Removing the radio/carphone
Remove the dashboard environment panel. See Dashboard environment panel (including climate control module (CCM)), replacing .
Scheme 1011
Remove the radio/carphone
Unscrew the two screws in the lower edge.
Installing the radio/carphone
Install
In reverse order.
Scheme 1012
Angle the radio and carphone unit in and press it upwards.
Ordering carphone software
Order the software. See 9438270 .
Programming the carphone control module
Program the new control module. See 9438270 .
Finishing work, carphone
Check that no diagnostic trouble codes have been stored during the repair.
Test drive the vehicle. Check that the function of the engine is OK.
Ordering radio software
Order software. See: 9438438 .
Finishing work, radio
Check that no diagnostic trouble codes have been stored during the repair.
Test drive the vehicle. Check that the function of the engine is OK.
Carphone components
Note. For carphone components, see
- antenna «Antenna»(ref-445641-S07309791712012010600000)
- carphone box «Carphone box»(ref-445641-S24187292322012010600000)
- microphone «Hands-free microphone»(ref-445641-S19539171152012010600000)
- loudspeaker «Hands-free loudspeakers»(ref-445641-S42408991742012010600000)
- handset «Handset holder»(ref-445643-S15942864112012010600000) .
Radio components
Only 4-door vehicle bodies
Note. For radio components, see
- windshield antenna / amplifier «Windshield antenna and amplifier»(ref-445649-S03614115822012010600000)
- sub-antenna in bumper / amplifier «Sub-antenna in bumper / amplifier»(ref-445649-S24341680092012010600000)
- power amplifier «Power amplifier»(ref-445649-S04620437442012010600000)
- CD-changer «CD player»(ref-445649-S29555369212012010600000) .
Central loudspeaker, replacing
Cars which do not have RTI may have a large central loudspeaker in the middle of the dashboard.
Scheme 1013
Remove
- the loudspeaker grille. Use: «9512943»(ref-403953-S25727720672011061000000) . Turn a quarter turn and pull up.
Scheme 1014
- the 3 screws.
- the connector.
Install
In reverse order.
