LOCATION OF CONTROL MODULES ON THE MOST NETWORK
Note. The control modules on the MOST network should be positioned in a particular order. If this order is not followed, the fault-tracing of the MOST network will deteriorate.
When a control module is added to the MOST network, it should be placed in the correct order on the network to make it easier to fault-trace the control modules.
If the control modules are connected in another order, this does not effect the function of the MOST network, but fault-tracing will be more difficult.
The control modules should be placed in the following order
- Infotainment control module (ICM)
- Multimedia module (MMM)
- AM/FM tuner module (AFM)
- Traffic message channel module (TMC)
- Audio module (AUD)
- Global positioning system module (GPS)
- Subwoofer module (SUB)
- Phone module (PHM)
- Media player module (MPM) or integrated audio module (IAM)
If the minimum configuration of control modules on the MOST network is used in the vehicle, the following control modules are connected (when the vehicle is fitted with a media player module (MPM))
- infotainment control module (ICM)
- media player module (MPM)
- AM/FM tuner module (AFM)
- audio module (AUD).
If, instead, the vehicle is fitted with an integrated audio module (IAM), an infotainment control module (ICM) is connected in addition to this.
Note. The control modules on the MOST network should be positioned in a particular order. If this order is not followed, the fault-tracing of the MOST network will deteriorate.
When a control module is added to the MOST network, it should be placed in the correct order on the network to make it easier to fault-trace the control modules.
If the control modules are connected in another order, this does not effect the function of the MOST network, but fault-tracing will be more difficult.
The control modules should be placed in the following order
- Infotainment control module (ICM)
- Multimedia module (MMM)
- Traffic message channel module (TMC) / Remote Digital Audio Receiver (RDAR)
- Audio module (AUD)
- Subwoofer module (SUB)
- Global positioning system module (GPS)
- Phone module (PHM)
- Integrated Audio Module (IAM)
Note. The control modules on the MOST network should be positioned in a particular order. If this order is not followed, troubleshooting of the MOST network will be more difficult.
When a control module is added to the MOST network, it should be placed in the correct order on the network to make it easier to fault-trace the control modules.
If the control modules are connected in another order, this does not effect the function of the MOST network, but fault-tracing will be more difficult.
The control modules should be placed in the following order
- Infotainment control module (ICM)
- Multimedia module (MMM)
- Remote Digital Audio Receiver (RDAR)
- Audio module (AUD)
- Subwoofer module (SUB)
- Phone module (PHM)
- Integrated audio module (IAM)
- Accessory USB unit (AUU)
Scheme 184
The MOST network can consist of up to nine different control modules.
The infotainment control module (ICM) deals with monitoring and communication on the MOST network. The infotainment control module (ICM) is in turn monitored by the central electronic module (CEM) on the CAN network.
The vehicle can be equipped with either a media player module (MPM) or an integrated audio module (IAM).
When the vehicle is equipped with a media player module (MPM), there are - in addition to the infotainment control module (ICM) - three control modules fitted as standard on the MOST network. These are the audio module (AUD), AM/FM tuner module (AFM) and media player module (MPM).
When the vehicle is equipped with an integrated audio module (IAM), only this, besides the infotainment control module (ICM), is fitted as standard on the MOST network.
The table below lists all the control modules which may be included in the MOST network.
Explanation
CAN = Controller Area Network, electrical network for communication.
LS CAN = low speed side of the CAN.
MOST = Media Oriented Systems Transport, fiber optic network for communication.
Master control module = Control module which monitors the MOST network.
Slave control module = Control module which supplies the MOST network functions.
Option = accessory installed at the factory during the purchase of a new car.
Accessory = after market installation.
(x) = position number in the illustration.
