Installing service clips
Note. The automatic transmission has a gear selector cable while the manual transmission has two gear selector cables.
Ensure that the gear selector cable is engaged before fitting the blue clip. Press the clip into position as shown in the illustration.
Check that the clip is positioned in the groove as shown in the illustration.
Scheme 426
Install
- the inner of the two hose couplings for the passenger compartment heater connecting sleeve in the firewall
- the charge air pipe for the turbocharger (TC)
- the hose between the intake manifold and charge air cooler (CAC)
- the clamp for the cable harness on the engine.
Tighten the nut for the rear engine pad. Tighten to 50 Nm .
Scheme 427
Install
- the air cleaner (ACL) housing assembly with the intake manifold and connections
- the ground lead for the mounting on the engine (where applicable)
- the upper torque rod between the wheel arches. Tighten the screws. Tighten to 50 Nm
- the screw for the torque rod to engine mounting. Tighten to 80 Nm .
Fill with coolant. Carefully check while reaching operating temperature or test driving that the level remains the same and that there is no leakage.
Carry out checks after working on the gearbox. See Transmission replacement, post-checking .
