CHECKING FUEL PRESSURE SENSOR
Note. If diagnostic trouble codes (DTC) for the fuel pressure sensor or atmospheric pressure sensor are stored, these diagnostic trouble codes (DTC) must be fault-traced and remedied first.
HINT: The following method is for checking if the diagnostic trouble code has been caused by a defective fuel pressure sensor. This can be done by comparing the fuel pressure sensor's readout signal with actual fuel pressure (readout on pressure gauge connected to fuel system's lines).
Scheme 42
Scheme 43
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000) CAUTION: The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer.
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are about the same. Different values indicate malfunction in the circuit for the fuel pressure sensor.
Is the fuel pressure sensor OK?
- YES Refer to «CHECKING COMPONENTS»(ref-495382-S28924690262012082100000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S00225039382012082100000)
CHECKING COMPONENTS
Check the connectors between fuel pump module and the fuel pump for contact resistance and oxidation.
Try with a new fuel pump module if no malfunction is found in the above troubleshooting.
Remedy as necessary.
Other information
- see «FUEL PUMP DRIVER MODULE»(ref-495380-S18216290782012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
Scheme 44
- Continue Refer to «VERIFICATION»(ref-495382-S35597611852012082100000)
FAULT-TRACING INFORMATION
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
VERIFICATION
HINT: After carrying out the repair, check that the fault has been remedied.
Scheme 45
Scheme 46
- Ignition off
- Reinstall the connectors, components etc.
- Engine idling
- Read off the fuel pressure and the work load of the fuel pump. The upper digital display and the graphic display (red font color) indicate the absolute fuel pressure, calculated from the fuel pressure sensor The center digital display (blue font color) indicates the current work load required for the fuel pump (FP) to maintain the present fuel pressure. (Normal value 50 % ±10& %.) The lower digital display indicates the relative fuel pressure (white font color), calculated from the fuel pressure sensor and the atmospheric pressure sensor (= absolute pressure minus atmospheric pressure). If a manometer is connected during the test, it should indicate this pressure. Check the fuel pressure value together with the value for the fuel pump work load. The requested pressure is 380 kPa at idle speed. A (relative) fuel pressure lower than 380 kPa together with a high fuel pump work load indicates a fault in pressure regulation.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S42316902002012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
| CAUTION | The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer. |
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000)
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are the same. Different values indicate malfunction.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S42316902002012082100000)
FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
Note. If diagnostic trouble codes (DTC) for the fuel pressure sensor or atmospheric pressure sensor are stored, these diagnostic trouble codes (DTC) must be fault-traced and remedied first.
HINT: The following method is for checking if the diagnostic trouble code has been caused by a defective fuel pressure sensor. This can be done by comparing the fuel pressure sensor's readout signal with actual fuel pressure (readout on pressure gauge connected to fuel system's lines).
- Connect pressure gauge: «FUEL PRESSURE GAUGE»(ref-511741-S33063024162012102900000) CAUTION: The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer.
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are about the same. Different values indicate malfunction in the circuit for the fuel pressure sensor.
Is the fuel pressure sensor OK?
- YES Refer to «CHECKING COMPONENTS»(ref-495382-S07028940092012082100000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S05759124012012082100000)
Check the connectors between fuel pump module and the fuel pump for contact resistance and oxidation.
Try with a new fuel pump module if no malfunction is found in the above troubleshooting.
Remedy as necessary.
