FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

FAULTY COMMUNICATION (2006, 2007)

see FAULTY COMMUNICATION (2006, 2007)

FAULTY COMMUNICATION (2008-2012)

see FAULTY COMMUNICATION (2008-2012)

FAULTY CONFIGURATION (2006, 2007)

see FAULTY CONFIGURATION (2006, 2007)

FAULTY CONFIGURATION (2008-2012)

see FAULTY CONFIGURATION (2008-2012)

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 305

Scheme 305: VERIFICATION
Scheme 305: VERIFICATION

Scheme 306

Scheme 306
Scheme 306

Scheme 307

Scheme 307
Scheme 307
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the power supply to the infotainment control module (ICM) using the VCT2000 (or appropriate scan tool). Check that the voltage is approximately battery voltage.

Is the voltage OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S05740515292012072500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

REPLACING A COMPONENT

The multimedia module (MMM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the multimedia module (MMM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. If the fault recurs, replace the multimedia module (MMM).

In the event of a permanent fault, replace the multimedia module (MMM).

Remedy as necessary.

Other information

  1. see «CONTROL MODULE INFORMATION AND ENTERTAINMENT»(ref-488435-S26530464512012072500000)
  1. Continue Refer to «INFORMATION»(ref-488541-S25102139622012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

REPLACING THE COMPONENT

The multimedia module (MMM) has registered an internal fault.

If the fault is intermittent it means that it has been registered previously but is no longer present. Intermittent faults can occur for a number of different reasons. The fault is evaluated depending on how it occurs. If the fault recurs, replace the multimedia module (MMM).

In the event of a permanent fault, replace the multimedia module (MMM).

HINT: After replacement, up to 15 minutes of mixed driving may be necessary before the control module is calibrated and displays correct traffic information.

Remedy as necessary.

Other information

  1. see «CONTROL MODULE INFORMATION AND ENTERTAINMENT»(ref-488435-S26530464512012072500000)
  1. Continue Refer to «INFORMATION»(ref-488541-S09601014652012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

The multimedia module (MMM) has registered an internal fault.

If the fault is intermittent it means that it has been registered previously but is no longer present. Intermittent faults can occur for a number of different reasons. The fault is evaluated depending on how it occurs. If the fault recurs, replace the multimedia module (MMM).

In the event of a permanent fault, replace the multimedia module (MMM).

HINT: After replacement, up to 15 minutes of mixed driving may be necessary before the control module is calibrated and displays correct traffic information.

Remedy as necessary.

Other information

  1. see «CONTROL MODULE INFORMATION AND ENTERTAINMENT»(ref-488435-S26530464512012072500000)
  1. Continue Refer to «INFORMATION»(ref-488541-S41354026602012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see INTERNAL FAULT

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

The multimedia module (MMM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the multimedia module (MMM) or may be a different type of fault which occurs on different occasions.

The problem could be due to a damaged sector on the harddrive. Transfer map information from the DVD to the hard drive in the multimedia module (MMM).

If the fault recurs, replace the multimedia module (MMM).

Other information

  1. see «CONTROL MODULE INFORMATION AND ENTERTAINMENT»(ref-488435-S26530464512012072500000)
  1. Continue Refer to «INFORMATION»(ref-488541-S15080896412012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

The fault is due to one of the following

  1. The Multimedia module (MMM) is not intended for this vehicle, for example a used control module with different software/hardware has been used. Check that the correct control module is installed in the car.
  2. Configuring the control module. Transfer map information from the DVD to the hard drive in the multimedia module (MMM).
  1. Continue Refer to «INFORMATION»(ref-488541-S31759246122012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

The remote digital audio receiver (RDAR) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the remote digital audio module (RDAR).

In the event of a permanent fault, replace the Remote Digital Audio Receiver (RDAR).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S32738626992012072500000)
  2. see «SATELLITE RADIO CONTROL MODULE»(ref-488435-S01304790962012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S31488476092012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S15528072982012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S33611831342012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S15560293722012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S33336002102012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CONFIGURATION FAULT

The vehicle's configuration file, which is stored in the central electronic module (CEM), does not indicate that the vehicle is equipped with a digital radio receiver.

  1. Remedy the fault by loading new software into the Central Electronic Module (CEM).
  1. Continue Refer to «VERIFICATION»(ref-488541-S38302145952012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S17600957252012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The control module has registered that the information about the vehicle's configuration is missing in the control module, or that it does not match the software that is downloaded in the control module.

  1. Download new software to the Remote Digital Audio Receiver (RDAR).
  1. Continue Refer to «VERIFICATION»(ref-488541-S34589142002012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S22364101232012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see CONFIGURATION FAULT

The remote digital audio receiver (RDAR) has registered internal overheating in the control module.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the remote digital audio module (RDAR). If the fault recurs, replace the remote digital audio module (RDAR).

