Jacking points, body
Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Scheme 1
When jacking the vehicle, the jacking points given below must be used. The jacking plate must have a rubber pad to prevent damage to the vehicle.
Scheme 2
When jacking the vehicle, the jacking points given below must be used. The jacking plate must have a rubber pad to prevent damage to the vehicle.
Front lift
A wooden load relief plate (200*200*20 mm) must be used behind the sub-frame bracket.
Rear lift
A wooden spacer (170*80*50 mm) must be used at the front of the sub-frame bracket.
