SIGNAL DESCRIPTION CENTRAL ELECTRONIC MODULE (CEM)
General
All the values given below are between the connections in column 1 and connection #A28 in column 2 (power ground). This applies unless otherwise indicated in the last column.
Note. It is important to connect the breakout box and check the ground terminals before taking readings.
| U= | DC voltage in volts (V) | T = | Time in milliseconds (ms) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | % duty | Duty cycle (pulse ratio) as a percentage (%) |
Scheme 242
| Connector E, Front-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #E1 | Transmission control module (TCM), signal supply | Ubat at ignition in position II; Ulow otherwise | ||
| #2 | #E2 | Electrical power steering module (EPS), signal supply | Ubat at ignition in position II; Ulow otherwise | ||
| #3 | #E3 | Brake control module (BCM), signal supply | Ubat at ignition in position I; Ulow otherwise | ||
| #4 | #E4 | Reserve | |||
| #5 | #E5 | Reserve | |||
| #6 | #E6 | Reserve | |||
| #7 | #E7 | Reserve | |||
| #8 | #E8 | Windshield washer motor, power supply | Ulow | Ubat/Ulow | |
| #9 | #E9 | Reserve | |||
| #10 | #E10 | Engine control module (ECM), waking | Ulow | Ubat/Ulow | |
| #11 | #E11 | High beam right-hand, power supply | Ulow | Ubat/Ulow | |
| #12 | #E12 | Tailgate washer motor, power supply | Ulow | Ubat/Ulow | |
| #13 | #E13 | Front left-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #14 | #E14 | Back-up (reversing) lamp, check signal | Ulow | Ulow/Ubat | |
| #15 | #E15 | Reserve | |||
| #16 | #E16 | Reserve | |||
| #17 | #E17 | Reserve | |||
| #18 | #E18 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #19 | #E19 | Reserve | |||
| #20 | #E20 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #21 | #E21 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #22 | #E22 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #23 | #E23 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #24 | #E24 | Reserve | |||
| #25 | #E25 | Low beam left, power supply | Ubat/Ulow | Ubat/Ulow | |
| #26 | #E26 | Reserve | |||
| #27 | #E27 | Full beam left, power supply | Ulow | Ubat/Ulow | |
| #28 | #E28 | Stop lamp switch, power supply | Ulow/Ulow | Ulow/Ubat | |
| #29 | #E29 | Gas discharge lamp module (GDL), power supply | Ulow | Ulow/Ubat | |
| #30 | #E30 | Reserve | |||
| #31 | #E31 | Reserve | |||
| #32 | #E32 | Reserve | |||
| #33 | #E33 | Reserve | |||
| #34 | #E34 | Reserve | |||
| #35 | #E35 | Reserve | |||
| #36 | #E36 | Siren, power supply | Ubat | Ubat | |
| #37 | #E37 | Low beam right-hand, power supply | Ulow | Ubat/Ulow | |
| #38 | #E38 | Front left-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #39 | #E39 | Front right-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #40 | #E40 | Stop lamp switch, check signal to ECM | Ubat/Ulow | Ubat/Ulow | |
| #41 | #E41 | Stop lamp switch, control signal | Ubat/Ulow | Ubat/Ulow | |
Scheme 243
| Connector G, Front-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #G1 | Communication LIN bus 3 | During communication the voltage is 0V - Ubat | Siren control module (SCM) | |
| #2 | #G2 | Front right-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #3 | #G3 | Communication LIN bus 9 | During communication the voltage is 0V - Ubat | WMM | |
| #4 | #G4 | Reserve | |||
| #5 | #G5 | Reserve | |||
| #6 | #B6 | Battery temperature sensor, ground | Ulow | Ulow | The battery temperature gauge removed from and including structure week 200605 |
| #7 | #G7 | Accelerator pedal (AP) position sensor, check signal | Ulow | Ulow | |
| #8 | #G8 | Reserve | |||
| #9 | #G9 | Relay, front fog lamp, control signal | Ubat | Ulow/Ubat | |
| #10 | #G10 | Reserve | |||
| #11 | #G11 | Relay, headlamp wash / wipe, control signal | Ubat | Ulow/Ubat | |
| #12 | #G12 | Clutch pedal sensor, check signal | Ulow | Ulow | |
| #13 | #G13 | Battery temperature sensor, signal | Ulow | U=0V-5V | The battery temperature gauge removed from and including structure week 200605 |
| #14 | #G14 | Communication CAN_L high speed network | The voltage is 1.5-2.5 V during communication | Electrical power steering module (EPS) / Brake control module (BCM) / Body sensor cluster (BSC) / Transmission control module (TCM) / Integrated Starter Generator (ISG) | |
| #15 | #G15 | Communication CAN_H high speed network | The voltage is 2.0-3.5 V during communication | Electrical power steering module (EPS) / Brake control module (BCM) / Body sensor cluster (BSC) / Transmission control module (TCM) / Integrated Starter Generator (ISG) | |
| #16 | #G16 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | Combustion preheater module (CPM) | |
| #17 | #G17 | Reserve | |||
| #18 | #G18 | Relay, horn, control signal | Ulow/Ubat | Ulow/Ubat | |
| #19 | #G19 | Hood switch | Ulow with the hood closed Ulow-Ubat with the hood open | Pulsed signal, f=100Hz | |
| #20 | #G20 | Reserve | |||
| #21 | #G21 | Clutch pedal sensor, power supply | Ulow | U=5 V | |
| #22 | #G22 | Accelerator pedal (AP) position sensor, power supply | Ulow | U=5 V | |
| #23 | #G23 | Clutch pedal sensor, power supply | Ulow | U=0.15-4.75V | |
| #24 | #G24 | Clutch pedal sensor, power supply | Ulow | Ulow/Ubat | I4-motor |
| #25 | #G25 | Reserve | |||
| #26 | #G26 | Communication LIN bus 2 | During communication the voltage is 0V - Ubat | Xenon lamps (GDL) | |
| #27 | #G27 | Switch, brake fluid level | Ulow at normal level; Ubat at low level | ||
| #28 | #G28 | Switch, washer fluid level | Ulow at normal level; Ubat at levels below 0.7 liters | ||
| #29 | #G29 | Reserve | |||