In the event of a permanent fault, replace the Remote Digital Audio Receiver (RDAR).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S32738626992012072500000)
  2. see «SATELLITE RADIO CONTROL MODULE»(ref-488435-S01304790962012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S05129305752012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S15375628932012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING FUSES AND POWER SUPPLY

The remote digital audio receiver (RDAR) is suppled power from the central electronic module (CEM) via a fuse.

Check if the fuse for the Remote Digital Audio Receiver (RDAR) is half burned by testing with a new fuse.

HINT: A half burned fuse can cause intermittent faults.

  1. Ignition on.

Check the supply voltage to the Remote Digital Audio Receiver (RDAR) by

  1. Measure the voltage between control module connectors #C784-1 and #C784-2.
  2. Measuring the battery voltage.

If the difference between the control module's supply voltage and the battery voltage is greater than 2 V, the malfunction is in the supply cable.

If the difference is less than 2 V there may be an internal malfunction in the phone module (PHM).

  1. Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-488433-S32473177372012072500000)
  2. see «LOCATION OF COMPONENTS»(ref-488437-S32738626992012072500000)
  3. see «CONTENTS»(ref-488410-S20176265562012072500000)
  4. see «SATELLITE RADIO CONTROL MODULE»(ref-488435-S01304790962012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S01200345732012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check that the radio is working and that the reception is acceptable.

Is the radio playing through the loudspeakers?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S19445910692012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING SOFTWARE

The Bluetooth phone module (BPM) has registered that the local configuration file is the incorrect version.

This may be due to a fault in the software in the Bluetooth phone module (BPM). Remedy the fault by downloading new software into the Bluetooth phone module (BPM).

Continue after programming.

  1. Continue Refer to «VERIFICATION»(ref-488541-S11217416322012072500000)

Scheme 308

Scheme 308: VERIFICATION
Scheme 308: VERIFICATION

Scheme 309

Scheme 309
Scheme 309

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off.
  2. Restore components and connectors.
  3. Ignition on.

Check the function of the Bluetooth phone module (BPM).

Is the carphone working?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S42796005292012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Use the following information and general checks during fault-tracing.

Note. Check that the fuses are intact. For locations, see the vehicle owner's manual or cover for fuse box.

  1. Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
  2. Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
  3. Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
  4. Use VIDA (Volvo scan tool). Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
  5. Check relevant components according to Component specifications .
  6. Check relevant signals using appropriate service information regarding signal specification and breakout box .

Remedy as necessary.

Other information

  1. see «DESCRIPTION OF FROZEN VALUES»(ref-509596-S09304876612012101500000)
  2. see «STATUS IDENTIFIER, DESCRIPTION»(ref-509605-S31724754632012101500000)
  3. see «COUNTERS, DESCRIPTION»(ref-509559-S09171325382012101500000)
  4. see «DESCRIPTION OF PARAMETERS»(ref-488542-S35736830302012072500000)
  5. see «LOCATION OF COMPONENTS»(ref-488437-S00463498312012072500000)
  6. see «SIGNAL SPECIFICATION»(ref-488433-S35496156192012072500000)
  7. see «CONTENTS»(ref-488410-S20176265562012072500000)

Repair

  1. see «BLUETOOTH CONTROL MODULE (2008, 2009)»(ref-488435-S21174864172012072500000)

Scheme 310

Scheme 310
Scheme 310
  1. Continue Refer to «INFORMATION»(ref-488541-S28722727152012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

FAULTY SOFTWARE

The control module has registered that invalid or incorrect data has been obtained from the vehicle configuration file.

This can be due to a fault in the Central electronic module (CEM).

Downloading new software

Remedy the fault by loading new software into the Central Electronic Module (CEM).

After downloading new software into the central electronic module (CEM), the new software must also be downloaded into the Bluetooth phone module (BPM)

Continue after programming.

  1. Continue Refer to «VERIFICATION»(ref-488541-S13359204632012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off.
  2. Reinstall the connectors, components etc.
  3. Ignition on. Check the function of the Bluetooth phone module (BPM).

Is the carphone working?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S31867080552012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Use the following information and general checks during fault-tracing.

Note. Check that the fuses are intact. For locations, see the vehicle owner's manual or cover for fuse box.

  1. Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
  2. Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
  3. Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
  4. Use VIDA (Volvo scan tool). Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
  5. Check relevant components according to Component specifications .
  6. Check relevant signals using appropriate service information regarding signal specification and breakout box .

