Fitting ceiling microphone Volvo S80 I facelift

Fitting ceiling microphone

Note. If new headlining is to be fitted, a hole will have to be made in the roof.

Scheme 139

With sunroof.

Without profile in place.

A - 17 mm

B - 38 mm

C - 22 mm

D - 12 mm

Scheme 140

With sunroof.

With profile in place.

A - 8 mm

B - 30 mm

C - 22 mm

D - 12 mm

Scheme 141

Without sunroof.

Without parts in place.

A - 166 mm

B - 68 mm

C - 22 mm

D - 12 mm

Scheme 142

Without sunroof.

With parts in place.

A - 142 mm

B - 61 mm

C - 22 mm

D - 12 mm

Note. The cable harness should be glued or taped to the headlining.

Fit

1. the connector by the A-pillar
2. cover for microphone.
3. ceiling module, see «Roof module»(ref-440253-S36218367242011121400000) .
4. panel, A-pillar, see «Replacing A-post panel»(ref-440253-S33543302672011121400000) .
