, see TIGHTENING TORQUE .

Scheme 741

Install

1. the sensor. Lightly tighten the 2 screws
2. the rubber washer, the lock washer and the nut on the sensor.

Tighten the nut. Lock the nut with the locking washer.