| #30 | #G30 | Engine control module (ECM), collision signal | Ulow/Ubat | Ulow/Ubat | Diesel only |
| #31 | #G31 | Accelerator pedal (AP) position sensor, check signal | Ulow | U=0.15-4.85V | |
| #32 | #G32 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Combustion preheater module (CPM) | |
Scheme 244
| Connector A, Cockpit-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #A1 | Dimmer, check signal | Ulow | Ulow-Ubat | |
| #2 | #A2 | Reserve | |||
| #3 | #A3 | Positive temperature coefficient (PTC) heater, signal supply | Ubat at ignition in position II; Ulow otherwise | ||
| #4 | #A4 | Data link connector (DLC), power supply | Ubat | Ubat | |
| #5 | #A5 | Reserve | |||
| #6 | #A6 | Reserve | |||
| #7 | #A7 | Reserve | |||
| #8 | #A8 | Phone module (PHM), power supply | Ulow | Ubat | |
| #9 | #A9 | Multimedia module (MMM) display, power supply | Ulow | Ubat | |
| #10 | #A10 | Supplemental restraint system module (SRS), 15-power supply | Ulow | Ubat | |
| #11 | #A11 | Reserve | |||
| #12 | #A12 | Reserve | |||
| #13 | #A13 | Reserve | |||
| #14 | #A14 | CEM, signal ground | Ulow | Ulow | |
| #15 | #A15 | S-supply (Power supply from ignition switch) | Ulow (Key out), Ubat (key in) | ||
| #16 | #A16 | X-supply to passenger compartment, power supply | Ubat at ignition in positions I and II; Ulow otherwise | ||
| #17 | #A17 | 15-supply (Power supply from ignition switch) | Ubat (Key in positions II and III); Ulow otherwise | ||
| #18 | #A18 | Steering wheel module (SWM), power supply | Ubat | Ubat | |
| #19 | #A19 | Audio module (AUD), 30-supply | Ubat | Ubat | |
| #20 | #A20 | Reserve | |||
| #21 | #A21 | Climate control module (CCM), infotainment control module (ICM), power supply | Ulow | Ubat | |
| #22 | #A22 | Reserve | |||
| #23 | #A23 | Cigarette lighter, power supply | Ubat | Ubat | |
| #24 | #A24 | Reserve | |||
| #25 | #A25 | Courtesy lighting, power supply | Ubat/Ulow | Ubat/Ulow | |
| #26 | #A26 | Reserve | |||
| #27 | #A27 | Reserve | |||
| #28 | #A28 | Power ground | Ulow | Ulow | |
| #29 | #A29 | Multimedia module (MMM), power supply | Ulow | Ubat | |
| #30 | #A30 | X-supply (Power supply from the ignition switch) | Ubat (Key in positions I and II); Ulow otherwise | ||
| #31 | #A31 | Reserve | |||
| #32 | #A32 | LED front fog lamp, ground | Ubat | Ulow | |
| #33 | #A33 | Phone module (PHM), collision signal | Airbag not triggered = Ubat-8V Airbag triggered= Pulse 1-0.6V below 200ms | ||
| #34 | #A34 | Fuel tank filler cover switch, check signal | Ulow | Ubat/Ulow | |
| #35 | #A35 | Remote receiver (RRX), signal | During communication the voltage is 0V - Ubat | ||
| #36 | #A36 | Reserve | |||
| #37 | #A37 | Reserve | |||
| #38 | #A38 | Driver information module (DIM) / glove compartment lighting, power supply | Ubat (Key in positions I and II); Ulow otherwise | ||
| #39 | #A39 | Back-up gear inhibitor, control signal | Ubat at speeds above 25 km/h; Ulow at speeds below 15 km/h | Manual 6-speed transmission | |
| #40 | #A40 | Light switch, power supply | Ubat | Ubat | |
| #41 | #A41 | Remote receiver (RRX), voltage feed | Ubat | Ubat | |
| #42 | #A42 | 50-supply (Power supply from ignition switch) | Ubat (Key in position III); Ulow otherwise | ||
| #43 | #A43 | Supplemental restraint system module (SRS), X-power supply | Ubat (Key in positions I and II); Ulow otherwise | ||
| #44 | #A44 | Climate control system motors and sensors, power supply | Ulow | Ubat | |
| #45 | #A45 | Steering wheel module (SWM), power supply | Ubat (Key in positions I and II); Ulow otherwise | ||
| #46 | #A46 | Reserve | |||
| Connector B, Cockpit-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #B1 | Positive temperature coefficient (PTC) heater, control signal | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #2 | #B2 | Light switch, control signal | Ulow/Ubat | Ulow/Ubat | Light switch in position 1 |
| #3 | #B3 | Lamp, switch, hazard warning signal flashers, power supply | Ubat-Ulow if activated; Ulow otherwise | ||
| #4 | #B4 | Light switch, control signal | Ulow/Ubat | Ulow/Ubat | Light switch in position 0 |
| #5 | #B5 | Alarm LED, power supply | Alarm activated: 5V 0.5Hz 5% duty Alarm triggered: 5V 4Hz 25% duty | Pulse width modulation (PWM) signal | |
| #6 | #B6 | Rear fog lamp LED in light switch, power supply | Ulow | Ubat/Ulow | |
| #7 | #B7 | Reserve | |||
| #8 | #B8 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | Infotainment control module (ICM) / Driver information module (DIM) | |
| #9 | #B9 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Infotainment control module (ICM) / Driver information module (DIM) | |
| #10 | #B10 | Steering column lock module (SCL), power supply | Ubat approx. one second after the key has been inserted or removed; Ulow otherwise | ||
| #11 | #B11 | Diagnostic communication (CAN H) for the high speed network | The voltage is 2.0-3.5 V during communication | ||
| #12 | #B12 | Diagnostic communication (CAN_L) for the high speed network | The voltage is 1.5-2.5 V during communication | ||
| #13 | #B13 | Key lock ignition switch, control signal | Ulow when key approved; Ubat otherwise | ||
| #14 | #B14 | Malfunction indicator lamp (MIL), power supply | Ulow | Ubat/Ulow | |
| #15 | #B15 | Diagnostic communication (CAN_L) for the low speed network | The voltage is 1.5-2.5 V during communication | ||
| #16 | #B16 | Diagnostic communication (CAN_H) for the low speed network | The voltage is 2.0-3.5 V during communication | ||
| #17 | #B17 | Communication LIN bus 2 | During communication the voltage is 0V - Ubat | Steering column lock module (SCL) / start control module (SCU) | |