| Control module | Function | Communication | Other |
|---|---|---|---|
| Infotainment control module (ICM) (1) | Monitors the MOST network. | Master control module, connected to both the LS CAN and the MOST network | Included in the standard set-up of the MOST network. Must be connected to the MOST network to function. |
| Multimedia module (MMM) (2) | Displays traffic information on the directly connected display screen. | Slave module on the MOST network. | Option, accessory. |
| AM/FM tuner module (AFM) (3) | Consists of an AM/FM antenna. | Slave module on the MOST network. | Included in the standard setup of the MOST network when the vehicle is equipped with a media player module (MPM). Otherwise, available as an option, accessory. |
| Traffic message channel module (TMC) (4) | Consists of a TMC antenna and a receiver. | Slave module on the MOST network. | Option, accessory. |
| Audio module (AUD) (5) | Amplifier to which all loudspeakers except the subwoofer module (SUB) are connected. The microphone is also directly connected to this control module. | Slave module on the MOST network. | Included in the standard setup of the MOST network when the vehicle is equipped with a media player module (MPM). Otherwise, available as an option, accessory. |
| Global positioning system module (GPS) (6) | Consists of a GPS antenna. | Slave module on the MOST network. | Option, accessory. |
| Subwoofer module (SUB) (7) | Amplifier and bass speakers integrated in the same unit. | Slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the subwoofer module (SUB) to function. |
| Phone module (PHM) (8) | Controls carphone functions. | Connected to the LS CAN and is a slave module on the MOST network. | Option, accessory. |
| Media player module (MPM) (9) | Available in three versions: CD player, CD changer or combined CD and MD player. | Slave module on the MOST network. | Included in the standard setup of the MOST network when the vehicle is equipped with this control module. |
| Integrated audio module (IAM) (9) | Available in three versions: CD player, CD changer or combined CD and MD player. Has its own AM/FM aerial. The performance model has 4 loudspeakers. For the High performance and Premium models, the audio module (AUD) is required. | Slave module on the MOST network. | Included in the standard setup of the MOST network when the vehicle is equipped with this control module. |
Scheme 185
The MOST network can consist of up to nine different control modules.
The infotainment control module (ICM) deals with monitoring and communication on the MOST network. The infotainment control module (ICM) is in turn monitored by the central electronic module (CEM) on the CAN network.
The vehicle is always equipped with an Infotainment control module (ICM) and Integrated Audio Module (IAM).
In addition to these two, one or more control modules is/are connected to the MOST loop to obtain the desired functions in the vehicle.
The table below lists all the control modules which may be included in the MOST network.
Explanation
CAN = Controller Area Network, electrical network for communication.
LS CAN = low speed side of the CAN.
MOST = Media Oriented Systems Transport, fiber optic network for communication.
Master control module = Control module which monitors the MOST network.
Slave control module = Control module which supplies the MOST network functions.
Option = Factory installed accessories, during the purchase of a new car.
Accessory = After market installation.
| Control module | Function | Communication | Other |
|---|---|---|---|
| Infotainment control module (ICM) | Monitors the MOST network. | Master control module, connected to both the LS CAN and the MOST network | Included in the standard set-up of the MOST network. Must be connected to the MOST network to function. |
| Multimedia module (MMM) | Displays traffic information on the directly connected display screen. | Slave module on the MOST network. | Option, accessory. The global positioning system module (GPS) must be connected to the MOST network for the Multimedia module (MMM) to work. |
| Traffic message channel module (TMC) | Consists of a TMC antenna and a receiver. | Slave module on the MOST network. | Option, accessory. |
| Remote Digital Audio Receiver (RDAR) | Receives and decodes digital radio signals. Has a directly connected antenna. | Slave module on the MOST network. | Option, accessory. Only USA/CDN. |
| Audio module (AUD) | Amplifier to which all speakers except the subwoofer module (SUB) are connected. | Slave module on the MOST network. | Option, accessory. Included in sound systems High Performance and Premium Sound. |
| Subwoofer module (SUB) | Amplifier and bass speakers integrated in the same unit. | Slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the subwoofer module (SUB) to function. |
| Global positioning system module (GPS) | Consists of a GPS antenna. | Slave module on the MOST network. | Option, accessory. |
| Phone module (PHM) | Controls carphone functions. | Connected to the LS CAN and is a slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the Phone module (PHM) to function. |
| Integrated Audio Module (IAM) | Has its own AM/FM aerial. The performance model has 4 loudspeakers. For the High performance and Premium Sound models, the audio module (AUD) is required. | Slave module on the MOST network. | Included in the standard set-up of the MOST network. |
Scheme 186
The MOST network can consist of up to nine different control modules.
The infotainment control module (ICM) deals with monitoring and communication on the MOST network. The infotainment control module (ICM) is in turn monitored by the central electronic module (CEM) on the CAN network.
The vehicle is always equipped with an Infotainment control module (ICM) and Integrated Audio Module (IAM).
In addition to these two, one or more control modules is/are connected to the MOST loop to obtain the desired functions in the vehicle.
The table below lists all the control modules which may be included in the MOST network.
Explanation
CAN = Controller Area Network, electrical network for communication.
LS CAN = low speed side of the CAN.
MOST = Media Oriented Systems Transport, fiber optic network for communication.
Master control module = Control module which monitors the MOST network.
Slave control module = Control module which supplies the MOST network functions.
Option = Factory installed accessories, during the purchase of a new car.
