BELT TENSION
Serpentine belt tension is automatically adjusted by tensioner.
DRIVE BELT ROUTING
Note. Serpentine belt is self-adjusting. For drive belt routing (Scheme 8)
Scheme 8
Note. Charge indicator lamp in the combined instrument panel is controlled by the driver information module via signals from the Controller area network. Check indicator according to wiring diagram. See WIRING DIAGRAMS .
BATTERY DISCONNECT/CONNECT
When disconnecting and connecting battery, observe the following
- Supplemental Restraining System (SRS) is active for a certain time after power is cut. Wait 3 minutes before starting work.
- Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS (or AIR BAG SAFETY PRECAUTIONS) and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article.
- When connecting battery, key must be in position 2. No one must be in the car when battery is connected. Airbag module may activate when power is connected.
- When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. Obtain an-theft radio security code.
- After battery has been disconnected, vehicle may have to be driven for a few minutes before engine runs normally.
- After connecting battery lead, initialize central locking, interior lighting and sun roof by using remote control, or VADIS vehicle communication, to unlock car.
- On vehicles equipped with manual or standard climate control, blower fan speed must be recalibrated after connecting battery. To recalibrate blower fan, turn ignition to ON position. Turn blower fan switch to maximum, and then to minimum.
- On vehicles equipped with sun roof, once battery has been reconnected, recalibration of sun roof may be necessary. Perform following procedure: Ensure sun roof is closed. Switch ignition to position "I". Press sun roof switch so that sun roof is in tilt position. Release switch. Press switch so that sun roof is in tilt position again, and hold for at least 5 seconds until sun roof closes. Release switch. If sun roof is in correct position, calibration is complete. If sun roof has not moved into correct position, repeat procedure. If sun roof is still not in correct position after completing second recalibration, continue to next step. Press sun roof switch so that sun roof completely opens. Release switch. Press switch in opposite direction and hold for at least 5 seconds to close sun roof. Release switch. Close sun roof and perform calibration procedure again.
Note. Battery is located in rear of vehicle under cargo compartment floor panel.
GENERATOR BELT PULLEY (W/FREEWHEEL)
Note. If vehicle is cold, battery charge warning lamp may light shortly after start-up. Freewheel needs to rotate and warm up bearing grease before it locks and engages the rotor shaft. If warning lamp remains lit, it may be an indication that freewheel has not locked pulley to rotor shaft.
Start engine. Raise engine to 3,000 RPM. Ensure power consuming components are connected. Check that only a weak clicking sound is heard when freewheel engages and disengages. Switch off engine. Check that generator rotates for longer than engine.
Rotate pulley counter-clockwise and brake heavily. Freewheel should grip rotor shaft when rotating counter-clockwise. Stop rotation. When braking pulley, freewheel mechanism should release so that rotor shaft continues to rotate.
GENERATOR BELT PULLEY (2001-03)
Note. On vehicles produced from 2001-2003, manufacturer does not provide specific procedure for generator belt pulley removal and installation.
GENERATOR BELT PULLEY (2004)
Note. Vehicles equipped with 5-cylinder engine do not need to remove generator to remove or install generator belt pulley.