| #18 | #B18 | Blower fan motor, control signal | Blower fan activated: Ubat f=400Hz 16-95% duty | Pulse width modulation (PWM) signal | |
| #19 | #B19 | Switch hazard warning signal flashers, control signal | Ulow/Ubat | Ulow/Ubat | |
| #20 | #B20 | Reserve | |||
| #21 | #B21 | Dimmer, control signal | Ulow | Ubat/Ulow | |
| #22 | #B22 | Switch, rear fog lamp, control signal | Ulow/Ubat | Ulow/Ubat | |
| #23 | #B23 | Switch, front fog lamp, control signal | Approx. 6-7V /Ubat | Approx. 6-7V /Ubat | |
| #24 | #B24 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | Phone module (PHM) | |
| #25 | #B25 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Phone module (PHM) | |
| #26 | #B26 | Switch horn, check signal | Ulow/Ubat | Ulow/Ubat | |
| #27 | #B27 | Switch privacy lock, check signal | Ubat | Ulow/Ubat | |
| #28 | #B28 | Sun sensor, ground | Ulow | Ulow | |
| #29 | #B29 | Twilight sensor | Ulow | U=5 V | |
| #30 | #B30 | Sun sensor, check signal | Ulow | U=0.25-4.75V | |
| #31 | #B31 | Switch high beam flash, check signal | Ubat | Ulow/Ubat | |
| #32 | #B32 | Blower fan motor, check signal | Fan OK and active: Amplitude = Ubat, f = 80 - 600 Hz, 50 % duty. Fan OK, but input signal outside tolerance: Amplitude = Ubat, f = 12.5 Hz, 50 % duty. Fan OK, but not active: Amplitude = Ubat, f = 0Hz, 100 % duty. | Pulse width modulation (PWM) signal | |
| Connector C, Floor-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #C1 | Switch parking brake, check signal | Ubat | Ulow/Ubat | |
| #2 | #C2 | Fuel tank filler cover, control signal | Ubat/Ulow | Ubat/Ulow | |
| #3 | #C3 | Left-hand stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #4 | #C4 | Right-hand stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #5 | #C5 | Reserve | |||
| #6 | #C6 | Rear fog lamp, power supply | Ulow | Ubat/Ulow | |
| #7 | #C7 | High level stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #8 | #C8 | Unlocking tailgate, control signal | Ulow | Ubat/Ulow | |
| #9 | #C9 | Rear left-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #10 | #C10 | Rear right-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #11 | #C11 | Reserve | |||
| #12 | #C12 | Rear right-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #13 | #C13 | License plate lighting, power supply | Ubat/Ulow | Ubat/Ulow | |
| #14 | #C14 | Rear left-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #15 | #C15 | Reserve | |||
| #16 | #C16 | Fuel pump (FP), power supply | Ulow | Ubat/Ulow | |
| #17 | #C17 | Subwoofer module (SUB), power supply | Ulow | Ubat/Ulow | |
| #18 | #C18 | Rear seat belt buckle, X-supply | Ulow | Ubat | |
| #19 | #C19 | Reserve | |||
| #20 | #C20 | Cargo compartment lighting and power seat, power supply | Ubat/Ulow | Ubat/Ulow | Supply from relay, interior lighting |
| #21 | #C21 | Left-hand rear door module (LDM), power supply | Ubat | Ubat | |
| #22 | #C22 | 12 V output cargo compartment, power supply | Ubat | Ubat | |
| #23 | #C23 | Audio module (AUD), power supply | Ubat | Ubat | |
| #24 | #C24 | Passenger door module (PDM), power supply | Ubat | Ubat | |
| #25 | #C25 | Reserve | |||
| #26 | #C26 | Reserve | |||
| #27 | #C27 | Right-hand rear door module (RDM), power supply | Ubat | Ubat | |
| #28 | #C28 | Relay, rear windshield defroster, control signal | Ulow | Ubat/Ulow | |
| #29 | #C29 | Passenger power seat module (PSM), power supply | Ubat | Ubat | |
| #30 | #C30 | Power seat module (PSM), power supply | Ubat | Ubat | |
| #31 | #C31 | Driver door module (DDM), power supply | Ubat | Ubat | |
| #32 | #C32 | Keyless vehicle module (KVM), signal | At communication the voltage is Ubat-(1-1.5) V | ||
| #33 | #C33 | Rear windshield wiper, power supply | Ubat | Ubat | |
| #34 | #C34 | Rear windshield wiper, control signal | Ulow | Ubat/Ulow | Signal from relay, rear windshield wiper |
| #35 | #C35 | Reserve | |||
| #36 | #C36 | Reserve | |||
| #37 | #C37 | Occupant weight sensor (OWS), power supply | Ubat | Ubat | |
| #38 | #C38 | Tow hitch and back-up (reversing) warning, power supply | Ulow | Ubat | |
| #39 | #C39 | Differential electronic module (DEM), power supply | Ulow | Ubat | |
| #40 | #C40 | Audio module (AUD), power supply | Ubat at key in positions I and II; Ulow otherwise | Power supply from Relay, infotainment | |
| #41 | #C41 | Keyless vehicle module (KVM), power supply | Ubat | Ubat | |
| #42 | #C42 | Passenger seat heater, power supply | Ubat | Ubat | Power supply from relay, comfort |
| #43 | #C43 | Driver seat heater, power supply | Ubat | Ubat | Power supply from relay, comfort |
| #44 | #C44 | Antenna module (ATM), power supply | Ubat | Ubat | |
| #45 | #C45 | Back-up (reversing) lamp, power supply | Ulow | Ubat/Ulow | Power supply from relay, back-up (reversing) lamp |
| #46 | #C46 | Reserve | |||
| Connector F, Floor-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #F1 | Rear left-hand seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #2 | #F2 | Rear center seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #3 | #F3 | Rear right-hand seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #4 | #F4 | Reserve | |||
| #5 | #F5 | Fuel level sensor pump side, check signal | Ulow | U=0.5-4V | Full: 0.5V Empty: 4V |
| #6 | #F6 | Reserve | |||
| #7 | #F7 | Fuel level sensor, common ground | Ulow | Ulow | |
| #8 | #F8 | Reserve | |||
| #9 | #F9 | Fuel level sensor AWD, ground | Ulow | Ulow | AWD |
| #10 | #F10 | Reserve | |||
| #11 | #F11 | Reserve | |||
