A/c-Heater System - Automatic: Specifications Volvo V70 I

Automatic HVAC System 2 illustrations

A/C SYSTEM SPECIFICATIONS

ApplicationSpecification
Compressor TypeZexel DKS-15CH 6-cyl.
Compressor Belt Tension(1)
System Oil Capacity(2) 6.8 ozs.
Refrigerant (R-134a) Capacity26.4 ozs.
System Operating Pressures (3)
High Side406-450 psi (28.5-31.6 kg/cm 2 )
Low Side25-33 psi (1.8-2.3 kg/cm 2 )
(1) Belt tension is maintained by automatic belt tensioner. (2) Use PAG Oil (Part No. 11 61 407-0) (3) Pressure switch cut-out points.
(1)Belt tension is maintained by automatic belt tensioner.
(2)Use PAG Oil (Part No. 11 61 407-0)
(3)Pressure switch cut-out points.

A/C SYSTEM SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Compressor Bracket-To-Compressor30 (40)
Compressor Pipe Fitting15 (20)
Compressor Pipe Flange Bolt18 (24)
Condenser Inlet & Outlet19 (25)
Expansion Valve22 (30)
Receiver-Drier Connection22 (30)
INCH Lbs. (N.m)
High-Pressure Sensor Connection7 (10)

TORQUE SPECIFICATIONS

Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1

Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)

Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2

Scheme 2: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