Accessory = After market installation.
| Control module | Function | Communication | Other |
|---|---|---|---|
| Infotainment control module (ICM) | Monitors the MOST network. | Master control module, connected to both the LS CAN and the MOST network | Included in the standard set-up of the MOST network. Must be connected to the MOST network to function. |
| Multimedia module (MMM) | Displays traffic information on the directly connected display screen. | Slave module on the MOST network. | Option, accessory. The global positioning system module (GPS) must be connected to the MOST network for the Multimedia module (MMM) to work. |
| Remote Digital Audio Receiver (RDAR) | Receives and decodes digital radio signals. Has a directly connected antenna. | Slave module on the MOST network. | Option, accessory. Only USA/CDN. |
| Audio module (AUD) | Amplifier to which all speakers except the subwoofer module (SUB) are connected. | Slave module on the MOST network. | Option, accessory. Included in sound systems High Performance and Premium Sound. |
| Subwoofer module (SUB) | Amplifier and bass speakers integrated in the same unit. | Slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the subwoofer module (SUB) to function. |
| Phone module (PHM) | Controls carphone functions. | Connected to the LS CAN and is a slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the Phone module (PHM) to function. |
| Integrated audio module (IAM) | Has its own AM/FM aerial. The performance model has 4 loudspeakers. For the High performance and Premium Sound models, the audio module (AUD) is required. | Slave module on the MOST network. | Included in the standard set-up of the MOST network. |
| Accessory USB unit (AUU) | Enables listening to the customer's portable media players in the vehicle's speaker system via USB-port. | Slave module on the MOST network. | Option, accessory. |
Scheme 187
The MOST network can consist of up to nine different control modules.
The infotainment control module (ICM) deals with monitoring and communication on the MOST network. The infotainment control module (ICM) is in turn monitored by the central electronic module (CEM) on the CAN network.
The vehicle is always equipped with an Infotainment control module (ICM) and Integrated Audio Module (IAM).
In addition to these two, one or more control modules is/are connected to the MOST loop to obtain the desired functions in the vehicle.
The table below lists all the control modules which may be included in the MOST network.
Explanation
CAN = Controller Area Network, electrical network for communication.
LS CAN = low speed side of the CAN.
MOST = Media Oriented Systems Transport, fiber optic network for communication.
Master control module = Control module which monitors the MOST network.
Slave control module = Control module which supplies the MOST network functions.
Option = Factory installed accessories, during the purchase of a new car.
Accessory = After market installation.
| Control module | Function | Communication | Other |
|---|---|---|---|
| Infotainment control module (ICM) | Monitors the MOST network. | Master control module, connected to both the LS CAN and the MOST network | Included in the standard set-up of the MOST network. Must be connected to the MOST network to function. |
| Multimedia module (MMM) | Displays traffic information on the directly connected display screen. | Slave module on the MOST network. | Option, accessory. |
| Remote Digital Audio Receiver (RDAR) | Receives and decodes digital radio signals. Has a directly connected antenna. | Slave module on the MOST network. | Option, accessory. |
| Audio module (AUD) | Amplifier to which all speakers except the subwoofer module (SUB) are connected. | Slave module on the MOST network. | Option, accessory. Included in sound systems High Performance and Premium Sound. |
| Subwoofer module (SUB) | Amplifier and bass speakers integrated in the same unit. | Slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network for the subwoofer module (SUB) to function. |
| Phone module (PHM) | Controls carphone functions. | Connected to the LS CAN and is a slave module on the MOST network. | Option, accessory. The audio module (AUD) must be connected to the MOST network in order for the Phone module (PHM) to work. The Phone module (PHM) cannot be installed in vehicles at the same time as the Bluetooth phone module (BPM). |
| Bluetooth phone module (BPM) | Functions as a wireless link between the vehicle's infotainment system and mobile telephone equipped with Bluetooth technology. | Slave module on the MOST network. | Option, accessory. The Bluetooth phone module (BPM) cannot be installed in the vehicle at the same time as the Phone module (PHM). |
| Integrated Audio Module (IAM) | Has its own AM/FM aerial. The performance model has 4 loudspeakers. For the High performance and Premium Sound models, the audio module (AUD) is required. | Slave module on the MOST network. | Included in the standard set-up of the MOST network. |
| Accessory USB unit (AUU) | Enables listening to the customer's portable media players in the vehicle's speaker system via USB-port. | Slave module on the MOST network. | Option, accessory. |
Note. The control modules on the MOST network should be positioned in a particular order. If this order is not followed, the fault-tracing of the MOST network will deteriorate.
When a control module is added to the MOST network, it should be placed in the correct order on the network to make it easier to fault-trace the control modules.
If the control modules are connected in another order, this does not effect the function of the MOST network, but fault-tracing will be more difficult.
The control modules should be placed in the following order
- Infotainment control module (ICM)
- Multimedia module (MMM)
- Remote Digital Audio Receiver (RDAR)
- Audio module (AUD)
- Phone module (PHM)/ Bluetooth phone module (BPM)
- Integrated Audio Module (IAM)
- Accessory USB unit (AUU)