| #12 | #F12 | Collision | Activated = 2-8V Not activated = 8-12V | ||
| #13 | #F13 | Input signal seat belt reminder passenger | Ulow | U=0-5V | Oscillating signal in 3 phases |
| #14 | #F14 | Communication CAN_L high speed network | The voltage is 1.5-2.5 V during communication | Steering wheel module (SWM) / Differential electronic module (DEM) | |
| #15 | #F15 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Supplemental restraint system module (SRS) / Driver door module (DDM) / Passenger door module (PDM) | |
| #16 | #F16 | Communication CAN_H high speed network | The voltage is 2.0-3.5 V during communication | Steering wheel module (SWM) / Differential electronic module (DEM) | |
| #17 | #F17 | Input/output signal seat belt reminder passenger | Ulow | U=0-5V | Oscillating signal in 3 phases |
| #18 | #F18 | Switch passenger door, check signal | Ubat if the door is open; Ulow otherwise | ||
| #19 | #F19 | Switch driver's door, check signal | Ubat if the door is open; Ulow otherwise | ||
| #20 | #F20 | Switch right-hand rear door, check signal | Ubat if the door is open; Ulow otherwise Applies to C30: Ubat | Applies to C30: tampering protection for cable harness in tailgate | |
| #21 | #F21 | Switch left-hand rear door, check signal | Ubat if the door is open; Ulow otherwise Applies to C30: Ulow | Applies to C30: glass wire in rear window | |
| #22 | #F22 | Handle tailgate, check signal | Ulow/Ubat | Ulow/Ubat | Grounded when the tailgate handle is pressed in. |
| #23 | #F23 | Reserve | |||
| #24 | #F24 | Switch tailgate, check signal | Ubat if the tailgate is open; Ulow otherwise | ||
| #25 | #F25 | Fuel level sensor ejector side, check signal | Ulow | U=0.5-4V | Full: 0.5V Empty: 4V (AWD) |
| #26 | #F26 | Reserve | |||
| #27 | #F27 | Reserve | |||
| #28 | #F28 | Outside temperature sensor, signal ground | Ulow | Ulow | |
| #29 | #F29 | Reserve | |||
| #30 | #F30 | Communication CAN_H low speed network | The voltage is 2.0-3.5 V during communication | Supplemental restraint system module (SRS) / Driver door module (DDM) / Passenger door module (PDM) | |
| #31 | #F31 | Outside temperature sensor, check signal | Ulow | U=0.5-4V | |
| #32 | #F32 | Reserve | |||
| Connector H, Roof-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #15 | #H1 | LED seat belt reminder, power supply | Ulow | Ubat/Ulow | |
| #16 | #H2 | LED reduced alarm position, power supply | Ulow | Ubat/Ulow | |
| #17 | #H3 | Remote Keyless Entry (RKE), signal | At communication the voltage is Ubat-(1-1.5) V | ||
| #18 | #H4 | Roof console and sun roof motor, power supply | Ubat | Ubat | |
| #19 | #H5 | Automatic anti-glare door mirror inhibitor, control signal | Ulow | Ubat/Ulow | |
| #20 | #H6 | Remote Keyless Entry (RKE), power supply | Ubat | Ubat | |
| #21 | #H7 | Rain sensor module (RSM), power supply | Ubat | Ubat | |
| #22 | #H8 | Communication CAN_H low speed network | The voltage is 2.0-3.5 V during communication | AEM | |
| #23 | #H9 | Reserve | |||
| #24 | #H10 | Reserve | |||
| #25 | Terminal #H11 | Reserve | |||
| #26 | Terminal #H12 | Reserve | |||
| #27 | Terminal #H13 | Reserve | |||
| #28 | #H14 | Reserve | |||
| #29 | #H15 | Reserve | |||
| #30 | #H16 | Reserve | |||
| #31 | #H17 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), communication signal | Ulow-Ubat | Ulow-Ubat | Communication with both MMS or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), for 5DRS |
| #32 | #H18 | Control signal, comfort closing | Ulow | Ulow/Ubat | |
| #33 | #H19 | Switch reduced alarm position, control signal | Ubat | Ulow/Ubat | |
| #34 | #H20 | Control signal, sun roof | Ulow | Ubat-Ulow/Ulow | F=1.381*speed (Km/h), 50% pulse ratio. |
| #35 | #H21 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), voltage feed | Ubat/Ulow | Ubat/Ulow | Feeds voltage to both MMS or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), for 5DRS. |
| #36 | #H22 | PAD warning lamp, power supply | Ulow | Ubat/Ulow | |
| #37 | #H23 | Communication LIN bus 9 | During communication the voltage is 0V - Ubat | Rain sensor module (RSM) | |
| #38 | #H24 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | AEM | |
| #39 | #H25 | Reserve | |||
| #40 | #H26 | Reserve | |||
| #41 | #H27 | Reserve | |||
| #42 | #H28 | Reserve | |||
| #43 | #H29 | Reserve | |||
| #44 | #H30 | Reserve | |||
| #45 | #H31 | Reserve | |||
| #46 | #H32 | Reserve | |||
Scheme 245
| Connector D, Roof-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #D1 | Reserve | |||
| #2 | #D2 | Reserve | |||
| #3 | #D3 | Roof lighting, return cable | Ulow | Ulow | |
| #4 | #D4 | Dimmer, check signal | Ulow | Ulow-Ubat | |
| #5 | #D5 | High level stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | 4 door |
| #6 | #D6 | Reserve | |||
| #7 | #D7 | Roof lighting, power supply | Ubat/Ulow | Ubat/Ulow | |
| #8 | #D8 | Reserve | |||
| #9 | #D9 | Accessory electronic module (AEM) ground | Ulow | Ulow | |
| #10 | #D10 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl model year 2012), rain sensor (RSM) and Remote Keyless Entry (RKE), ground | Ulow | Ulow | |
| #11 | #D11 | Reserve | |||
| #12 | #D12 | Roof console and sun roof, ground | Ulow | Ulow | |
| #13 | #D13 | Reserve | |||
| #14 | #D14 | Sun roof control module, power supply | Ubat (for 5 minutes only according to the conditions on the right) | Ubat | Active when the ignition is off and neither of the front doors have been opened |
General
All the values given below are between the connections in column 1 and connection #A28 in column 2 (power ground). This applies unless otherwise indicated in the last column.