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-488433-S23855992902012072500000)
  2. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  3. see «CHECKING THE SUPPLY VOLTAGE/GROUND TERMINAL»(ref-488432-S22828041502012072500000)
  4. see «DESCRIPTION OF FROZEN VALUES»(ref-509596-S02454817102012101500000)
  5. see «STATUS IDENTIFIER, DESCRIPTION»(ref-509605-S31724754632012101500000)
  6. see «COUNTERS, DESCRIPTION»(ref-509559-S09171325382012101500000)

Repair

  1. see «SWITCH VOLVO ON CALL (2011)»(ref-488435-S25665483282012072500000)
  2. see «TELEPHONE HANDSET (2011)»(ref-488435-S14571305732012072500000)
  3. see «ANTENNA, GLOBAL POSITIONING SYSTEM MODULE (GPS) (2011)»(ref-488435-S10549327772012072500000)
  4. see «BATTERY VOLVO ON CALL (2011)»(ref-488435-S14977186812012072500000)
  5. see «SIM CARD READER (2011)»(ref-488435-S04422966052012072500000)
  6. see «MICROPHONE TELEPHONE (2011)»(ref-488435-S00977116972012072500000)
  7. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «INFORMATION»(ref-488541-S13138006152012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S16901637352012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S27136586782012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S15613084942012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S11666148162012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S20868476142012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S29261653822012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S06949133382012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The phone module (PHM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the phone module (PHM).

In the event of a permanent fault, replace the phone module (PHM).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S36851453372012072500000)

Erase DTCs and reread the DTCs from the Phone module (PHM) using the VCT2000 (or appropriate scan tool).

Note. After erasing DTCs there is a delay to ensure that the diagnostics for the Phone module (PHM) have been carried out.

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Scheme 311

Scheme 311: VERIFICATION
Scheme 311: VERIFICATION

Are the diagnostic trouble code (DTCs) still stored?

  1. YES Refer to «INFORMATION»(ref-488541-S32957791632012072500000)
  2. NO OKAY: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The phone module (PHM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference at start up of the control module or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. If the fault recurs, replace the control module.

In the event of a permanent fault, replace the control module. See PHONE MODULE (PHM) (2011) .

Remedy as necessary.

  1. Continue Refer to «INFORMATION»(ref-488541-S33509461802012072500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S25546932542012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The phone module (PHM) has registered a fault on the integrated GSM/GPRS unit.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the phone module (PHM).

In the event of a permanent fault, replace the phone module (PHM).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S03860638932012072500000)

Erase DTCs and reread the DTCs from the Phone module (PHM) using the VCT2000 (or appropriate scan tool).

Note. After erasing DTCs there is a delay to ensure that the diagnostics for the Phone module (PHM) have been carried out.

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Are the diagnostic trouble code (DTCs) still stored?

  1. YES Refer to «INFORMATION»(ref-488541-S13986983332012072500000)
  2. NO OKAY: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see INTERNAL FAULT

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S36310492622012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S31540847822012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

  1. Ignition off. The diagnostic trouble code (DTC) is stored when the calculated capacity of the reserve battery is too low. Replace the reserve battery. See see «BATTERY VOLVO ON CALL (2011)»(ref-488435-S14977186812012072500000) Remedy as necessary. Other information: see «LOCATION OF COMPONENTS»(ref-488437-S29140510632012072500000) see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S27636611442012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S29053532982012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition off. The phone module (PHM) has detected a fault in the internal antenna for Volvo On Call functionality. This type of fault means that the control module must be replaced. Replace the carphone module (PHM). See see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000) Remedy as necessary. Other information: see «LOCATION OF COMPONENTS»(ref-488437-S29140510632012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S42413520662012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S20649385662012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The Phone module (PHM) has registered a fault on the internal SIM card.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the phone module (PHM).

In the event of a permanent fault, replace the phone module (PHM).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S03821871672012072500000)

Erase DTCs and reread the DTCs from the Phone module (PHM) using the VCT2000 (or appropriate scan tool).

Note. After erasing DTCs there is a delay to ensure that the diagnostics for the Phone module (PHM) have been carried out.

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Are the diagnostic trouble code (DTCs) still stored?

  1. YES Refer to «INFORMATION»(ref-488541-S06693070042012072500000)
  2. NO OKAY: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition off. The phone module (PHM) has detected a fault in the internal SIM card for the Volvo On Call subscription. This type of fault means that the control module must be replaced. Replace the carphone module (PHM). See see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000) Remedy as necessary. Other information: see «LOCATION OF COMPONENTS»(ref-488437-S29140510632012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S32619911492012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S26032934902012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. Troubleshooting of this diagnostic trouble code requires that you delete diagnostic trouble codes, that is, why this diagnostic trouble code should be checked last of the diagnostic trouble codes in the Phone module (PHM).

