GENERATOR SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Carbon Brushes (Minimum Length) | 0.2" (5.0 mm) | |
| Generator | ||
| NCB 1 (BOSCH) | 120 A | |
| E140/8 (BOSCH) | 140 A | |
| Nominal Output | 1680 W | |
| Rotor Winding (Resistance) | 2.6 Ohms | |
| Stator Winding (Resistance) | .06 Ohms | |
GENERATOR SPECIFICATIONS
Note. Charging voltage (Scheme 1)is with a 25-45 amp generator load at about 2300 RPM.
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Generator Belt Pulley | ||
| Fixed Pulley | 48 (65) | |
| Freewheel | 59 (80) | |
| Generator Mounting Bolt (M8) | 18 (24) | |
| INCH Lbs. (N.m) | ||
| B+ Terminal | 133 (15) | |
| Battery Connector | 22 (2.5) | |
TORQUE SPECIFICATIONS