Other information
- see «FUEL PUMP DRIVER MODULE»(ref-495380-S18216290782012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S30616922422012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Engine idling
- Read off the fuel pressure and the work load of the fuel pump. The upper digital display and the graphic display (red font color) indicate the absolute fuel pressure, calculated from the fuel pressure sensor The center digital display (blue font color) indicates the current work load required for the fuel pump (FP) to maintain the present fuel pressure. (Normal value 50 % ±10& %.) The lower digital display indicates the relative fuel pressure (white font color), calculated from the fuel pressure sensor and the atmospheric pressure sensor (= absolute pressure minus atmospheric pressure). If a manometer is connected during the test, it should indicate this pressure. Check the fuel pressure value together with the value for the fuel pump work load. The requested pressure is 380 kPa at idle speed. A (relative) fuel pressure lower than 380 kPa together with a high fuel pump work load indicates a fault in pressure regulation.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S40017733172012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
| CAUTION | The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer. |
- Connect pressure gauge: «FUEL PRESSURE GAUGE»(ref-511741-S33063024162012102900000)
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are the same. Different values indicate malfunction.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S40017733172012082100000)
see FAULT-TRACING
Note. If diagnostic trouble codes (DTC) for the fuel pressure sensor or atmospheric pressure sensor are stored, these diagnostic trouble codes (DTC) must be fault-traced and remedied first.
HINT: The following method is for checking if the diagnostic trouble code has been caused by a defective fuel pressure sensor. This can be done by comparing the fuel pressure sensor's readout signal with actual fuel pressure (readout on pressure gauge connected to fuel system's lines).
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000) CAUTION: The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer.
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are about the same. Different values indicate malfunction in the circuit for the fuel pressure sensor.
Is the fuel pressure sensor OK?
- YES Refer to «CHECKING COMPONENTS»(ref-495382-S24150166102012082100000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S03219781812012082100000)
Check the connectors between fuel pump module and the fuel pump for contact resistance and oxidation.
Try with a new fuel pump module if no malfunction is found in the above troubleshooting.
Remedy as necessary.
Other information
- see «FUEL PUMP DRIVER MODULE»(ref-495380-S18216290782012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S33887745592012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Engine idling
- Read off the fuel pressure and the work load of the fuel pump. The upper digital display and the graphic display (red font color) indicate the absolute fuel pressure, calculated from the fuel pressure sensor The center digital display (blue font color) indicates the current work load required for the fuel pump (FP) to maintain the present fuel pressure. (Normal value 50 % ±10& %.) The lower digital display indicates the relative fuel pressure (white font color), calculated from the fuel pressure sensor and the atmospheric pressure sensor (= absolute pressure minus atmospheric pressure). If a manometer is connected during the test, it should indicate this pressure. Check the fuel pressure value together with the value for the fuel pump work load. The requested pressure is 380 kPa at idle speed. A (relative) fuel pressure lower than 380 kPa together with a high fuel pump work load indicates a fault in pressure regulation.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S29445976002012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
| CAUTION | The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer. |
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000)
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are the same. Different values indicate malfunction.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S29445976002012082100000)
Note. If diagnostic trouble codes (DTC) for the fuel pressure sensor or atmospheric pressure sensor are stored, these diagnostic trouble codes (DTC) must be fault-traced and remedied first.
HINT: The following method is for checking if the diagnostic trouble code has been caused by a defective fuel pressure sensor. This can be done by comparing the fuel pressure sensor's readout signal with actual fuel pressure (readout on pressure gauge connected to fuel system's lines).
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000) CAUTION: The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer.
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are about the same. Different values indicate malfunction in the circuit for the fuel pressure sensor.
Is the fuel pressure sensor OK?
- YES Refer to «CHECKING COMPONENTS»(ref-495382-S14676637322012082100000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S27367735562012082100000)
Check the connectors between fuel pump module and the fuel pump for contact resistance and oxidation.
Try with a new fuel pump module if no malfunction is found in the above troubleshooting.
Remedy as necessary.
