Engine Air Baffle - Installation Instructions Volvo S80 I facelift

1. Raise the car.

Scheme 568

1. Install the air baffle. Tighten the screws (1). Tighten to 25 Nm (19 lbf. ft.) .

Scheme 569

1. Raise the car
2. Remove the air baffle (1) by slackening off the screws (2).

Scheme 570

1. Lift up the protective panel towards the sub-frame. Install the small screws in the front holes (1). Position all the washers between the sub-frame and the protective panel in the right hole. Loosely screw the screws into place
2. Position the sleeve between the protective panel and the sub-frame by the hole (2). Screw the long screw into place.

Scheme 571

1. Position the nuts (1) and the washers (2) above the rear holes in the sub-frame. Position the washers (3) between the sub-frame and the protective panel. Loosely screw the screws (4) into place
2. Tighten the front screws (5). Tighten to 25 Nm (19 ft. lb)
3. Tighten the rear screws (4). Tighten to 50 Nm (38 ft. lb)
4. Post-tighten the screws after approximately 1 minute so that the materials have time to settle.
