CHECKING THE POWER SUPPLY AND GROUND TERMINALS

Voltage supply, parking assistance module (PAM)

The parking assistance module (PAM) is powered via a power input on the control module.

Power input terminal #A1 is +15-supplied via the central electronic module (CEM) and a fuse from the ignition switch. The ignition switch is powered from the battery via the integrated relay/fusebox in the engine compartment. In the event of an open-circuit, park assist cannot be activated.

Checking the power supply

Check the power supply cable from the central electronic module (CEM) to parking assistance module (PAM) terminal #A1. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Also check the power supply from the battery via the integrated relay/fusebox and the ignition switch to the central electronic module (CEM). Check the fuses. The voltage must be approximately battery voltage.

Ground terminal, parking assistance module (PAM)

Parking assistance module (PAM) has a ground input. The ground input from the control module is power ground and is connected to the ground terminal in the car body. See the relevant wiring diagram for further information about the ground terminals in the bodywork.

Checking the ground terminal

Check the ground lead between parking assistance module (PAM) terminal #A8 and the ground terminal. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. With the ignition on, the drop in voltage between the ground connection for the control module and the ground terminal must not be greater than 0.5 V.

Remedy as necessary.

Other information

1. See «CONNECTING THE BREAKOUT BOX»(ref-460881-S07979544772012033000000)
2. See «SIGNAL SPECIFICATION»(ref-472829-S21289716042012051500000) (LHD)
3. See the relevant wiring diagram for information about circuit and ground terminals in the bodywork
4. see «CONTENTS»(ref-460870-S01977592262012033000000)

Power supply, keyless vehicle module (KVM)

The keyless vehicle module (KVM) is powered via a power input on the control module.

The control module has a 30-supply from the battery via the central electronic module (CEM).

1. Power input terminal #C4 (#B4) is supplied with power via a fuse from the battery.

Checking the power supply

Check the power supply cable from the battery to the engine compartment fusebox. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Check the fuse. The voltage must be approximately battery voltage.

Check the power supply cable from the engine compartment fusebox and the central electronic module (CEM) terminal #E22 (22). Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Check the fuse. The voltage must be approximately battery voltage when the ignition is on.

Check the power supply from the central electronic module (CEM) terminal #A41(41) and keyless vehicle module (KVM) terminal #C4 (#B4). Check for an open-circuit. Check for loose connections. Check for contact resistance and oxidation. Also check the fuse on the central electronic module (CEM). The voltage must be approximately battery voltage.

Ground terminal, keyless vehicle module (KVM)

The keyless vehicle module (KVM) has a ground input. The control module is grounded in the B-post on the corresponding side where the control module is installed. See the relevant wiring diagram for further information about ground terminals.

1. Ground input terminal #C5 (#B5) is power ground and is connected to the ground terminal in the car body.

Checking the ground terminal

Check the ground lead between the keyless vehicle module (KVM) and the ground terminal. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. With the ignition on, the drop in voltage between the ground connection for the keyless vehicle module (KVM) and the ground terminal must not be greater than 0.5 V.

Remedy as necessary.

Other information

1. See «CONNECTING THE BREAKOUT BOX (2005-2007)»(ref-460881-S18426185402012033000000)
2. See «SIGNAL SPECIFICATION (2005-2007)»(ref-460883-S36271107472012033000000)
3. See the relevant wiring diagram for information about circuit and ground terminals in the bodywork
4. see «CONTENTS»(ref-460870-S01977592262012033000000) .

Power supply, keyless vehicle module (KVM)

The keyless vehicle module (KVM) is powered via a power input on the control module.

The control module has a 30-supply from the battery via the central electronic module (CEM).

1. Power input terminal #C4 (#B4) is supplied with power via a fuse from the battery.

Checking the power supply

Check the power supply cable from the battery to the engine compartment fusebox. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Check the fuse. The voltage must be approximately battery voltage.

Check the power supply cable from the engine compartment fusebox and the central electronic module (CEM) terminal #E22 (22). Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Check the fuse. The voltage must be approximately battery voltage when the ignition is on.

Check the power supply from the central electronic module (CEM) terminal #A41(41) and keyless vehicle module (KVM) terminal #C4 (#B4). Check for an open-circuit. Check for loose connections. Check for contact resistance and oxidation. Also check the fuse on the central electronic module (CEM). The voltage must be approximately battery voltage.