Other information
- see «FUEL PUMP DRIVER MODULE»(ref-495380-S18216290782012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S38814809202012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Engine idling
- Read off the fuel pressure and the work load of the fuel pump. The upper digital display and the graphic display (red font color) indicate the absolute fuel pressure, calculated from the fuel pressure sensor The center digital display (blue font color) indicates the current work load required for the fuel pump (FP) to maintain the present fuel pressure. (Normal value 50 % ±10& %.) The lower digital display indicates the relative fuel pressure (white font color), calculated from the fuel pressure sensor and the atmospheric pressure sensor (= absolute pressure minus atmospheric pressure). If a manometer is connected during the test, it should indicate this pressure. Check the fuel pressure value together with the value for the fuel pump work load. The requested pressure is 380 kPa at idle speed. A (relative) fuel pressure lower than 380 kPa together with a high fuel pump work load indicates a fault in pressure regulation.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S10941640942012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
| CAUTION | The pressure in the fuel injection system can reach approximately 650 kPa when this diagnostic trouble code (DTC) is stored. Use an adapted manometer. |
- Connect the pressure gauge: «FUEL SYSTEM PRESSURE, CHECKING»(ref-495381-S07954819082012082100000)
- Run the engine until it is warm and let it idle.
- A/C off. Read off relative fuel pressure. The relative fuel pressure is calculated from the fuel pressure sensor's and the atmospheric pressure sensor's signal (=absolute pressure minus atmospheric pressure). Check that the value on the pressure gauge and the readout value are the same. Different values indicate malfunction.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S10941640942012082100000)
see FAULT-TRACING
see FAULT-TRACING
INFORMATION
There is no fault-tracing for this diagnostic fault code (DTC).
For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.
see FAULT-TRACING INFORMATION
see FAULT-TRACING INFORMATION
see FAULT-TRACING INFORMATION
Use the following information and general checks during fault-tracing.
Note. Check that the fuses are intact. For locations, see the vehicle owner's manual or cover for fuse box.
- Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
- Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
- Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
- Use VIDA (Volvo scan tool) . Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
- Check relevant components according to Component specifications .
- Check relevant signals using the appropriate service information regarding signal specification and breakout box .
Remedy as necessary.
Other information
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000)
- see «DESCRIPTION OF STATUS IDENTIFIER»(ref-511742-S04853029262012102900000)
- see «DESCRIPTION OF COUNTER»(ref-511742-S36878088092012102900000)
- see «DESCRIPTION OF PARAMETERS»(ref-495378-S06704972322012082100000)
- see «DESCRIPTION OF ACTIVATIONS»(ref-495378-S34546887032012082100000)
- see «LOCATION OF COMPONENTS»(ref-495371-S32154419462012082100000)
- see «COMPONENT SPECIFICATIONS»(ref-495312-S07194419502012082100000)
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000)
- see «CONTENTS»(ref-495309-S30765989192012082100000)
Scheme 47
- Continue Refer to «VERIFICATION»(ref-495382-S20227430992012082900000)
HINT: After carrying out the repair, check that the fault has been remedied.
Scheme 48
- Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
- Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.
Is the function OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S11787789142012082900000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
Use the following information and general checks during fault-tracing.
Note. Check that the fuses are intact. For locations, see the vehicle owner's manual or cover for fuse box.
- Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
- Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
- Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
- Use VIDA (Volvo scan tool) . Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
- Check relevant components according to Component specifications .
- Check relevant signals using appropriate service information regarding signal specification and breakout box .
Remedy as necessary.
Other information
- see «DESCRIPTION OF STATUS IDENTIFIER»(ref-511742-S04853029262012102900000)
- see «DESCRIPTION OF COUNTER»(ref-511742-S36878088092012102900000)
- see «DESCRIPTION OF PARAMETERS»(ref-495378-S06704972322012082100000)
- see «DESCRIPTION OF ACTIVATIONS»(ref-495378-S34546887032012082100000)
- see «LOCATION OF COMPONENTS»(ref-495371-S32154419462012082100000)
- see «COMPONENT SPECIFICATIONS»(ref-495312-S07194419502012082100000)
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000)
- see «CONTENTS»(ref-495309-S30765989192012082100000)
- Continue Refer to «INFORMATION»(ref-495382-S14237736912012082900000)
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Start and run the engine to operating temperature. Read off the mass air flow (MAF) sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal is approximately 5-6 g/s with the engine idling at operating temperature. Check that the signal from the mass air flow (MAF) sensor is correct.
