Remove Special Tool
Remove special tool 9988695
HINT: If the ignition is switched on when neither the steering wheel module nor special tool are connected, a diagnostic trouble code (DTC) will be stored indicating an open-circuit. Any diagnostic trouble code (DTC) must be erased.
Scheme 151
Remove screw from parking position (A) and secure the contact reel in lock position (B). Do not detach the screw from the plastic strip.
| CAUTION | The steering wheel must never be turned while the contact reel is locked. The contact reel pin will shear off. |
Scheme 152
Scheme 153
| CAUTION | The steering wheel must never be turned while the contact reel is locked. The contact reel pin will shear off. |
3 Torx 20 screws in the steering wheel cover.
2 Torx 20 screws in the switches.
To remove and install contact reel, see Replacing SRS contact reel .
Scheme 154
If the locking screw is not in the lock position as shown in the illustration, the contact reel must be zeroed. For zeroing see Resetting SRS contact reel .
Note. A new contact reel is zeroed at the factory and supplied with the locking screw installed. Zeroed means that the steering wheel can be turned to full lock in either direction without damaging the contact reel.
Remove special tool 9988695 .
Scheme 155
Scheme 156
Rest lower part of steering wheel module on steering wheel (1).
Connect SRS ignition cable to the module (2).
Fold module up into the steering wheel (3). Check that the SRS ignition cable is not trapped.