Note. It is important to connect the breakout box and check the ground terminals before taking readings.
| U= | DC voltage in volts (V) | T = | Time in milliseconds (ms) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | % duty | Duty cycle (pulse ratio) as a percentage (%) |
| Connector E, Front-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #E1 | Headlamp Control Module (HCM) & ABL/GDL signal feed | Ubat at ignition in position II; Ulow otherwise | ||
| #2 | #E2 | Electrical power steering module (EPS), signal supply | Ubat at ignition in position II; Ulow otherwise | ||
| #3 | #E3 | Brake control module (BCM), Transmission control module (TCM) signal feed | Ubat at ignition in position I; Ulow otherwise | ||
| #4 | #E4 | Reserve | |||
| #5 | #E5 | Reserve | |||
| #6 | #E6 | Reserve | |||
| #7 | #E7 | Reserve | |||
| #8 | #E8 | Windshield washer motor, power supply | Ulow | Ubat/Ulow | |
| #9 | #E9 | Signal, ignition position III to Engine control module (ECM). | |||
| #10 | #E10 | Engine control module (ECM), waking | Ulow | Ubat/Ulow | |
| #11 | #E11 | High beam right-hand, power supply | Ulow | Ubat/Ulow | |
| #12 | #E12 | Tailgate washer motor, power supply | Ulow | Ubat/Ulow | |
| #13 | #E13 | Front left-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #14 | #E14 | Back-up (reversing) lamp, check signal | Ulow | Ulow/Ubat | |
| #15 | #E15 | Reserve | |||
| #16 | #E16 | Reserve | |||
| #17 | #E17 | Reserve | |||
| #18 | #E18 | Spare | Ubat | Ubat | |
| #19 | #E19 | Reserve | |||
| #20 | #E20 | 30-supply to the central electronic module (CEM) | Ulow | Ubat | |
| #21 | #E21 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #22 | #E22 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #23 | #E23 | 30-supply to the central electronic module (CEM) | Ubat | Ubat | |
| #24 | #E24 | Reserve | |||
| #25 | #E25 | Low beam left, power supply | Ubat/Ulow | Ubat/Ulow | |
| #26 | #E26 | Reserve | |||
| #27 | #E27 | Full beam left, power supply | Ulow | Ubat/Ulow | |
| #28 | #E28 | Stop lamp switch, power supply | Ulow/Ulow | Ulow/Ubat | |
| #29 | #E29 | 15-feed (Power feed from ignition)/ relay diesel filter | Ulow | Ulow/Ubat | |
| #30 | #E30 | Relay electrically heated rear window | |||
| #31 | #E31 | Reserve | |||
| #32 | #E32 | Reserve | |||
| #33 | #E33 | Reserve | |||
| #34 | #E34 | Reserve | |||
| #35 | #E35 | Reserve | |||
| #36 | #E36 | Siren, power supply | Ubat | Ubat | |
| #37 | #E37 | Low beam right-hand, power supply | Ulow | Ubat/Ulow | |
| #38 | #E38 | Front left-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #39 | #E39 | Front right-hand turn signal lamp, power supply | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #40 | #E40 | Stop lamp switch, check signal to ECM | Ubat/Ulow | Ubat/Ulow | |
| #41 | #E41 | Stop lamp switch, control signal | Ubat/Ulow | Ubat/Ulow | |
| Connector G, Front-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #G1 | Communication LIN bus 3 | During communication the voltage is 0V - Ubat | Siren control module (SCM) | |
| #2 | #G2 | Front right-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #3 | #G3 | Communication LIN bus 9 | During communication the voltage is 0V - Ubat | Windshield wiper, rain sensor | |
| #4 | #G4 | Reserve | |||
| #5 | #G5 | Reserve | |||
| #6 | #B6 | Reserve | Ulow | Ulow | |
| #7 | #G7 | Accelerator pedal (AP) position sensor, check signal | Ulow | Ulow | Only 5-cylinder engines |
| #8 | #G8 | Reserve | |||
| #9 | #G9 | Relay, front fog lamp, control signal | Ubat | Ulow/Ubat | On vehicles equipped with the function for running lights, the relay supplies the front fog lights instead of the running lights. |
| #10 | #G10 | Communication LIN bus 14 | Spare on vehicles with structure week before 201020. Battery monitoring sensor (BMS) Only vehicles with function for brake energy regeneration. | ||
| #11 | #G11 | Relay, headlamp wash / wipe, control signal | Ubat | Ulow/Ubat | |
| #12 | #G12 | Clutch pedal sensor, check signal | Ulow | Ulow | Only 5-cylinder engines |
| #13 | #G13 | Reserve | |||
| #14 | #G14 | Communication CAN_L high speed network | The voltage is 1.5-2.5 V during communication | ECM/BCM/EPS/ISG/TCM/HCM | |
| #15 | #G15 | Communication CAN_H high speed network | The voltage is 2.0-3.5 V during communication | ECM/BCM/EPS/ISG/TCM/HCM | |
| #16 | #G16 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | ||
| #17 | #G17 | Voltage secondary battery | Ubat The voltage may differ from the vehicle's other voltage. First when the secondary battery is connected to the vehicle's electrical system (secondary battery relay activated) when, e. g., charging the battery, the voltage is the same as for other voltage in the vehicle. | Only on vehicle with the function Automatic engine start/stop. | |
| #18 | #G18 | Relay, horn, control signal/ Panic function | Ulow/Ubat | Ulow/Ubat | |
| #19 | #G19 | Hood switch | Ulow with the hood closed Ulow-Ubat with the hood open | Pulsed signal, f=100Hz | |
| #20 | #G20 | Reserve | |||
| #21 | #G21 | Clutch pedal sensor, power supply | Ulow | U=5 V | All engines |
| #22 | #G22 | Accelerator pedal (AP) position sensor, power supply | Ulow | U=5 V | |
| #23 | #G23 | Clutch pedal sensor, signal | Ulow | U=0.15-4.75V | |
| #24 | #G24 | Clutch pedal sensor, power supply | Ulow | Ulow/Ubat | I4-motor |
| #25 | #G25 | Reserve | |||
| #26 | #G26 | Communication LIN bus 2 | During communication the voltage is 0V - Ubat | Xenon lamps (GDL) | |
| #27 | #G27 | Signal, brake fluid level | Ulow at normal level; Ubat at low level | ||
| #28 | #G28 | Switch, washer fluid level | Ulow at normal level; Ubat at levels below 0.7 liters | ||
| #29 | #G29 | Reserve | |||
| #30 | #G30 | Fuel pump (FP) relay | |||
| #31 | #G31 | Accelerator pedal (AP) position sensor, check signal | Ulow | U=0.15-4.85V | |