Is the signal correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S00173104462012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
CHECKING THE STATUS
- Ignition on Check whether the fault is permanent or intermittent by reading off the mass air flow (MAF) sensor signal. Check that the signal is approximately 5-6 g/s with the engine idling at operating temperature.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S11400103152012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Start and run the engine to operating temperature. Read off the mass air flow (MAF) sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal is approximately 5-6 g/s with the engine idling at operating temperature. Check that the signal from the mass air flow (MAF) sensor is correct.
Is the signal correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S26499366252012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
- Ignition on Check whether the fault is permanent or intermittent by reading off the mass air flow (MAF) sensor signal. Check that the signal is approximately 5-6 g/s with the engine idling at operating temperature.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S39709782582012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Start and run the engine to operating temperature. Read off the mass air flow (MAF) sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal is approximately 5-6 g/s with the engine idling at operating temperature. Check that the signal from the mass air flow (MAF) sensor is correct.
Is the signal correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S22926786122012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
CHECKING THE CONNECTORS AND HOSE CONNECTOR
Check the hose connectors on the intake manifold for damage and leakage.
Check the connector and terminals on the pressure sensor. Check for contact resistance. Check for oxidation.
Remedy as necessary.
Other information
- see «TEMPERATURE AND MANIFOLD ABSOLUTE PRESSURE SENSOR (MAPT)»(ref-495380-S37900287752012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
Scheme 49
Scheme 50
- Continue Refer to «VERIFICATION»(ref-495382-S07094684872012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the pressure sensor signal for intake pressure and the atmospheric pressure sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the values correspond. The atmospheric pressure sensor signal is used as a reference value in this check.
Is the value within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S16138415552012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
Check the hose connectors on the intake manifold for damage and leakage.
Check the connector and terminals on the pressure sensor. Check for contact resistance. Check for oxidation.
Remedy as necessary.
Other information
- see «MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR»(ref-495380-S36162271532012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S41571040932012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the pressure sensor signal for intake pressure and the atmospheric pressure sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the values correspond. The atmospheric pressure sensor signal is used as a reference value in this check.
Is the value within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S13858906412012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the hose connectors on the intake manifold for damage and leakage.
Check the connector and terminals on the pressure sensor. Check for contact resistance. Check for oxidation.
Remedy as necessary.
Other information
- see «MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR»(ref-495380-S36162271532012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S39250136152012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the pressure sensor signal for intake pressure and the atmospheric pressure sensor signal by clicking on the VCT2000 symbol in VIDA (Volvo scan tool). Check that the values correspond. The atmospheric pressure sensor signal is used as a reference value in this check.
Is the value within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S34925258242012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
- Start the engine. Check whether the fault is permanent or intermittent by reading the signal of the air temperature sensor. Check that the value is feasible. If the value is not feasible, the fault is permanent. If the value is feasible, the fault is intermittent and not currently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S04531834282012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the intake air temperature sensor's signal by clicking on the symbol for VCT2000 in VIDA (Volvo scan tool). Check that the signal is within its permitted range.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S25812318552012082100000)
- Start the engine. Check whether the fault is permanent or intermittent by reading the signal of the air temperature sensor. Check that the value is feasible. If the value is not feasible, the fault is permanent. If the value is feasible, the fault is intermittent and not currently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S04823528382012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the intake air temperature sensor's signal by clicking on the symbol for VCT2000 in VIDA (Volvo scan tool). Check that the signal is within its permitted range.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S28678330242012082100000)
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
- Start the engine. Check whether the fault is permanent or intermittent by reading the signal of the air temperature sensor. Check that the value is feasible. If the value is not feasible, the fault is permanent. If the value is feasible, the fault is intermittent and not currently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S32004893732012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read off the intake air temperature sensor's signal by clicking on the symbol for VCT2000 in VIDA (Volvo scan tool). Check that the signal is within its permitted range.
