Location of components
Fuel pump
in the fuel tank.
Fuel filter
by the left rear wheel.
Engine control module (ECM)
on the center console under the dashboard.
Data Link Connector (DLC)
on the left of the center console (LHD cars); on the right on the center console (RHD cars).
Scheme 79
The bracket for the connectors
on the firewall in the engine compartment.
| 1 | Front heated oxygen sensor (HO2S) connector |
|---|---|
| 2 | Rear heated oxygen sensor (HO2S) connector |
| 3 | Engine speed (RPM) sensor connector |
| 4 | Knock sensor (KS) connector |
| 5 | Camshaft position (CMP) sensor connector |
| 6 | Ignition coils / camshaft adjustment valve connector |
See Location of components
