RESISTANCE VALUES, EVAPORATOR TEMPERATURE SENSOR
The component specification gives the value of the component without the connector connected.
Scheme 10
| Measurement values, resistance | Other |
|---|---|
| 55 °C = approximately 288.9 kohms -50 °C = approximately 201.0 kohms -45 °C = approximately 141.5 kohms -40 °C = approximately 100.9 kohms -35 °C = approximately 72.8 kohms -30 °C = approximately 53.1 kohms -25 °C = approximately 39.1 kohms -20 °C = approximately 29.1 kohms -15 °C = approximately 21.9 kohms -10 °C = approximately 16.6 kohms -5 °C = approximately 12.7 kohms 0 °C = approximately 9.8 kohms 5 °C = approximately 7.6 kohms 10 °C = approximately 6.0 kohms 15 °C = approximately 4.7 kohms 20 °C = approximately 3.8 kohms 25 °C = approximately 3.0 kohms 30 °C = approximately 2.4 kohms 35 °C = approximately 2.0 kohms 40 °C = approximately 1.6 kohms 45 °C = approximately 1.3 kohms 50 °C = approximately 1.1 kohms 55 °C = approx. 895.9 ohms 60 °C = approx. 746.4 ohms 65 °C = approx. 624.9 ohms 70 °C = approx. 525.6 ohms 75 °C = approx. 444.4 ohms 80 °C = approx. 377.4 ohms | Measure the resistance between terminals #1 and #2. |
TEMPERATURE SENSOR VALUES
RESISTANCE VALUES, PASSENGER COMPARTMENT TEMPERATURE SENSOR
The component specification gives the value of the component without the connector connected.
Scheme 11
| Measurement values, resistance | Other |
|---|---|
| 40 °C = approximately 207.1 kohms -30 °C = approximately 118.9 kohms -20 °C = approximately 70.8 kohms -10 °C = approximately 43.6 kohms 0 °C = approximately 27.6 kohms 10 °C = approximately 18.0 kohms 20 °C = approximately 12.0 kohms 25 °C = approximately 9.9 kohms 30 °C = approximately 8.2 kohms 40 °C = approximately 5.7 kohms 50 °C = approximately 4.0 kohms 60 °C = approximately 2.9 kohms | Measure the resistance between terminals #3 and #5. Only for the ECC version of the climate control module (CCM). |
TEMPERATURE SENSOR VALUES