Is the signal within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S07813386922012082100000)
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT-TRACING
see FAULT-TRACING
- Start the engine. Check whether the fault is permanent or intermittent. Read off the engine coolant temperature sensor signal. Check that the value is within its permitted range. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, the fault is intermittent and not presently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S32267085832012082100000)
Scheme 51
- Ignition off Check the engine coolant temperature (ECT) sensor connector and terminals. Check for contact resistance and oxidation. Check the engine coolant temperature (ECT) sensor resistance. Take readings between terminals #1 and #2. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000) see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000) see «COMPONENT SPECIFICATIONS»(ref-495312-S07194419502012082100000) see «MASS AIR FLOW (MAF) SENSOR»(ref-495383-S19897526302012082100000) see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S00327848462012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S18934064052012082100000)
- Start the engine. Check whether the fault is permanent or intermittent. Read off the engine coolant temperature sensor signal. Check that the value is within its permitted range. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, the fault is intermittent and not presently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S33342586212012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S13513102482012082100000)
- Start the engine. Check whether the fault is permanent or intermittent. Read off the engine coolant temperature sensor signal. Check that the value is within its permitted range. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, the fault is intermittent and not presently active.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S33627269352012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S40827255692012082100000)
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING .
see FAULT-TRACING
see FAULT-TRACING
REPLACING THERMOSTAT
Note. This diagnostic trouble code (DTC) is stored if the engine temperature sensor freezes. This may happen if the coolant level is low or there is too little glycol in the coolant. Check the coolant level and its freezing point.
Engine control module (ECM) has registered that the actual temperature increase has deviated from the calculated temperature increase. This deviation is probably due to a damaged thermostat.
Check cables and connectors between engine control module (ECM) and engine temperature sensor for contact resistance and oxidation.
Remedy as necessary.
Other information
- see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000)
- see «THERMOSTAT»(ref-495384-S22999893522012082100000)
- see «ENGINE COOLANT TEMPERATURE SENSOR (ECT)»(ref-495380-S41666175032012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «CHECKING THE STATUS»(ref-495382-S11328837642012082100000)
Scheme 52
- Start the engine.
Check whether the fault is permanent or intermittent by reading off the signal from the engine coolant temperature (ECT) sensor. Check that the value is within its permitted range.
The fault is permanent if the value is not within its permitted range. Check that the value is within its permitted range.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S19106117372012082100000)
Scheme 53
Scheme 54
- Ignition off.
Check the engine coolant temperature (ECT) sensor. Check for contact resistance and oxidation.
Check the engine temperature sensor's resistance between #1 and #2 (against the sensor).
Remedy as necessary.
Other information
- see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000)
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000)
- see «COMPONENT SPECIFICATIONS»(ref-495312-S07194419502012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
Scheme 55
- Continue Refer to «VERIFICATION»(ref-495382-S00475008132012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S15861848982012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
Note. This diagnostic trouble code (DTC) is stored if the engine temperature sensor freezes. This may happen if the coolant level is low or there is too little glycol in the coolant. Check the coolant level and its freezing point.
Engine control module (ECM) has registered that the actual temperature increase has deviated from the calculated temperature increase. This deviation is probably due to a damaged thermostat.
Check cables and connectors between engine control module (ECM) and engine temperature sensor for contact resistance and oxidation.
Remedy as necessary.
Other information
- see «SIGNAL SPECIFICATION»(ref-495312-S41561654002012082100000)
- see «THERMOSTAT»(ref-495384-S24906202252012082100000)
- see «ENGINE COOLANT TEMPERATURE SENSOR (ECT)»(ref-495380-S41666175032012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «CHECKING THE STATUS»(ref-495382-S30982180242012082100000)
- Start the engine.
Check whether the fault is permanent or intermittent by reading off the signal from the engine coolant temperature (ECT) sensor. Check that the value is within its permitted range.
The fault is permanent if the value is not within its permitted range. Check that the value is within its permitted range.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S13807350042012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S14289387942012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Note. This diagnostic trouble code (DTC) is stored if the engine temperature sensor freezes. This may happen if the coolant level is low or there is too little glycol in the coolant. Check the coolant level and its freezing point.
