Removal & Installation (C70, S70 & V70)
Remove driver's mirror trim panel by pulling outward. Remove inner door handle trim. Remove Torx screw from bottom of inner door pull handle. Push center button of clips along lower edge of door panel and remove clips. Pull lower edge of door outward and slide upward to disengage retainers. Disconnect connectors and remove door panel. (Scheme 3) To install, reverse removal procedure.
Scheme 3
Removal & Installation (S90 & V90)
For removal and installation, refer to illustration. (Scheme 3)
Scheme 4
Grip behind mirror glass with fingers and pull straight out. If mirror is heated, detach contact pin. Remove 3 motor screws. Disconnect connector and remove motor. To install, reverse removal procedure.
- Remove mirror glass by pressing on lower edge of mirror until cogs can be seen in slit at bottom of mirror assembly. Using a screwdriver, move cogs to left and lift out mirror glass. (Scheme 5)
- Remove 4 screws and lift out motor. (Scheme 6) Disconnect connector. To install, reverse removal procedure.
Scheme 5
Scheme 6
Removal & Installation
Remove door panel. See DOOR PANEL. Remove power mirror panel. Disconnect connector. Remove 3 bolts. Remove power mirror assembly. (Scheme 7)
Scheme 7
Remove driver's door panel. See DOOR PANEL . Turn door panel over and remove switch from door panel. To install, reverse removal procedures.
Remove screw from bottom of driver's master switch assembly. Remove master window switch assembly, and replace power mirror switch. To install, reverse removal procedure.