| #32 | #G32 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | ||
| Connector A, Cockpit-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #A1 | Dimmer, check signal | Ulow | Ulow-Ubat | |
| #2 | #A2 | Reserve | |||
| #3 | #A3 | Positive temperature coefficient (PTC) heater, signal supply | Ubat at ignition in position II; Ulow otherwise | ||
| #4 | #A4 | Data link connector (DLC), power supply | Ubat | Ubat | |
| #5 | #A5 | Reserve | |||
| #6 | #A6 | Reserve | |||
| #7 | #A7 | Reserve | |||
| #8 | #A8 | Phone module (PHM), power supply | Ulow | Ubat | |
| #9 | #A9 | Multimedia module (MMM) display, power supply | Ulow | Ubat | |
| #10 | #A10 | SRS module/ ECM module, 15-volt feed | Ulow | Ubat | |
| #11 | #A11 | Reserve | |||
| #12 | #A12 | Reserve | |||
| #13 | #A13 | Reserve | |||
| #14 | #A14 | CEM, signal ground | Ulow | Ulow | |
| #15 | #A15 | S-supply (Power supply from ignition switch) | Ulow (Key out), Ubat (key in) | ||
| #16 | #A16 | Reserve | |||
| #17 | #A17 | 15-supply (Power supply from ignition switch) | Ubat (Key in positions II and III); Ulow otherwise | ||
| #18 | #A18 | Reserve | Ubat | Ubat | |
| #19 | #A19 | Reserve | Ubat | Ubat | |
| #20 | #A20 | Reserve | |||
| #21 | #A21 | Climate control module (CCM), infotainment control module (ICM), IAM power supply | Ulow | Ubat | |
| #22 | #A22 | Reserve | |||
| #23 | #A23 | Cigarette lighter, power supply | Ubat | Ubat | |
| #24 | #A24 | Reserve | |||
| #25 | #A25 | Courtesy lighting, power supply | Ubat/Ulow | Ubat/Ulow | Voltage supply alcolock (option 2009-) |
| #26 | #A26 | Reserve | |||
| #27 | #A27 | Reserve | |||
| #28 | #A28 | Power ground | Ulow | Ulow | |
| #29 | #A29 | Multimedia module (MMM), power supply | Ulow | Ubat | |
| #30 | #A30 | X supply (Voltage supply from ignition switch) | Ubat (Key in positions I and II); Ulow otherwise | ||
| #31 | #A31 | Reserve | |||
| #32 | #A32 | LED front fog lamp, ground | Ubat | Ulow | |
| #33 | #A33 | Phone module (PHM), collision signal | Airbag not triggered = Ubat-8V Airbag triggered= Pulse 1-0.6V below 200ms | ||
| #34 | #A34 | Fuel tank filler cover switch, check signal | Ulow | Ubat/Ulow | |
| #35 | #A35 | Communication LIN bus 3 | During communication the voltage is 0V - Ubat | Remote receiver RKE and RRX | |
| #36 | #A36 | Reserve | |||
| #37 | #A37 | LED ABL, ground | Ubat | Ulow | |
| #38 | #A38 | Glove compartment lighting/ Left, right headlight/ courtesy lighting, power feed | Ubat (Key in positions I and II); Ulow otherwise | ||
| #39 | #A39 | Back-up gear inhibitor, control signal | Ubat at speeds above 25 km/h; Ulow at speeds below 15 km/h | Manual 6-speed transmission | |
| #40 | #A40 | Light switch, power supply | Ubat | Ubat | |
| #41 | #A41 | Reserve | |||
| #42 | #A42 | 50-supply (Power supply from ignition switch) | Ubat (Key in position III); Ulow otherwise | ||
| #43 | #A43 | Supplemental restraint system module (SRS), X-power supply | Ubat (Key in positions I and II); Ulow otherwise | ||
| #44 | #A44 | Climate control system motors and sensors, power supply | Ulow | Ubat | |
| #45 | #A45 | Steering wheel module (SWM) cruise control, power feed | Ubat (Key in positions I and II); Ulow otherwise | ||
| #46 | #A46 | Reserve | |||
| Connector B, Cockpit-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #B1 | Positive temperature coefficient (PTC) heater, control signal | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #2 | #B2 | Light switch, control signal | Ulow/Ubat | Ulow/Ubat | Light switch in position 1 |
| #3 | #B3 | Lamp, switch, hazard warning signal flashers, power supply | Ubat-Ulow if activated; Ulow otherwise | ||
| #4 | #B4 | Light switch, control signal | Ulow/Ubat | Ulow/Ubat | Light switch in position 0 |
| #5 | #B5 | Alarm LED, power supply | Alarm activated: 5V 0.5Hz 5% duty Alarm triggered: 5V 4Hz 25% duty | Pulse width modulation (PWM) signal | |
| #6 | #B6 | Rear fog lamp LED in light switch, power supply | Ulow | Ubat/Ulow | |
| #7 | #B7 | Solar sensor 2, power feed | |||
| #8 | #B8 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | Infotainment control module (ICM) / Driver information module (DIM) | |
| #9 | #B9 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Infotainment control module (ICM) / Driver information module (DIM) | |
| #10 | #B10 | Steering column lock module (SCL), power supply | Ubat approx. one second after the key has been inserted or removed; Ulow otherwise | Does not apply to the USA/CDN markets for 2009 | |
| #11 | #B11 | Diagnostic communication (CAN H) for the high speed network | The voltage is 2.0-3.5 V during communication | ||
| #12 | #B12 | Diagnostic communication (CAN_L) for the high speed network | The voltage is 1.5-2.5 V during communication | ||
| #13 | #B13 | Key lock ignition switch, control signal | Ulow when key approved; Ubat otherwise | ||
| #14 | #B14 | Malfunction indicator lamp (MIL), power supply | Ulow | Ubat/Ulow | |
| #15 | #B15 | Diagnostic communication (CAN_L) for the low speed network | The voltage is 1.5-2.5 V during communication | ||
| #16 | #B16 | Diagnostic communication (CAN_H) for the low speed network | The voltage is 2.0-3.5 V during communication | ||
| #17 | #B17 | Communication LIN bus 2 | During communication the voltage is 0V - Ubat | Steering column lock module (SCL) / start control module (SCU) | |
| #18 | #B18 | Blower fan motor, control signal | Blower fan activated: Ubat f=400Hz 16-95% duty | Pulse width modulation (PWM) signal | |
| #19 | #B19 | Switch hazard warning signal flashers, control signal | Ulow/Ubat | Ulow/Ubat | |
| #20 | #B20 | Reserve | |||
| #21 | #B21 | Dimmer, signal feed | |||
| #22 | #B22 | Switch, rear fog lamp, control signal | Ulow/Ubat | Ulow/Ubat | |