Engine control module (ECM) has registered that the actual temperature increase has deviated from the calculated temperature increase. This deviation is probably due to a damaged thermostat.
Check cables and connectors between engine control module (ECM) and engine temperature sensor for contact resistance and oxidation.
Remedy as necessary.
Other information
- see «SIGNAL SPECIFICATION»(ref-495312-S34327310952012082100000)
- see «THERMOSTAT»(ref-495384-S24906202252012082100000)
- see «ENGINE COOLANT TEMPERATURE SENSOR (ECT)»(ref-495380-S41666175032012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «CHECKING THE STATUS»(ref-495382-S04197478462012082100000)
- Start the engine.
Check whether the fault is permanent or intermittent by reading off the signal from the engine coolant temperature (ECT) sensor. Check that the value is within its permitted range.
The fault is permanent if the value is not within its permitted range. Check that the value is within its permitted range.
- Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-495382-S35535695552012082100000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on Read the engine temperature sensor signal by clicking the VCT2000 symbol in VIDA (Volvo scan tool). Check that the signal corresponds with the engine temperature.
Does the signal correspond to the engine temperature?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S15387421402012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
- Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
- Continue Refer to «CHECKING COMPONENTS»(ref-495382-S14980496242012082100000)
| CAUTION | Do not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector. |
Check the front heated oxygen sensor (HO2S) connector (bank 1). Check for contact resistance and oxidation.
Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.
Remedy as necessary.
Other information
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S12130706792012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S32066528532012082100000)
- see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-495385-S11420067592012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
Scheme 56
- Continue Refer to «VERIFICATION»(ref-495382-S28408261602012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After repairing, it is necessary to check that the malfunction has been fixed.
- Ignition off
- Reinstall the connectors, components etc.
- Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.
Trouble status shows "No malfunction found"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S40990465272012082100000)
see FAULT TRACING
- Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
- Continue Refer to «CHECKING COMPONENTS»(ref-495382-S12968640862012082100000)
| CAUTION | Do not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector. |
Check the front heated oxygen sensor (HO2S) connector (bank 1). Check for contact resistance and oxidation.
Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.
Remedy as necessary.
Other information
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S08896627592012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S41561654002012082100000)
- see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-495385-S06573129632012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S28982710782012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After repairing, it is necessary to check that the malfunction has been fixed.
- Ignition off
- Reinstall the connectors, components etc.
- Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.
Trouble status shows "No malfunction found"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S32750854512012082100000)
- Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
- Continue Refer to «CHECKING COMPONENTS»(ref-495382-S16640155252012082100000)
| CAUTION | Do not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector. |
Check the front heated oxygen sensor (HO2S) connector (bank 1). Check for contact resistance and oxidation.
Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.
Remedy as necessary.
Other information
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S37583422002012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S34327310952012082100000)
- see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-495385-S30645837602012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S13343352652012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After repairing, it is necessary to check that the malfunction has been fixed.
- Ignition off
- Reinstall the connectors, components etc.
- Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.
Trouble status shows "No malfunction found"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S24530303812012082100000)
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
No fault-tracing has been developed for this diagnostic trouble code (DTC).
The diagnostic trouble code (DTC) for this fault is first stored in the Transmission control module (TCM), then in the Engine control module (ECM). This diagnostic trouble code (DTC) can first be erased when the root fault has been remedied and the diagnostic trouble code (DTC) for the root fault has been erased.
For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
- Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
- Continue Refer to «CHECKING COMPONENTS»(ref-495382-S36549991792012082100000)
| CAUTION | Do not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector. |
Check the front heated oxygen sensor (HO2S) connector (bank 2). Check for contact resistance and oxidation.
Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.
Remedy as necessary.
Other information
- see «CONNECTING THE BREAKOUT BOX»(ref-495310-S08896627592012082100000)
- see «SIGNAL SPECIFICATION»(ref-495312-S41561654002012082100000)
- see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-495385-S06573129632012082100000)
- see «CHECKING WIRING AND TERMINALS»(ref-495309-S37197517212012082100000)
- Continue Refer to «VERIFICATION»(ref-495382-S31190097952012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After repairing, it is necessary to check that the malfunction has been fixed.
