Suspension Module (Sum) - Specifications, Electrical/electronic: Overview Volvo V70 II рестайлинг

Suspension Control Systems 2 illustrations ~108 words

Scheme 1

Scheme 1: Signal Specification

Connector C, terminals #C1-#C2

All values given below are between the terminals stated in column 1 (terminal in the breakout box) and terminal #C2 (ground). This applies unless otherwise indicated in brackets.

Note. It is important to connect the breakout box and check ground terminals before reading off.

U=DC voltage in volts (V)U AC =Alternating current in volts (V)
U bat =Battery voltageF =Frequency in Hertz (Hz)
U low =Voltage approximately 0 V%duty =Duty cycle (pulse ratio) as a percentage (%)
T =Time in milliseconds (ms)
Terminal in the breakout boxTerminalSignal typeIgnition onOther
31#C115-supply (power supply via relay, Central Electronic Module (CEM))U batIgnition in position II
32#C2GroundU low

Scheme 2

Scheme 2

Connector A, terminals #A1 #A30

All values given below are between the terminals stated in column 1 (terminal in the breakout box) and terminal #C2 (ground). This applies unless otherwise indicated in brackets.

Note. It is important to connect the breakout box and check ground terminals before reading off.

U=DC voltage in volts (V)U AC =Alternating current in volts (V)
U bat =Battery voltageF =Frequency in Hertz (Hz)
U low =Voltage approximately 0 V%duty =Duty cycle (pulse ratio) as a percentage (%)
T =Time in milliseconds (ms)
Terminal in the breakout boxTerminalSignal typeIgnition onOther
1#A1Ground, left rear solenoidU low
2#A2Voltage, left rear solenoidU lowWith the car stationary
3#A3Voltage, background lighting keypad (R-line)U batPulse width modulation (PWM) signal controlled
4#A4Ground, right rear solenoidU low
5#A5Voltage, right rear solenoidU lowWith the car stationary
6#A6Voltage, left front solenoidU lowWith the car stationary
7#A7Ground, left front solenoidU low
8#A8Ground, right front solenoidU low
9#A9Voltage, right front solenoidU lowWith the car stationary
10#A10Signal from the acceleration sensor, car body left frontUapprox.2 V When the car body is not movingA varying signal between 0-5 V when the body is moving
11#A11Indicator 2 on the keypad (R-line)Lamp lit: U = U bat Lamp off: U = U low -2V
12#A12Signal from acceleration sensor suspension left frontUapprox.2.5 V When the suspension is not movingA signal varying between 0-5 V when the suspension is moving
13#A13Voltage, sensor5 V
14#A14Signal, position sensor rear right suspensionU = 0.5 - 4.5 V, depending on the vertical position of the body
15#A15Communication CAN_L high speed network1.5-2.5 V1.5 V, at communication
16#A16Communication CAN_H high speed network2.5-3.5 V3.5 V, at communication
17#A17Signal from the acceleration sensor, car body left rearUapprox.2 V When the car body is not movingA varying signal between 0-5 V when the body is moving
18#A18Reserve
19#A19Ground, sensor 1U low
20#A20
21#A21Ground, keypad (R-line)U low
22#A22Signal from the acceleration sensor, car body right frontUapprox.2 V When the car body is not movingA signal varying between 0-5 V when the suspension is moving
23#A23Sensor ground 2U low
24#A24Signal from the keypad (R-line)Approx.4.5 VWhen button is pressed in approx.1-4.5 V
25#A25Voltage, left rear position sensor5 V
26#A26Indication 1 on the keypad (R-line)Lamp lit: U = Ubat Lamp not lit: U = Ulow
27#A27Signal from acceleration sensor suspension right frontUapprox.2.5 V When the suspension is not movingA signal varying between 0-5 V when the suspension is moving
28#A28Signal, suspension position sensor left rearU = 0.5 - 4.5 V, depending on the vertical position of the body
29#A29Indicator 3 on the keypad (R-line)Lamp lit: U = U bat Lamp not lit: U = U low -2V
30#A30