| #23 | #B23 | Switch, front fog lamp, control signal | Ulow/Ubat | Ulow/Ubat | |
| #24 | #B24 | Communication CAN_H low speed network | The voltage is 2-3.5 V during communication | Carphone module | |
| #25 | #B25 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | Carphone module | |
| #26 | #B26 | Switch horn, check signal | Approx. 6-7V /Ubat | Approx. 6-7V /Ubat | |
| #27 | #B27 | Switch privacy lock, check signal | Ubat | Ulow/Ubat | |
| #28 | #B28 | Sun sensor, ground | Ulow | Ulow | |
| #29 | #B29 | Twilight sensor | Ulow | U=5 V | |
| #30 | #B30 | Solar sensor 1, power feed | Ulow | U=0.25-4.75V | |
| #31 | #B31 | Switch high beam flash, check signal | Ubat | Ulow/Ubat | |
| #32 | #B32 | Blower fan motor, check signal | Fan OK and active: Amplitude = Ubat, f = 80 - 600 Hz, 50 % duty. Fan OK, but input signal outside tolerance: Amplitude = Ubat, f = 12.5 Hz, 50 % duty. Fan OK, but not active: Amplitude = Ubat, f = 0Hz, 100 % duty. | Pulse width modulation (PWM) signal | |
| Connector C, Floor-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #C1 | Switch parking brake, check signal | Ubat | Ulow/Ubat | |
| #2 | #C2 | Fuel tank filler cover, control signal | Ubat/Ulow | Ubat/Ulow | |
| #3 | #C3 | Left-hand stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #4 | #C4 | Right-hand stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #5 | #C5 | Reserve | |||
| #6 | #C6 | Rear fog lamp, power supply | Ulow | Ubat/Ulow | |
| #7 | #C7 | High level stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #8 | #C8 | Unlocking tailgate, control signal | Ulow | Ubat/Ulow | |
| #9 | #C9 | Rear direction indicator left, signal | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #10 | #C10 | Rear direction indicator right, signal | Ulow | Ubat-Ulow/Ulow | Pulse width modulation (PWM) signal |
| #11 | #C11 | Reserve | |||
| #12 | #C12 | Rear right-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #13 | #C13 | License plate lighting, power supply | Ubat/Ulow | Ubat/Ulow | |
| #14 | #C14 | Rear left-hand parking lamp, power supply | Ubat/Ulow | Ubat/Ulow | |
| #15 | #C15 | Emergency brake lights (US-market) Spare otherwise. | From model year 2010, the output for emergency brake lights is used on the US-market. | ||
| #16 | #C16 | Fuel pump (FP), power supply | Ulow | Ubat/Ulow | |
| #17 | #C17 | Reserve | |||
| #18 | #C18 | Rear seat belt buckle, X-supply | Ulow | Ubat | |
| #19 | #C19 | Reserve | |||
| #20 | #C20 | Cargo compartment lighting and power seat, power supply | Ubat/Ulow | Ubat/Ulow | Supply from relay, interior lighting |
| #21 | #C21 | Left-hand rear door module (LDM), power supply | Ubat | Ubat | |
| #22 | #C22 | 12 V output cargo compartment, power supply | Ubat | Ubat | |
| #23 | #C23 | Audio module (AUD), power supply | Ubat | Ubat | |
| #24 | #C24 | Passenger door module (PDM), power supply | Ubat | Ubat | |
| #25 | #C25 | Reserve | |||
| #26 | #C26 | Brake light, control signal to Keyless vehicle module (KVM) | |||
| #27 | #C27 | Right-hand rear door module (RDM), power supply | Ubat | Ubat | |
| #28 | #C28 | Reserve | |||
| #29 | #C29 | Passenger power seat module (PSM), power supply | Ubat | Ubat | |
| #30 | #C30 | Power seat module (PSM), power supply | Ubat | Ubat | |
| #31 | #C31 | Driver door module (DDM), power supply | Ubat | Ubat | |
| #32 | #C32 | Keyless vehicle module (KVM), signal | At communication the voltage is Ubat-(1-1.5) V | ||
| #33 | #C33 | Rear windshield wiper, power supply | Ubat | Ubat | |
| #34 | #C34 | Rear windshield wiper, control signal | Ulow | Ubat/Ulow | Signal from relay, rear windshield wiper |
| #35 | #C35 | Reserve | |||
| #36 | #C36 | Reserve | |||
| #37 | #C37 | Occupant weight sensor (OWS), power supply | Ubat | Ubat | |
| #38 | #C38 | Reserve | |||
| #39 | #C39 | Tow hitch and back-up (reversing) warning, power supply | Ulow | Ubat | |
| #40 | #C40 | Audio module (AUD), power supply | Ubat at key in positions I and II; Ulow otherwise | Power supply from Relay, infotainment | |
| #41 | #C41 | Keyless vehicle module (KVM), power supply | Ubat | Ubat | |
| #42 | #C42 | Passenger seat heater, power supply | Ubat | Ubat | Power supply from relay, comfort |
| #43 | #C43 | Driver seat heater, power supply | Ubat | Ubat | Power supply from relay, comfort |
| #44 | #C44 | Antenna module (ATM), power supply | Ubat | Ubat | |
| #45 | #C45 | Back-up (reversing) lamp, power supply | Ulow | Ubat/Ulow | Power supply from relay, back-up (reversing) lamp |
| #46 | #C46 | Reserve | |||
| Connector F, Floor-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #F1 | Rear left-hand seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #2 | #F2 | Rear center seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #3 | #F3 | Rear right-hand seat belt buckle sensor, check signal | Ulow | 4-5V/0-1V | |
| #4 | #F4 | Reserve | |||
| #5 | #F5 | Fuel level sensor pump side, check signal | Ulow | U=0.5-4V | Full: 0.5V Empty: 4V |
| #6 | #F6 | Reserve | |||
| #7 | #F7 | Fuel level sensor, common ground | Ulow | Ulow | |
| #8 | #F8 | Reserve | |||
| #9 | #F9 | Reserve | |||
| #10 | #F10 | Reserve | |||
| #11 | #F11 | Reserve | |||
| #12 | #F12 | Collision signal | Activated = 2-8V Not activated = 8-12V | ||
| #13 | #F13 | Input signal seat belt reminder passenger | Ulow | U=0-5V | Oscillating signal in 3 phases |
| #14 | #F14 | Communication CAN_L high speed network | The voltage is 1.5-2.5 V during communication | SWM | |
| #15 | #F15 | Communication CAN L low speed network | The voltage is 1.5-2.5 V during communication | SRS | |
| #16 | #F16 | Communication CAN_H high speed network | The voltage is 2.0-3.5 V during communication | SWM | |
| #17 | #F17 | Input/output signal seat belt reminder passenger | Ulow | U=0-5V | Oscillating signal in 3 phases |