- Ignition off
- Reinstall the connectors, components etc.
- Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.
Trouble status shows "No malfunction found"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S01155257622012082100000)
see FAULT TRACING
see FAULT TRACING
see FAULT TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING
see FAULT-TRACING INFORMATION
see FAULT-TRACING INFORMATION
see FAULT-TRACING INFORMATION
see FAULT-TRACING INFORMATION
PREPARATORY CHECKS
Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.
The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).
HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.
HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.
- Continue Refer to «CHECKING ETHANOL CONTENT»(ref-495382-S17879398022012082100000)
CHECKING SYSTEM
HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.
HINT: To find the problem, proceed as follows
- Check the oil dipstick for installation and damage that may cause air leakage, that is, that measured air is not drawn into the engine.
- Check the injectors for incorrect type and any damage that limits injected volume.
- Check the inlet system and exhaust system for leaks.
- Engine running.
- Check fuel pressure to, see if it is low.
- Ignition on
- Check residual pressure for too low residual pressure.
Remedy as necessary.
HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.
HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.
Other information
- see «EXHAUST SYSTEM, CHECK»(ref-495386-S33279488772012082100000)
- Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-495382-S23495487032012082100000)
CHECKING MASS AIR FLOW SENSOR
- Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.
- For more information about current fuel compensation: Refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-495382-S00538711672012082100000)
- To continue: Refer to «RESET ADAPTATIONS»(ref-495382-S29444903592012082100000)
Scheme 57
- Turn off the engine.
- Ignition on Reset adaptations to zero by pressing on the symbol for VCT2000 in VIDA (Volvo scan tool). This is done to give the system a normal starting point. Thus it can be seen faster if the adaptations run off up or down.
- Continue Refer to «START ADAPTATIONS»(ref-495382-S15212741592012082100000)
READOUT OF TOTAL FUEL COMPENSATION
- Engine running.
- For reading out total fuel compensation at every given moment, press on the symbol for VCT2000 in VIDA (Volvo scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.
- Continue Refer to «RESET ADAPTATIONS»(ref-495382-S29444903592012082100000)
START ADAPTATIONS
Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.
Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.
The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.
HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.
For adaptation to start, certain conditions must be fulfilled
- Engine speed > or = 600 RPM.
- Engine temperature between 80-110°C.
- Adaptation active = executed.
- EVAP-valve not active = 0 μs.
HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.
Are these values OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S32028949672012082100000)
CHECKING ETHANOL CONTENT
HINT: The cause of the symptom and/or diagnostic trouble code may be that the vehicle has been refuelled with incorrect fuel for that vehicle. The fuel system contains fuel with too high ethanol content.
The energy content in ethanol-diluted fuel is lower than in pure gasoline. This means that the control module compensates for the lower energy content, by increasing the injection volume, to be able to reach lambda=1 at the front heated oxygen sensor. This compensation is normally called "Front lambda control slow" or "Lambda integrator", and varies to compensate for the vehicle's status in the form of component spread, small air leaks, wear, etc. The value of this compensation in the ideal case is 1.0 for pure gasoline. Increased ethanol content of the fuel increases the compensation by approx. 0.05 per 10% ethanol dilution.
The control module is designed to handle an ethanol dilution up to 25%. In combination with other deviations from the ideal case, however, lower ethanol content may be enough to cause customer symptoms. This mainly occurs at engine start with cool engine at outdoor temperatures below 0 °C. Then the diagnostic trouble code may also be set for the engine running on too lean mixture.
Note. In a vehicle intended for gasoline, only pure gasoline shall be used. Even if engine start/operation works, other fuel-related components in the vehicle may be damaged by too high ethanol content.
