Engine coolant heater, component location

The information below applies to cars manufactured up to week 38 2001 inclusive.

Information for cars manufactured from week 39 2001 inclusive. See Engine coolant heater, component location .

Scheme 1

Location in the car

The heater is located inside the front fender, in front of the front left wheel arch.

Scheme 2

Components

1. Control module

2. Fan shroud

3. Heat exchanger

4. Fuel pump

5. Water pump

Scheme 3

Heater components

1. Coolant temperature sensor

2. Flame sensor

3. Overheat protection thermostat

4. Glow plugs

The illustrations in this service information are used for different model years and / or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Climate control, location of components

The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 4

1. Climate control unit
2. Outside temperature sensor
3. Passenger compartment temperature sensor (ECC)
4. Sun sensor (ECC)
5. Climate control unit
6. Air quality sensor
7. Multifilter / filter.

Scheme 5

1. Heat exchanger
2. Evaporator
3. Fan motor
4. Power unit
5. Damper motor module (DMM) air distribution
6. Damper motor module (DMM) temperature right
7. Damper motor module (DMM) temperature left
8. Damper motor module (DMM) recirculation
9. Damper motor module (DMM) defroster
10. Coolant pipe terminal; to and from the engine compartment
11. Temperature sensor, evaporator (left-hand drive cars)
12. Temperature sensor, evaporator (right-hand drive cars).