Erase DTCs from the Phone module (PHM) and restart the control module using the VCT2000 (or appropriate scan tool). Continue according to the instructions there.

If the diagnostic trouble code is intermittent the problem has been solved during restart.

If the diagnostic trouble code is permanent, replace Phone module (PHM).

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)

Was a fault detected?

  1. YES Refer to «VERIFICATION»(ref-488541-S40665618552012072500000)
  2. NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Erase DTCs and reread the DTCs from the Phone module (PHM) using the VCT2000 (or appropriate scan tool).

Note. After erasing DTCs there is a delay to ensure that the diagnostics for the Phone module (PHM) have been carried out.

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Are the diagnostic trouble code (DTCs) still stored?

  1. YES Refer to «INFORMATION»(ref-488541-S13987632732012072500000)
  2. NO OKAY: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE COMPONENT

Change the switches for Volvo On Call. Check that the lighting in the switches works by altering the lighting intensity on the buttons.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «SWITCH VOLVO ON CALL (2011)»(ref-488435-S25665483282012072500000)

Does the lighting work?

  1. YES Refer to «VERIFICATION»(ref-488541-S42532556572012072500000)
  2. NO Refer to «INFORMATION»(ref-488541-S27902854602012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off.
  2. Reinstall the connectors, components etc.
  3. Ignition on.

Check the carphone by making a call.

Read diagnostic trouble codes using the VCT2000 (or appropriate scan tool).

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Is the carphone working?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S27902854602012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S37533240862012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S31715390232012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S33548080872012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S34001981602012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition off. Check that the internal reserve battery for Volvo On Call is correctly connected. Check the connector. Remedy as necessary. Other information see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000) see «BATTERY VOLVO ON CALL (2011)»(ref-488435-S14977186812012072500000) see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S20830723832012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off.
  2. Reinstall the connectors, components etc.
  3. Ignition on.

Erase and read out DTCs using the VCT2000 (or appropriate scan tool).

A spare battery check will be performed in connection with reading off the diagnostic trouble codes (DTCs).

Check that the diagnostic trouble code has disappeared or changed status to intermittent.

Is the carphone working?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S13040591012012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition off. Check that the internal reserve battery for Volvo On Call is correctly connected. Check the connector. Remedy as necessary. Other information: see «LOCATION OF COMPONENTS»(ref-488437-S29140510632012072500000) see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000) see «BATTERY VOLVO ON CALL (2011)»(ref-488435-S14977186812012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S17911915322012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off.
  2. Reinstall the connectors, components etc.
  3. Ignition on.

Erase and read out DTCs using the VCT2000 (or appropriate scan tool).

A spare battery check will be performed in connection with reading off the diagnostic trouble codes (DTCs).

Check that the diagnostic trouble code has disappeared or changed status to intermittent.

Is the carphone working?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S39619164222012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S21231383502012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The Phone module (PHM) has registered an internal memory fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference upon start-up or may be another type of fault that can recur at different times. The fault is evaluated depending on how it occurs. If the fault recurs, replace the phone module (PHM).

In the event of a permanent fault, replace the phone module (PHM).

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-488437-S34919709752012072500000)
  2. see «PHONE MODULE (PHM) (2011)»(ref-488435-S38294423722012072500000)
  1. Continue Refer to «VERIFICATION»(ref-488541-S10777622072012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Erase DTCs and reread the DTCs from the Phone module (PHM) using the VCT2000 (or appropriate scan tool).

Note. After erasing DTCs there is a delay to ensure that the diagnostics for the Phone module (PHM) have been carried out.

Check that the current DTC has disappeared or changed status from permanent to intermittent fault.

Are the diagnostic trouble code (DTCs) still stored?

  1. YES Refer to «INFORMATION»(ref-488541-S42038191112012072500000)
  2. NO OKAY: Troubleshooting has been completed.

see INTERNAL FAULT

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

Has the status of the diagnostic trouble code (DTC) changed?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-488541-S23737550062012072500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Problems with the local parameter file are remedied by downloading new software to the Phone module (PHM).

  1. Load new software into the control module.
  1. Continue Refer to «VERIFICATION»(ref-488541-S08790050282012072500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the carphone. Make a call so that both the handset and the hands-free system are used. See the manufacturer's instruction manual. Ignition off. Ignition on. Read off the diagnostic trouble codes (DTCs). Check that the relevant diagnostic trouble code (DTC) has switched status from permanent to intermittent fault.

More articles — Infotainment Control Module, Multimedia Module, Rdar Module, Bluetooth Phone Module, and Phone Module - Diagnostic Trouble Codes
