Interior - Installation Instructions, Accessories: Other Volvo V50 I рестайлинг

SUN VISOR

Note. SUN VISOR IS SECURED WITH PRESS STUDS OR ELASTIC STRAPS

Scheme 83

1. The sun visor can be attached to the top of the child seat with the press studs.

Scheme 84

Scheme 85

1. The sun visor can also be secured in the seat belt lead-ins in the seat backrest.

Scheme 86

1. Can also be folded to the side to protect against sunlight through the side window.

ISOFIX FRONT MOUNTING

Scheme 87

1. Fold the backrest forward on the front passenger side.

Scheme 88

1. Install the ISOFIX attachment to the SIPS tube with the four screws from the kit. Tighten the screws to 10 Nm (7.5 lbf. ft.)
2. Reset the backrest.

INSTALLING/REMOVING

Illustration applies to the passenger seat and car models

Scheme 89

Illustration applies to the rear seat and car models

Scheme 90

Installing the Isofix guide

1. Press the Isofix guide (1) into place between the backrest and seat cushion. Press it down to the Isofix mountings.
2. The Isofix mountings must be visible in the guide's (1) openings. Check that the guide is correctly installed.

Removing the Isofix guide

1. Grip the outer edges. Carefully pull the guide outwards.

PREPARATION

1. Take the protective cushion and locate the child seat in its correct position with the protective cushion between the seat's backrest and the dashboard. The lower edge of the protective cushion must be approximately edge to edge with the lower edge of the dashboard.
2. Mark out the lower edge of the protective cushion on the end face of the seat with a strip of tape.

1. Wash the back of the child seat for affixing the Velcro strap using a mixture of 30% washer fluid and 70% water as indicated by the marking.
2. Wipe dry.

1. Pull off one Velcro strap from the protective cushion. NOTE: Do not pull only on the white protective tape.

1. Pull off the protective tape from the detached Velcro strap.
2. Press the Velcro strap into the center of the backrest and according to the tape marking in the lower edge.
3. Press the protective cushion into the seat's backrest.
4. Remove the tape marking.

SUPPORT LEG FOR CHILD SEATS

The support leg is used for child seats on the rear seat

Scheme 91

1. Screw the support leg into the frame of the child sea. Use the screws from the kit. Tighten the screws thoroughly.

Scheme 92

1. Adjust the angle of the child seat by unscrewing the knob (1) completely. Adjust the length of the support leg. Screw in the knob. Tighten the knob.

The child must be sitting comfortably. A child is safest sitting upright in the car. Children unable to sit on their own must be in a semi-reclined position.
