VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 5
Scheme 5: VIN Code ID Explanation
SEVERE & NORMAL SERVICE DEFINITIONS
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
- Day And Night Temperatures Are Below Freezing
- Frequent Stop And Go Driving
- Frequent Long Periods Of Engine Idling
- Frequent Driving In Dusty Conditions
- Frequent Short Trips Of Less Than 5 Miles
- Frequent Operation At Sustained High Speeds During Hot Weather, Above 90°F (32°C)
- Frequent Trailer Towing
- Taxi, Police Or Delivery Service
CAMSHAFT TIMING BELT (IF EQUIPPED)
| CAUTION | Failure to replace a faulty camshaft timing belt may result in serious engine damage. |
The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.
Belts or components should be inspected and replaced if any of the following conditions exist
- Cracks Or Tears In Belt Surface
- Missing, Damaged, Cracked Or Rounded Teeth
- Oil Contamination
- Damaged Or Faulty Tensioners
- Incorrect Tension Adjustment
Scheme 6
Scheme 6: SERVICE POINT LOCATIONS
Scheme 7
Scheme 7: VEHICLE LUBRICATION POINTS
Scheme 8
Scheme 8: INFORMATION LABEL LOCATIONS
TIRE INFLATION
Tire specification label is located on the right front door.
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAR WARNING
Note. For information on air bag DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.
| CAUTION | System circuit is grounded by 2 screws beneath the driver's seat. DO NOT use these screws to ground any other accessory. DO NOT ground any other components near this system. |
SIDE IMPACT PROTECTION SYSTEM (SIPS)
Note. For information on air bag DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.
AIR CONDITIONING SERVICING
| CAUTION | Avoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service. |
| WARNING | R-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See AIR CONDITIONING SERVICE article in GENERAL INFORMATION section. |
ANTI-LOCK BRAKE SYSTEM
| CAUTION | The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals. |
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed hydraulic system without first referring to the ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
REPLACING BLOWN FUSES
| CAUTION | Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload. |
BRAKE SYSTEM
| CAUTION | If brake warning light comes on while driving it indicates a low fluid level or failure in one of the braking circuits. If the brake pedal can be depressed further than normal it is an indication that one of the brake circuits is not functioning. Stop vehicle and check brake reservoir fluid level. If level is below MIN mark, DO NOT drive vehicle. Have it towed to a repair shop. If level is between the MIN and MAX marks, proceed cautiously to a repair shop. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
| CAUTION | Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
WHEELS & TIRES
Only wheels tested and approved by the manufacturer should be used on models equipped with Air Dam aerodynamic components.
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
