PHONE MODULE (PHM), REPLACING
Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Ignition off.
Remove the bracket for the dashboard environment panel/infotainment panel. See MINIDISC / CD CONTROL MODULE, REPLACING .
Scheme 295
Remove the 2 screws.
Disconnect the connectors.
Remove the phone module (PHM) and the bracket.
Note. Vehicles that are built before chassis number 167156 require an adapter cable harness between the vehicle's connector and antenna for the new phone module (PHM).
Scheme 296
Note. Check that there is no dirt in the optical connectors.
Connect the connectors
Note. The bend radius of the optic cables and the antenna cables must not be less than 25 mm.
Install the phone module (PHM) and the bracket.
Install and tighten the screws.
Scheme 297
HINT: To facilitate installation of the control module, the rounded corner can be cut even with the corner of the control module. See illustration.
Install the bracket for the dashboard environment panel/infotainment panel. See MINIDISC / CD CONTROL MODULE, REPLACING .
Note. After replacing the phone module (PHM), new software must be ordered and the module programmed.