Ground terminal, keyless vehicle module (KVM)

The keyless vehicle module (KVM) has a ground input. The control module is grounded in the B-post on the corresponding side where the control module is installed. See the relevant wiring diagram for further information about ground terminals.

1. Ground input terminal #C5 (#B5) is power ground and is connected to the ground terminal in the car body.

Checking the ground terminal

Check the ground lead between the keyless vehicle module (KVM) and the ground terminal. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. With the ignition on, the drop in voltage between the ground connection for the keyless vehicle module (KVM) and the ground terminal must not be greater than 0.5 V.

Remedy as necessary.

Other information

1. See «CONNECTING THE BREAKOUT BOX (2008-2011)»(ref-460881-S30167096942012033000000)
2. See «SIGNAL SPECIFICATION, KEYLESS VEHICLE MODULE (KVM) (2008-2011)»(ref-460883-S42506885312012033000000)
3. See the relevant wiring diagram for information about circuit and ground terminals in the bodywork
4. see «CONTENTS»(ref-460870-S01977592262012033000000) .

CONNECTING THE BREAKOUT BOX (2005-2007)

Special tools

9511428

9512906

Scheme 1

1. Ignition off.
2. Remove fuse FX in the Central electronic module (CEM).
3. Release the Keyless vehicle module (KVM), See : «KEYLESS VEHICLE MODULE (KVM) (2005-2011)»(ref-460884-S18555340142012033000000)
4. Disconnect the connectors from the Keyless vehicle module (KVM).
5. Check in particular that the male and female terminals on the control module and the control module connector are intact, secure and cannot be pressed in. Check that the female terminal cables are securely connected
6. Especially check the pins that are in question for the diagnostic trouble code/symptom. See «SIGNAL SPECIFICATION (2005-2007)»(ref-460883-S36271107472012033000000)
7. Connect adapter «9512906»(ref-460875-S08021830602012033000000) to the connectors for the Keyless vehicle module (KVM) and connect breakout box «9511428»(ref-460875-S19859279082012033000000) to the adapter. NOTE: Before the control module functions can be checked and measurements taken, the removed fuses must first be installed.
8. The breakout box is designed to facilitate the reading of control module input and output signals when the control module is connected as well as the resistance of cables and components when the control module is disconnected. Using the breakout box reduces the risk of unintentionally short-circuiting cables or damaging pins in the connectors.

CONNECTING THE BREAKOUT BOX (2008-2011)

Special tools

9511428

9512906

CONNECTING THE BREAKOUT BOX

1. Ignition off.
2. Remove fuse FX in the Central electronic module (CEM).
3. Release the Keyless vehicle module (KVM), See: «KEYLESS VEHICLE MODULE (KVM) (2005-2011)»(ref-460884-S18555340142012033000000)
4. Disconnect the connectors from the Keyless vehicle module (KVM).
5. Check in particular that the male and female terminals on the control module and the control module connector are intact, secure and cannot be pressed in. Check that the female terminal cables are securely connected
6. Especially check the pins that are in question for the diagnostic trouble code/symptom. See «SIGNAL SPECIFICATION, KEYLESS VEHICLE MODULE (KVM) (2008-2011)»(ref-460883-S42506885312012033000000)
7. Connect adapter «9512906»(ref-460875-S08021830602012033000000) to the connectors for the Keyless vehicle module (KVM) and connect breakout box «9511428»(ref-460875-S19859279082012033000000) to the adapter. NOTE: Before the control module functions can be checked and measurements taken, the removed fuses must first be installed.
8. The breakout box is designed to facilitate the reading of control module input and output signals when the control module is connected as well as the resistance of cables and components when the control module is disconnected. Using the breakout box reduces the risk of unintentionally short-circuiting cables or damaging pins in the connectors.

Special tools

9511428

9512981

1. Ignition off
2. To expose the connectors for the parking assistance module (PAM)

Connect breakout box 9511428 to the adapter.

Parking Assistance Module (PAM)

1. Connect adapter «9512981»(ref-460875-S15700459612012033000000) to connector C1, C2 (option) and C3 connected to the control module.
2. For connector C1, terminals #C1:1-#C16 correspond to terminals #1-#16 on the breakout box.
3. For connector C2, terminals #C2:1 - #C2:12 correspond to terminals #C21 - #32 on the breakout box.
4. For connector C3, terminals #C3:1 - #C3:12 correspond to terminals #C41 - #52 on the breakout box.
