Ignition and Control Systems - Component Location: Overview Volvo S80 I рестайлинг

Engine Control Systems 5 illustrations ~218 words

Scheme 137

Scheme 137: Location of components, engine compartment

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentRemarks
1Engine coolant temperature (ECT) sensor
2Ground terminal
3Coolant level sensor
4Reset valve, camshaftExhaust and intake camshafts.
5Turbocharger (TC) control valveOnly turbocharged (TC) engines
6Camshaft sensorExhaust and intake camshafts.
7Brake pedal sensor
8Engine speed (RPM) sensor
9Outer temperature sensor
10Power supply terminal
11Fusebox
12Relay box
13Mass air flow (MAF) sensor
14Ignition coil
15Canister purge (CP) valve
16Boost pressure sensorThe intake air temperature (IAT) sensor is integrated in the boost pressure sensor
17Fuel pressure sensorThe fuel temperature sensor is integrated in the fuel pressure sensor
18Injector
19Oil level sensorLocated in the oil trough
20Engine cooling fan (FC) control module
21Throttle unitAlso includes the throttle position (TP) sensor
22A/C pressure sensor
23Knock sensor (KS)
24Engine control unit
25Engine cooling fan (FC) control modules

Scheme 138

Scheme 138: Location of components, engine compartment

Note. For S60/V70 2004- B5254T2 AW55-50SN US market, see Location of components, engine compartment .

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentRemarks
1Engine coolant temperature (ECT) sensor
2Ground terminal
3Coolant level sensor
4Camshaft reset valveAvailable on both the intake and the exhaust camshafts or only on one of the camshafts, varies between engine types
5Turbocharger (TC) control valveTurbocharged engines only
6Camshaft sensorAvailable on both the intake and the exhaust camshafts or only on one of the camshafts, varies between engine types
7Brake pedal sensor
8Engine speed (RPM) sensor
9Outer temperature sensor
10Power supply terminal
11Fusebox
12Relay box
13Mass air flow (MAF) sensorNaturally aspirated engines: Also includes the intake air temperature (IAT) sensor
14Canister purge (CP) valve
15Boost pressure sensorTurbocharged engines only: Also includes the intake air temperature (IAT) sensor
16Ignition coil
17Injector
18Engine cooling fan (FC) control module
19Throttle unitAlso includes the throttle position (TP) sensor
20A/C pressure sensor
21Knock sensor (KS)
22Engine control unit
23Engine cooling fan (FC) control modules

Scheme 139

Scheme 139: Location of components
  1. Engine coolant temperature (ECT) sensor
  2. Ground terminal
  3. Coolant level sensor
  4. Camshaft reset valve
  5. Turbocharger (TC) control valve
  6. Camshaft position sensor (CMP)
  7. Brake pedal sensor
  8. Engine speed (RPM) sensor
  9. Outer temperature sensor
  10. Power supply terminal
  11. Fusebox
  12. Relay box
  13. Mass air flow (MAF) sensor
  14. Intake air temperature sensor
  15. Boost pressure sensor
  16. Canister purge (CP) valve
  17. Ignition coil
  18. Injector
  19. Throttle unit
  20. Knock sensor (KS)
  21. Engine cooling fan (FC) control module
  22. A/C pressure sensor
  23. Engine control module (ECM).

Scheme 140

Scheme 140: Location of components
  1. Engine coolant temperature (ECT) sensor
  2. Ground terminal
  3. Coolant level sensor
  4. Camshaft reset valve
  5. Camshaft position sensor (CMP)
  6. Brake pedal sensor
  7. Engine speed (RPM) sensor
  8. Outer temperature sensor
  9. Power supply terminal
  10. Fusebox
  11. Relay box
  12. Mass air flow (MAF) sensor
  13. Injector
  14. Canister purge (CP) valve
  15. Ignition coil
  16. Knock sensor (KS)
  17. Engine cooling fan (FC) control module
  18. Throttle unit
  19. A/C pressure sensor
  20. Engine control module (ECM).

Scheme 141

Scheme 141: Location of components, engine compartment

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentRemarks
1Engine coolant temperature (ECT) sensor
2Ground terminal
3Coolant level sensor
4Camshaft reset valve5 cylinder turbo: exhaust camshaft, 6 cylinder normally aspirated: intake camshaft, 6 cylinder turbo: exhaust and intake camshafts.
5Turbocharger (TC) control valveOnly turbocharged (TC) engines
6Camshaft position sensor (CMP)5 cylinder turbo: exhaust camshaft, 6 cylinder normally aspirated: intake camshaft, 6 cylinder turbo: exhaust and intake camshafts.
7Brake pedal sensor
8Engine speed (RPM) sensor
9Outer temperature sensor
10Power supply terminal
11Fusebox
12Relay box
13Mass air flow (MAF) sensorNaturally aspirated engines: Also includes the intake air temperature (IAT) sensor
14Intake air temperature sensorOnly turbocharged (TC) engines
15Boost pressure sensorOnly turbocharged (TC) engines
16Canister purge (CP) valve
17Ignition coil
18Injector
19Throttle unitAlso includes the throttle position (TP) sensor
20Knock sensor (KS)
21Engine cooling fan (FC) control module
22A/C pressure sensor
23Engine control module (ECM)
24Cooling fan for control modules