- Measure the ethanol content of the fuel according to the instructions below. If measured ethanol content is above 25%, then ethanol dilution is the likely cause of the symptom and/or to the diagnostic trouble code being stored. If measured ethanol content is below 25%, symptoms and/or diagnostic trouble code may have been caused by earlier occurrence of incorrect fuel in the system for that vehicle. HINT: Check refuelling history by talking to customer. If nothing indicates incorrect fuel, neither now nor earlier, continue troubleshooting to check other possible causes of faults.
Other information
- see «MEASURING THE ETHANOL CONTENT»(ref-495310-S34118153452012082100000)
- Continue Refer to «CHECKING SYSTEM»(ref-495382-S17361372212012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
see FAULT-TRACING
Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.
The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).
HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.
HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.
- Continue Refer to «CHECKING ETHANOL CONTENT»(ref-495382-S26973955842012082100000)
HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.
HINT: To find the problem, proceed as follows
- Check the oil dipstick for installation and damage that may cause air leakage, that is, that measured air is not drawn into the engine.
- Check the inlet system and exhaust system for leaks.
- Engine running.
- Check fuel pressure to, see if it is low.
- Ignition on
- Check residual pressure for too low residual pressure.
Remedy as necessary.
HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.
HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.
Other information
- see «EXHAUST SYSTEM, CHECK»(ref-495386-S33279488772012082100000)
- Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-495382-S28218723022012082100000)
- Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.
- For more information about current fuel compensation: Refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-495382-S29040862052012082100000)
- To continue: Refer to «RESET ADAPTATIONS»(ref-495382-S06789472512012082100000)
- Engine running.
- For reading out total fuel compensation at every given moment, press on the symbol for VCT2000 in VIDA (Volvo scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.
- Continue Refer to «RESET ADAPTATIONS»(ref-495382-S06789472512012082100000)
Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.
Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.
The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.
HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.
For adaptation to start, certain conditions must be fulfilled
- Engine speed > or = 600 RPM.
- Engine temperature between 80-110°C.
- Adaptation active = executed.
- EVAP-valve not active = 0 μs.
HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.
Are these values OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «INFORMATION»(ref-495382-S34576489242012082100000)
HINT: The cause of the symptom and/or diagnostic trouble code may be that the vehicle has been refuelled with incorrect fuel for that vehicle. The fuel system contains fuel with too high ethanol content.
The energy content in ethanol-diluted fuel is lower than in pure gasoline. This means that the control module compensates for the lower energy content, by increasing the injection volume, to be able to reach lambda=1 at the front heated oxygen sensor. This compensation is normally called "Front lambda control slow" or "Lambda integrator", and varies to compensate for the vehicle's status in the form of component spread, small air leaks, wear, etc. The value of this compensation in the ideal case is 1.0 for pure gasoline. Increased ethanol content of the fuel increases the compensation by approx. 0.05 per 10% ethanol dilution.
The control module is designed to handle an ethanol dilution up to 25%. In combination with other deviations from the ideal case, however, lower ethanol content may be enough to cause customer symptoms. This mainly occurs at engine start with cool engine at outdoor temperatures below 0 °C. Then the diagnostic trouble code may also be set for the engine running on too lean mixture.
Note. In a vehicle intended for gasoline, only pure gasoline shall be used. Even if engine start/operation works, other fuel-related components in the vehicle may be damaged by too high ethanol content.
- Measure the ethanol content of the fuel according to the instructions below. If measured ethanol content is above 25%, then ethanol dilution is the likely cause of the symptom and/or to the diagnostic trouble code being stored. If measured ethanol content is below 25%, symptoms and/or diagnostic trouble code may have been caused by earlier occurrence of incorrect fuel in the system for that vehicle. HINT: Check refuelling history by talking to customer. If nothing indicates incorrect fuel, neither now nor earlier, continue troubleshooting to check other possible causes of faults.
Other information
- see «MEASURING THE ETHANOL CONTENT»(ref-495310-S34118153452012082100000)
- Continue Refer to «CHECKING SYSTEM»(ref-495382-S29692514402012082100000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