| #18 | #F18 | Switch passenger door, check signal | Ubat if the door is open; Ulow otherwise | ||
| #19 | #F19 | Switch driver's door, check signal | Ubat if the door is open; Ulow otherwise | ||
| #20 | #F20 | Switch right-hand rear door, check signal | Ubat if the door is open; Ulow otherwise Applies to C30: Ubat | Applies to C30: tampering protection for cable harness in tailgate | |
| #21 | #F21 | Switch left-hand rear door, check signal | Ubat if the door is open; Ulow otherwise Applies to C30: Ulow | Applies to C30: glass wire in rear window | |
| #22 | #F22 | Handle tailgate, check signal | Ulow/Ubat | Ulow/Ubat | Grounded when the tailgate handle is pressed in. |
| #23 | #F23 | Reserve | |||
| #24 | #F24 | Switch tailgate, check signal | Ubat if the tailgate is open; Ulow otherwise | ||
| #25 | #F25 | Fuel level sensor ejector side, check signal | Ulow | U=0.5-4V | Full: 0.5V Empty: 4V (AWD) |
| #26 | #F26 | Reserve | |||
| #27 | #F27 | Communication LIN 3 | During communication the voltage is 0V - Ubat | ||
| #28 | #F28 | Outside temperature sensor, signal ground | Ulow | Ulow | |
| #29 | #F29 | Reserve | |||
| #30 | #F30 | Communication CAN_H low speed network | The voltage is 2.0-3.5 V during communication | Supplemental restraint system module (SRS) / Driver door module (DDM) / Passenger door module (PDM) | |
| #31 | #F31 | Outside temperature sensor, check signal | Ulow | U=0.5-4V | |
| #32 | #F32 | Reserve | |||
| Connector H, Roof-2 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #15 | #H1 | LED seat belt reminder, power supply | Ulow | Ubat/Ulow | |
| #16 | #H2 | LED reduced alarm position, power supply | Ulow | Ubat/Ulow | |
| #17 | #H3 | Remote receiver (RKE/RRX), signal | At communication the voltage is Ubat-(1-1.5) V | Remote receiver Module (RRX) for non-keyless vehicle. Remote Receiver Module (RRX) for keyless vehicle. | |
| #18 | #H4 | Roof console and sun roof motor, power supply | Ubat | Ubat | |
| #19 | #H5 | Automatic anti-glare door mirror inhibitor, control signal | Ulow | Ubat/Ulow | |
| #20 | #H6 | Remote receiver (RKE/RRX), voltage feed | Ubat | Ubat | Remote receiver Module (RRX) for non-keyless vehicle. Remote Receiver Module (RRX) for keyless vehicle. |
| #21 | #H7 | Rain sensor module (RSM), power supply | Ubat | Ubat | |
| #22 | #H8 | Reserve | |||
| #23 | #H9 | Reserve | |||
| #24 | #H10 | Reserve | |||
| #25 | Terminal #H11 | Reserve | |||
| #26 | Terminal #H12 | Reserve | |||
| #27 | Terminal #H13 | Reserve | |||
| #28 | #H14 | Reserve | |||
| #29 | #H15 | Reserve | |||
| #30 | #H16 | Reserve | |||
| #31 | #H17 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), communication signal | Ulow-Ubat | Ulow-Ubat | Communication with both MMS or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), for 5DRS |
| #32 | #H18 | Control signal, comfort closing | Ulow | Ulow/Ubat | |
| #33 | #H19 | Switch reduced alarm position, control signal | Ubat | Ulow/Ubat | |
| #34 | #H20 | Control signal, sun roof | Ulow | Ubat-Ulow/Ulow | F=1.381*speed (Km/h), 50% pulse ratio. For C70 the output is used for light-emitting diodes in the doors for lock indication. |
| #35 | #H21 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), voltage feed | Ubat/Ulow | Ubat/Ulow | Feeds voltage to both MMS or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl. model year 2012), for 5DRS. |
| #36 | #H22 | PAD warning lamp, power supply | U low | U bat /U low | |
| #37 | #H23 | Communication LIN bus 9 | During communication the voltage is 0V - Ubat | RSM, HUS | |
| #38 | #H24 | Spare | |||
| #39 | #H25 | PAEL warning light, power feed | U low | U bat /U low | |
| #40 | #H26 | Reserve | |||
| #41 | #H27 | Reserve | |||
| #42 | #H28 | Reserve | |||
| #43 | #H29 | Reserve | |||
| #44 | #H30 | Reserve | |||
| #45 | #H31 | Reserve | |||
| #46 | #H32 | Reserve | |||
| Connector D, Roof-1 | |||||
|---|---|---|---|---|---|
| Breakout box terminal | Control module terminal | Signal type | Ignition off Active / Not active | Ignition on Active / Not active | Miscellaneous |
| #1 | #D1 | Reserve | |||
| #2 | #D2 | Reserve | |||
| #3 | #D3 | Roof lighting, return cable | Ulow | Ulow | |
| #4 | #D4 | LED switch, roof movement | Ulow | Ulow-Ubat | C70 |
| #5 | #D5 | High level stop lamp, power supply | Ubat/Ulow | Ubat/Ulow | 4 door |
| #6 | #D6 | Reserve | |||
| #7 | #D7 | Roof lighting, power supply | Ubat/Ulow | Ubat/Ulow | |
| #8 | #D8 | Reserve | |||
| #9 | #D9 | Reserve | |||
| #10 | #D10 | Mass movement sensor (MMS) or movement sensor (IMS) (IMS replaces MMS for S40, C30, and V50 from and incl model year 2012), Rain sensor module (RSM) and Remote receiver (RKE/RRX), ground | Ulow | Ulow | Remote receiver Module (RRX) for non-keyless vehicle. Remote Receiver Module (RRX) for keyless vehicle. |
| #11 | #D11 | Reserve | |||
| #12 | #D12 | Roof console and sun roof, ground | Ulow | Ulow | |
| #13 | #D13 | Reserve | |||
| #14 | #D14 | Sun roof control module, power supply | Ubat (for 5 minutes only according to the conditions on the right) | Ubat | Active when the ignition is off and neither of the front doors have been opened |
SIGNAL DESCRIPTION
General
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse width modulated signal as a % |
Scheme 246
| Breakout box terminal | Control module terminal | Signal type | Ignition on | Other |
|---|---|---|---|---|
| #C1-1 | Power supply | U = U bat | ||
| #C1-2 | Ground, power supply | U = U low | ||
| #C1-3 | Reserve | |||
| #C1-4 | Reserve |
CONNECTOR C1
Scheme 247
| Breakout box terminal | Control module terminal | Signal type | Ignition on | Other |
|---|---|---|---|---|
| #C2-1 | MOST input signal | Optical input signal when the MOST network is activated | ||
| #C2-2 | MOST output signal | Optical output signal when the MOST network is activated |
CONNECTOR C2
