Parking heaters 912-B and 912-D

The engine coolant heater is located inside the front fender, in front of the front left wheel arch.

Scheme 6

Scheme 6

Components

  1. Control module
  2. Fan shroud
  3. Heat exchanger
  4. Fuel pump (FP) (in front of the fuel tank)
  5. Water pump.

Scheme 7

Scheme 7

Components on the engine coolant heater

  1. Coolant temperature sensor
  2. Flame sensor
  3. Overheat protection thermostat
  4. Glow plugs.

Scheme 8

Scheme 8: Passenger compartment / Door mirror
  1. 1 Dashboard environment panel
  2. 2 Outside temperature sensor
  3. 3 Passenger compartment temperature sensor (ECC)
  4. 4 Sun sensor (ECC)
  5. 5 Climate control unit
  6. 6 Air quality sensor
  7. 7 Multifilter / filter.

Scheme 9

Scheme 9: Climate control unit
  1. 1 Heat exchanger
  2. 2 Evaporator
  3. 3 Blower fan motor
  4. 4 Power unit
  5. 5 Air distribution damper motor
  6. 6 Damper motor temperature right
  7. 7 Damper motor temperature left
  8. 8 Recirculation damper motor
  9. 9 Defroster damper motor (ECC)
  10. 10 Coolant pipe connection; to and from the engine compartment
  11. 11 Temperature sensor evaporator (left-hand drive cars)
  12. 11 Temperature sensor evaporator (right-hand drive cars).

Scheme 10

Scheme 10: Engine compartment
  1. 1 Compressor
  2. 2 Compressor - Condenser hoses and pipes
  3. 3 Condenser
  4. 4 Hoses and pipes at the junction point of the side member - compressor
  5. 5 Pipe at the expansion valve - junction point side member
  6. 6 Expansion valve
  7. 7 Pipe at the receiver - expansion valve
  8. 8 Intermediate pipe at the receiver - member / expansion valve
  9. 9 Receiver
  10. 10 Service valve
  11. 11 Service valve filling / emptying
  12. 12 Pressure sensor.

Engine compartment

  1. Compressor
  2. Compressor - condenser hoses and pipes
  3. Condenser
  4. Hoses and pipes at the junction point of the side member - compressor
  5. Pipe at the expansion valve - junction point side member
  6. Expansion valve
  7. Pipe, receiver - expansion valve
  8. Intermediate pipe between the receiver-member and the expansion valve
  9. Accumulator
  10. Service valve
  11. Service valve filling / emptying
  12. Pressure sensor.
