Fuse & Circuit Breaker Identification

  1. 1 - 50 Amp Heated Rear Window, Central Locking System, Power Supply Relay "B", Ignition Switch
  2. 2 - 50 Amp Audio, Power Seats, Hazard Warning Flashers, Compartment Lights, Power Antenna, Trailer Power
  3. 3 - 50 Amp Power Supply Relay "A"
  4. 4 - 50 Amp Fuel System Relay, Ignition System Relay
  5. 5 - 50 Amp ABS Unit
  6. 6 - 50 Amp Air Pump, Starter Solenoid, Horn
  7. 7 - 50 Amp Electric Cooling Fan
  8. 8 - 50 Amp Pos./Parking Light Relay, Headlight Relay, Fog Light Relay Ambient Temperature Sensor, Tailgate Wiper/Washer (Wagon)

Scheme 1

Scheme 1: RELAY/FUSE BOX IDENTIFICATION
Scheme 1: RELAY/FUSE BOX IDENTIFICATION
  1. 1 - 5 Amp Engine Control Module, Automatic Transmission Control Module
  2. 2 - 5 Amp AC Relay
  3. 3 - 15 Amp Relay, Air Pump, Heated Oxygen Sensor
  4. 4 - 15 Amp Fuel Pump
  5. 5 - 15 Amp Fuel Injection, Mass Air Flow (MAF) Sensor, Idle Air Control System, Engine Control Module
  6. 6 - 15 Amp Automatic Transmission Control Module
  7. 7 - 25 Amp Ignition Coil
  8. 8 - 25 Amp Foglights
  9. 9 - Spare
  10. 10 - 15 Amp Positioning/Parking Lights -- Left
  11. 11 - 15 Amp Positioning/Parking Lights -- Right
  12. 12 - 15 Amp Left High Beam
  13. 13 - 15 Amp Right High Beam, Instrument Panel
  14. 14 - 15 Amp Left Low Beam
  15. 15 - 15 Amp Right Low Beam
  16. 16 - 15 Amp A/C Compressor
  17. 17 - 15 Amp Horn
  18. 18 - Accessories

Scheme 2

Scheme 2: PASSENGER COMPARTMENT FUSE BOX IDENTIFICATION
Scheme 2: PASSENGER COMPARTMENT FUSE BOX IDENTIFICATION
  1. 1 - 25 Amp Heated Rear Window
  2. 2 - 20 Amp Central Locking
  3. 3 - 15 Amp Brake Light, Light Switch
  4. 4 - 10 Amp Ignition Switch, SRS
  5. 5 - Spare
  6. 6 - 25 Amp Windshield Wiper/Washer, Headlight Wiper, Horn Relay
  7. 7 - 20 Amp Climate Unit
  8. 8 - 15 Amp Power Seats, Power Side Door Mirrors, Tailgate Wiper/Washer Wagons), Instrument Lighting, Ambient Temperature Sensor
  9. 9 - 15 Amp Audio System
  10. 10 - 15 Amp Cigarette Lighter
  11. 11 - 5 Amp Interior Lighting, Transmission Mode Selector
  12. 12 - 5 Amp ABS
  13. 13 - 10 Amp Clock, Interior/Glove Compartment Lighting, Door Open Warning Lights, Cargo Space Lighting, Vanity Mirror
  14. 14 - 10 Amp Alarm, Horn
  15. 15 - 20 Amp Power Antenna, Headlight Flasher, Trailer
  16. 16 - 20 Amp Accessories
  17. 17 - 20 Amp Hazard Warning Flasher, Direction Indicator, Alarm Hazard Indication
  18. 18 - 15 Amp Audio/Amplifier, CD Changer
  19. 19 - 15 Amp Back-up Lights, Turn Indicators, Cruise Control
  20. 20 - 15 Amp Light Switch, High/Low Beam Relay
  21. 21 - 5 Amp Seat Belt Reminder, Timer - Electrically Heated Rear Window
  22. 22 - 15 Amp Heated Driver's Seat
  23. 23 - 15 Amp Heated Passenger's Seat
  24. 24 - 15 Amp Rear Fog Lamp
  25. 25 - 30 Amp (Automatic Circuit Breaker) Power Seats
  26. 26 - 30 Amp (Automatic Circuit Breaker) Power Windows, Power Sunroof
